UM1932
4.19

ST-LINK/V2-1 USB Mini-B connector CN1

The USB connector CN1 is used to connect the embedded ST-LINK/V2-1 to the PC.
Pin number
1
2
3
4.20

Audio jack CN3

A 3.5 mm stereo audio jack CN3 is available on STM32F469I-DISCO discovery board to
connect a headphone.

Figure 11. USB Mini-B connector CN1 (front view)

Table 12. USB Mini-B connector CN1

Description
VBUS (power)
DM
DP
UM1932 Rev 3
Hardware layout and configuration
Pin number
4
5,6
-
Description
GND
Shield
-
25/30
