S&C MIcro-AT Installation, Programming, And Operation Manual page 40

Appendix
Table 11. Event Identification Code Numbers In The Event Menu—Continued
Code
Number
General Events
601 Bus Type changed to COMMON
602 Bus Type changed to SPLIT
603 Bus Type changed to SPLIT-COM
604 Bus Type changed to PAD MNT
605 Bus Type changed to VISTA COM
606 Bus Type changed to VISTA SPLT
620 Preferred set to LEFT
621 Preferred set to RIGHT
622 System Frequency set to 50 Hz
623 System Frequency set to 60 Hz
624 Voltage Sensing set to 2-WIRE
625 Voltage Sensing set to 4-WIRE
626 Voltage Sensing Configuration set to LINE-TO-
GND
627 Voltage Sensing Configuration set to LINE-TO-
LINE
628 Source Bad Criteria set to 1-PHASE
629 Source Bad Criteria set to ALL PHASES
630 Unbalance Detect set to OUT
631 Unbalance Detect set to IN and OFF
632 Unbalance Detect set to IN and ON
633 Voltage Value Format set to VOLTS
634 Voltage Value Format set to PERCENTAGE
635 Return set to HOLD
636 Return set to AUTO
637 Return set to WINDOW
638 UPS Application set to NO UPS
639 UPS Application set to UPS ON LEFT
40 S&C Instruction Sheet 515-600
Description
Code
Number
Overcurrent Latch Events
640 UPS Application set to UPS ON RIGHT
641 Transition set to OPEN
642 Transition set to CLOSED
643 Lockout set to OUT
644 Lockout set to IN
645 Lockout set to EXTERNAL
646 Restore Values Executed
647 Dwell Timer set to OUT
648 Dwell Timer set to IN
649 Supervisory Control set to OUT
650 Supervisory Control set to IN
651 Normalize Left Executed
652 Normalize Right Executed
653 Set Base Left Executed
654 Set Base Right Executed
655 COM0 Bit Rate set to 2400
656 COM0 Bit Rate set to 4800
657 COM0 Bit Rate set to 9600
658 COM0 Bit Rate set to 19200
659 COM0 Bit Rate set to 38400
700 System date changed
701 System time changed
Description
