Table 11. Event Identification Code Numbers In The Event Menu
Code
Number
General Events
0 System Startup
10
Local to Auto
11 Local to Manual
12 Remote to Auto
13 Remote to Manual
20 Test keys enabled
21 Test keys disabled
88 Illegal Power Fail
90 EEPROM Initialized
99 Power Fail
Switch Operator Control Events
100 Closing Left
102 Opening Left
104 Operation Timeout Left
105
Operation Limit Left
111 Unexpected Opening Left
112 Unexpected Closing Left
113 Unknown Position Left
115 llegal Position Left
120
Closing Right
1222 Opening Right
124 Operation Timeout Right
125 Operation Limit Right
131 Unexpected Opening Right
132
Unexpected Closing Right
133 Unknown Position Right
135 Illegal Position Right
Source-Transfer Control Events
201 On Preferred
202 Timing Preferred Loss
203 Opening Preferred
204 Closing Alternate
205 On Alternate
206 Timing Alternate Loss
207 Timing Preferred Return
208 Opening Alternate
209 Closing Preferred
210 Delaying Return
211 Delaying Forward Transfer
212 Verify Preferred Loss
213 Verify Alternate Loss
217 Enter Lockout
218 Enter Manual
219 Enter Exception
220 Waiting for Window
Description
Code
Number
Overcurrent Latch Events
410 Latch OC Left
411 Start LR Timer Left
412 Cancel LR Timer Left
413 Reset OC Latch Left
414 Enter Normal Left
415 Enter Restraint Left
416 Enter Reset Restraint Left
417 Cancel Restraint Left
418 Cancel Confirm OC Left
419
Cancel Reset Restraint Left
420 Latch OC Right
421 Start LR Timer Right
422 Cancel LR Timer Right
423 Reset OC Latch Right
424
Enter Normal Right
425 Enter Restraint Right
426 Enter Reset Restraint Right
427 Cancel Restraint Right
428 Cancel Confirm OC Right
429
Cancel Reset Restraint Right
430 Start Verify OC Timer Left
431 Reset Verify OC Timer Left
440 Start Verify OC Timer Right
441 Reset Verify OC Timer Right
Source Condition Events
510 Loss of Left Due to Undervoltage
511 Loss of Left Due to Open Phase
512 Return of Left
513 Overvoltage Left
520 Loss of Right Due to Undervoltage
521 Loss of Right Due to Open Phase
522 Return of Right
523 Overvoltage Right
