Saving and Loading a Setup Configuration
When several IntelliCap controls use a similar setup configuration, the configuration from
one control can be saved and loaded into other controls. Only the setpoints that are different
for each control need to be configured.
Follow these steps to save a configuration:
STEP 1. Connect a PC to the control and start the IntelliLink software.
STEP 2. Click on the Setup button. Then, click on the Save Data button.
In the dialog box, choose a file name and location for saving this configuration. The
STEP 3.
extension ".cfg" is assumed. Then, click on the Save button.
Note: This process does not save the Physical Location field on the Setup: General screen.
Follow these steps to load a saved configuration into a control:
STEP 1. Connect a PC to the control and start the IntelliLink software.
STEP 2. Click on the Tools menu. Then, click on the Load Setpoints entry.
In the dialog box, choose the file for the configuration being loaded. Click on the
STEP 3.
Open button.
Enter the full path name and file name. Then, press the <Enter> key.
STEP 4.
STEP 5. Make any necessary setpoint configuration changes.
STEP 6. Enter the correct value in the Physical Location field on the Setup: General
screen.
S&C Instruction Sheet 1022-540 23
