S&C IntelliCap
Plus Automatic Capacitor Control
®

Table of Contents

Section
Qualified Persons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Read this Instruction Sheet . . . . . . . . . . . . . . . . . . . . . . 2
Retain this Instruction Sheet . . . . . . . . . . . . . . . . . . . . . . 2
Proper Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Special Warranty Provisions . . . . . . . . . . . . . . . . . . . . . . 2
Understanding Safety-Alert Messages . . . . . . . . . . . . . . 4
Following Safety Instructions . . . . . . . . . . . . . . . . . . . . . 4
Replacement Instructions and Labels . . . . . . . . . . . . . . 4
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Applicable Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Pre-Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . 6
Optional In-Shop Setup Steps . . . . . . . . . . . . . . . . . . . . 6
October 30, 2017
© S&C Electric Company 2003-2017, all rights reserved
Installation
Page
Section
On-Site Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Meter Base Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Bracket Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Harness Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
220-Volt Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Connecting Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Energize and Test the Control . . . . . . . . . . . . . . . . . . . . 22
Communication Equipment . . . . . . . . . . . . . . . . . . . . . . 23
Connecting Communication Hardware . . . . . . . . . . . . . 24
Instruction Sheet 1023-510
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IntelliCap Plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for S&C IntelliCap Plus

Summary of Contents for S&C IntelliCap Plus

  • Page 1: Table Of Contents

    S&C IntelliCap Plus Automatic Capacitor Control ® Installation Table of Contents Section Page Section Page Introduction Installing the Capacitor Control Qualified Persons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 On-Site Installation .

  • Page 2: Introduction

    PDF format at sandc.com/en/support/product-literature/ . Retain this This instruction sheet is a permanent part of your S&C IntelliCap Plus Automatic Capacitor Instruction Sheet Control. Designate a location where you can easily retrieve and refer to this publication.
  • Page 3 Introduction Warranty of the S&C IntelliCap Plus Automatic Capacitor Control is contingent upon the installation, configuration, and use of the control or software in accordance with S&C’s applicable instruction sheets. This warranty does not apply to major components not of S&C manufacture, such as communication devices.

  • Page 4: Safety Information

    Understanding Several types of safety-alert messages may appear throughout this instruction sheet and on labels attached to the S&C IntelliCap Plus Automatic Capacitor Control. Familiarize Safety-Alert Messages yourself with these types of messages and the importance of these various signal words: DANGER “DANGER”...

  • Page 5: Safety Precautions

    Safety Precautions DANGER The S&C IntelliCap Plus Automatic Capacitor Control line voltage input range is 93 to 276 Vac. Failure to observe the precautions below will result in serious personal injury or death. Some of these precautions may differ from your company’s operating procedures and rules .

  • Page 6: Pre-Installation Instructions

    S&C Electric Company. Pre-Installation Before installing the IntelliCap Plus control, carry out the following steps in the shop: Checklist STEP 1. Inspect the control for visible damage.

  • Page 7: Installing The Capacitor Control

    . The S&C IntelliCap Plus Automatic Capacitor Control is connected to switchgear operating at primary voltage levels . High voltage may be present in the wiring to the switch control or the switch control itself during certain failures of the switchgear wiring or grounding system, or because of a failure of the switch itself .

  • Page 8: Meter Base Mounting

    Install the control on the meter base, pole, or panel in a location with minimum traffic exposure. All IntelliCap Plus controls have an internal terminal strip; the terminal strip configuration is shown on a label inside the enclosure below the faceplate. The terminal strip wires connect to the meter base or cable connectors.
  • Page 9 Installing the Capacitor Control Ac line Ac neutral Open Close Figure 2. Four-jaw meter base socket configuration for capacitor controls with catalog number suffix -J40. Ac line Ac neutral Close Open Figure 3. Four-jaw meter base socket configuration for capacitor controls with catalog number suffix -J41.
  • Page 10 Installing the Capacitor Control Current sensor Ac neutral Ac line Open Current sensor Close neutral Figure 5. Six-jaw meter base socket configuration for capacitor controls with catalog number suffix -J61. Ac line Ac neutral Current sensor Current sensor hot neutral Open Close Figure 6.
  • Page 11 Installing the Capacitor Control Ac neutral & current Current sensor sensor neutral Ac line Open Current sensor Close hot (alternate) Figure 8. Six-jaw meter base socket configuration for capacitor controls with catalog number suffix -J64. Not connected Ac neutral Ac line Open Not connected Close...
  • Page 12 Common neutral Switch close/ open cable Neutral sensor to junction box cable Junction box to control cable S&C IntelliCap Plus Automatic Capacitor Control Ground lug Figure 12. Grounding the IntelliCap Plus enclosure. S&C Instruction Sheet 1023-510...
  • Page 13 Installing the Capacitor Control WARNING If lightning arresters are installed their ground path must not go through the neutral current sensor . Connect them to ground on the earth side of the sensor, to protect from potentially lethal voltages . Plug control into the meter base socket.

  • Page 14: Bracket Mounting

    Installing the Capacitor Control Bracket Mounting Attach the control to the pole with either lag bolts for a wood pole, or metal straps for a concrete or metal pole. See Figures 14 and 15 on page 15. Then, connect the cable as described below.
  • Page 15 Installing the Capacitor Control 9.85 (250) 1.00 (25) Upper mounting hole 20.00 14.79 (508) (376) IntelliCap Plus 18.00 (457) Dimensions in inches (mm) Lower mounting hole 5.00 (127) Figure 14. Front view of the capacitor control enclosure, showing the mounting holes. 10.25 (260) 8.44...
  • Page 16 Installing the Capacitor Control Not connected Ac line Open Close Ac neutral Figure 16. Bracket mount receptacle wiring configuration, five-pin for capacitor controls with catalog number suffix -M01, -D11, or -D12. Ac neutral & shield ground Line current Ac line sensor hot Neutral current/voltage Open...
  • Page 17 Installing the Capacitor Control Figure 19. Terminal Block wiring and test point configuration for catalog number suffix -JB1 or -JB2. Follow these steps to attach the control to a metal or concrete pole: Pass a stainless-steel strap or clamp through the two upper mounting slots in the STEP 1.

  • Page 18: Harness Wiring

    The IntelliCap Plus relay contacts are rated at 20 A at 250 Vac, 1 HP 120/250 Vac. In addition they have been tested to operate three Joslyn Vacuum Switches (36 A). If you need 125 Vdc to operate the capacitor switches, install interposing relays rated for 125 Vdc.

  • Page 19: 220-Volt Wiring

    240-volt output that has the center tap referenced to ground, connect the center tap to the Ac Neutral input and the high line to the Ac Line input of the IntelliCap Plus control. Use two auxiliary relays with 120-volt coils and 240-volt contacts rated to meet the requirements of the capacitor switch, and connect as indicated in Figure 20.

  • Page 20: Connecting Sensors

    Installing the Capacitor Control Connecting Sensors Some controls have var and/or neutral current or neutral voltage sensing connected in the meter socket. Other controls use connector(s) on the bottom of the control enclosure or terminal block J6. See Figure 11 on page 12 and Figure 19 on page 17, respectively. NOTICE Do not ground sensor cable shields at the top of the pole .
  • Page 21 Installing the Capacitor Control A phase B phase C phase Neutral Fuses Switches Starpoint Sensor To cap control option To cap control To cap control To cap control Lindsey sensor PT option S&C sensor option option Figure 22. Neutral voltage sensor and wye-connected bank with starpoint. S&C Instruction Sheet 1023-510...

  • Page 22: Energize And Test The Control

    (a) Observe that the LCD screen shows: **UnitOK**. If it shows: **ACTIVE ALARMS**, check the capacitor bank for a problem. The alarm condition must be corrected before the IntelliCap Plus control will operate correctly. (b) Check that the LCD screen is scrolling through the real-time and setpoint data. If the display is blank or if there is an error message, see Instruction Sheet 1023-550, “S&C IntelliCap Plus Automatic Capacitor Control: Troubleshooting.”...

  • Page 23: Communication Equipment

    A UtiliNet Radio should have a blinking pilot light. For most installations, the radio is installed in the enclosure door. The IntelliCap Plus control has two remote communication ports. When used with suitable communication equipment and protocols, you can remotely monitor and control the capacitor control installation.

  • Page 24: Connecting Communication Hardware

    For more information, see the appropriate communication points list, or contact S&C Electric Company. Connecting All IntelliCap Plus controls are radio ready. This provides the flexibility to add communication Communication hardware later. Hardware The SCADA PORT connector provides a communication signal and power (12 Vdc) connection for the radio.

  • Page 25: Installation And Connection Drawings

    Installation and Connection Drawings S&C Instruction Sheet 1023-510...
  • Page 26 Installation and Connection Drawings S&C Instruction Sheet 1023-510...
  • Page 27 Installation and Connection Drawings S&C Instruction Sheet 1023-510...
  • Page 28 Installation and Connection Drawings S&C Instruction Sheet 1023-510...
  • Page 29 Installation and Connection Drawings S&C Instruction Sheet 1023-510...
  • Page 30 Installation and Connection Drawings S&C Instruction Sheet 1023-510...
  • Page 31 Installation and Connection Drawings S&C Instruction Sheet 1023-510...
  • Page 32 Installation and Connection Drawings S&C Instruction Sheet 1023-510...
