Trove2Ks2 Enclosure Dimensions - Altronix TROVE Trove2KS2 Installation Manual

1.25"
(31.75mm)
6.25"
(21.59mm)
(158.75mm)
1.5"
1.25"
(38.1mm)
(31.75mm)
G
(685.8mm)
1.00"
(25.4mm)
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
web site: www.altronix.com | e-mail: info@altronix.com | Made in U.S.A.
IITroveKS
- 8 -
Trove2KS2 Enclosure Dimensions (H x W x D approximate):
27.25" x 21.75" x 6.5" (692.2mm x 552.5mm x 165.1mm)
2.00" 5.25"
(50.8mm) (133.35mm)
0.85"
27.00"
0.85"
(21.59mm)
2.00" 5.25"
(50.8mm) (133.35mm)
21.50"
(546.1mm)
3.50" 3.50"
(88.9mm) (88.9mm)
0.5625"
(14.29mm) 1.77"
(44.96mm)
2.415"
(61.34mm)
19.80"
(502.92mm)
7.00"
(177.79mm)
F04S
5.25"
(133.35mm)
0.685"
(17.399mm)
Knockouts
6.25"
1.125" (28.32mm)
(158.75mm)
0.885" (22.479mm)
1.25"
(31.75mm)
5.25" 2.00"
(133.35mm) (50.8mm)
2.00"
(50.8mm)
6.75"
(171.45mm)
8.25"
(209.54mm)
8.00"
(203.2mm)
2.00"
(50.8mm)
1.25"
(31.75mm)
MEMBER
TroveKS
