3 Assembling and using the cyclone

Pos : 4.2 /00005 Übersc hriften/1.1 Ü berschriften/1.1 Ü bers chriften BDA/11 Z ykl on M ontage (2) @ 3\mod_1279541156398_9.doc @ 20683 @ @ 1

3.1 Cyclone assembly

Pos : 4.3 /00004 War nhi nweis e/V0014 VORSICHT R oti erende M ess er @ 2 \mod_1263480051017_9.doc @ 18590 @ @ 1
Pos : 4.4 /00004 War nhi nweis e/V0001 VORSICHT Abg etrennte Fing er - Ei ngriff i n den drehenden R otor @ 2\mod_1279183830134_9.doc @ 20580 @ @ 1
Pos : 4.5 /00010 Bedienungsanlei tungen Kapitelsamml ung en/SM 300 Z yklon ( 2011) /0001 Z ySM Kapitel Z yklon M ontag e/0201 Z ySM Modul Montage Z yklon @ 2\mod_1279186828533_9.doc @ 20601 @ 3 @ 1
CAUTION
Injuries to limbs
Rotating blade
– Can cause injury to hands and feet.
• Keep hands and feet away from the device openings
when the device is switched on.
• Pull the plug out before cleaning or retrofitting.
CAUTION
Risk of injury to fingers
Reaching into the turning rotor
– Unintended reaching into the grinding area and the turning
rotor.
• Never connect the device to the mains without the
discharge flange.
• Only operate the device with discharge flange.
AV
1
Fig. 1: Removing the discharge flange
• Disconnect the device from the mains.
• Loosen the screw (A1).
• Pull off the discharge flange (AV).
