Summary of Contents for Retsch SM100
- Page 1 Manual Base Frame SM100 Translation © Retsch GmbH, 42781 Haan, Retsch-Allee 1-5, Germany 27.12.2011 0002...
- Page 2 Copyright Copyright by Retsch GmbH Haan, Retsch-Allee 1-5 D-42781 Haan Federal Republic of Germany...
- Page 3 Notes on the Operating Manual ......................4 Assembly Instructions ........................... 4 Frame assembly ..........................4 Index ..............................10...
-
Page 4: Frame Assembly
Pos : 3 /00005 Übersc hriften/1.1 Übersc hriften/1.1 Ü berschriften BDA/11 Ges tell M ontage @ 3\mod_1292917288312_9.doc @ 24070 @ @ 1 2.1 Frame assembly Pos : 4 /00010 Bedienungsanlei tungen Kapitelsamml ung en/SM 100/0010 SM100 Trans por t, Liefer umfang und Aufstellen/1020 SM100 Modul Gestell montieren @ 3\mod_1292496265450_9.doc @ 24060 @ @ 1... - Page 5 Assembly Instructions Fig. 1: Components of the stand The components come pre-assembled to simplify assembly of the frame. Fig. 2: Assembling the crossbar • Where necessary slightly loosen the four screws (TS) on the crossbar (TR). • Slide the crossbar into the lateral guides of the left and right roller track (RS).
- Page 6 Assembly Instructions Fig. 3: Fastening the crossbar angle bracket Ensure that the crossbar (TR) is aligned flush with the pre-assembled angle section (WS). Tighten the screw on the left and right of the angle section (SW). Fig. 4: Screwing the crossbar tight •...
- Page 7 Assembly Instructions Fig. 5: Mounting the side protective caps • Place the four black plastic caps on the openings. Fig. 6: Mounting the front protective caps • Place the two caps on the ends of the roller track.
- Page 8 Place the stand (SQ) on the crossbar. Fig. 8: Points for securing the stand Fig. 9: Screwing the stand onto the crossbar • Screw the stand (SQ) onto the crossbar. Fig. 10: Assembling the SM 100 • Then place the SM100 on the base frame.
- Page 9 Assembly Instructions • Using the 4 screws, screw the SM100 housing tightly onto the base frame. === Ende der Liste für T extmar ke Inhalt ===...
- Page 10 3 Index Assembly Instructions ........... 4 Notes on the Operating Manual ......4 befestigen Winkel-Traverse ........6 Schutzkappen ............7 Ständer Einzelteile ..........5 Changes ............... 4 Copyright .............. 4 Traverse montieren ..........5 Gestell ..............4 Untergestell ............4 Montage des Untergestells ........
