Antenna
The matching circuit is composed of C1, C2 and R1 for antenna impedance modification. By default,
value of R1 is 0Ω, while C1 and C2 are not mounted.
Figure 11: Antenna Efficiency at 700~960MHz and 1.7~6GHz
RMU500-EK_User_Guide
Π m
atching circuit
R1
0Ω
C2
Figure 10: Reference Design for Antenna
Figure 12: Antenna Efficiency at 1.7~6GHz
Module
ANT
C1
5G Module Series
RMU500-EK User Guide
17 / 26
