(b) Clock reception and generation
(c) Overflow counter
(d) Programmable local oscillator
(e) µp bus interface
(f) Generation of the AGC signal
COPYRIGHT SEXTANT Avionique 1995
c
The document reference is online, please check the correspondence between the online documentation and the printed version.
COMPONENT MAINTENANCE MANUAL
The Asic T100 receives:
- The HT100 clock (100 MHz), generated from the PLL1 circuit,
- The BT time base signal generated by the CPU PCB Z3
Based on these clocks, the Asic T100 generates the following clock
signals:
- H25T100 (25 MHz), by 4 way division of HT100,
- H2OT100 (20 MHz) by 5 way division of HT100
- H50 (50 MHz) by 2 way division of HT100
- Int BT
- The overflow counter is designed to count the number of presence
to 1 of the OVFL input bit on the HT100 clock during a period of
the int BT clock mentioned above.
This oscillator (specific to the Asic T100), is used to pre-process
the signal before a frequency change.
programmed using the µp bus interface, with 5 KHz steps; this makes
it possible to perform an infradine or supradine demodulation, de-
pending on the "frequency sign".
This interface enables the Asic T100 to communicate with the CPU
PCB using:
- Data bus D(25/31),
- Address bus A (0/3),
- Service bus SB.
This function is used to:
- Detect and compare amplitude
- Make integral proportional corrections.
Starting with AGC input and RAZCAG signals, the T100 circuit gene-
rates a AGC signal coded over 12 bits (DAC 0/11).
