Page 1: User Guide
THALES NAVIGATION ProMark2 System User Guide www.thalesnavigation.com...
Page 2 Thales Navigation. Your rights with regard to this publication and the computer programs are subject to the restrictions and limitations imposed by the copyright laws of the United States of America (“U.S.A.”) and/or the jurisdiction in...
Page 3 ONLY TO THE ORIGINAL PURCHASER OF THIS PRODUCT. In the event of a defect, Thales Navigation will, at its option, repair or replace the hardware product with no charge to the purchaser for parts or labor. The repaired or replaced product will be warranted for 90 days from the date of return shipment, or for the balance of the original warranty, whichever is longer.
Page 4 Thales Navigation, Inc., 471 El Camino Real, Santa Clara, California 95050, Phone: +1 408-615-5100, Fax: +1 408-615-5200 or Thales Navigation SA - ZAC La Fleuriaye - BP 433 - 44474 Carquefou Cedex - France Phone: +33 (0)2 28 09 38 00, Fax: +33 (0)2 28 09 39 39 Promark2 User’s Guide...
Page 5 THIS WARRANTY APPLIES ONLY TO THE ORIGINAL PURCHASER OF THIS PRODUCT. In the event of a defect, Thales Navigation will, at its option, repair or replace the hardware product with no charge to the purchaser for parts or labor.
Page 6 Certain conditions can cause inaccuracies which could require modifications to the receiver. Examples of such conditions include but are not limited to changes in the GPS or GLONASS transmission.). Opening, dismantling or repairing of this product by anyone other than an authorized Thales Navigation Service Center will void this warranty.
Page 7: Table Of Contents
Contents Chapter 1 Introduction ...1 What is the ProMark2 Survey System? ... 1 Items Supplied with ProMark2 ... 2 ProMark2 GPS Receiver ... 2 External GPS Antenna ... 3 External Antenna Cable ... 3 Vertical Antenna Extension ... 4 Field Receiver Bracket ... 4 HI (Height of Instrument) Measurement Tape ...
Page 8 Stop-and-go or Kinematic Base ...59 Kinematic Initialization ...61 Overview ... 61 Bar Point Initialization ... 62 Known Point Initialization ... 63 New Point Initialization... 65 Data Collection ...65 Stop-and-go Rover ...79 Survey Status Screen ... 91 Kinematic Alarm ...92 Kinematic Rover ...93 Chapter 4 Detailed Screen Descriptions ...
Page 9: List Of Figures
Figure 1.1: ProMark2 Two-Receiver System ... 1 Figure 1.2 ProMark2 GPS Receiver ... 2 Figure 1.3 External GPS Antenna ... 3 Figure 1.4 External Antenna Cable ... 3 Figure 1.5 Vertical Antenna Extension ... 4 Figure 1.6 Field Receiver Bracket ... 4 Figure 1.7 HI Measurement Tape ...
Page 10 Figure 3.11 Mounting ProMark2 into Field Bracket Cradle ... 42 Figure 3.12 Field Bracket on Tripod ... 43 Figure 3.13 Antenna Cable Connection at the Antenna and Receiver ... 44 Figure 3.14 Measuring HI (Height of Instrument) ... 45 Figure 3.15 Mode Screen ... 46 Figure 3.16 Survey Screen ...
Page 11 Figure 3.54 Survey Status Stop-and-go Screen ... 91 Figure 3.55 Mode Screen... 93 Figure 3.56 Survey Screen... 94 Figure 3.57 Survey Menu ... 95 Figure 3.58 Point Attribute Screen ... 96 Figure 3.59 Init Mode Screen ... 97 Figure 3.60 Point Attribute Screen ... 97 Figure 3.61 Recording Interval Screen ...
Page 12 Figure 4.29 Low Memory Alarm ... 139 Figure 4.30 Kinematic Alarm... 140 Figure 4.31 Power Down Screen... 141 Promark2 User’s Guide...
Page 13: List Of Tables
List of Tables Table 1.1 Performance and Physical Specifications ... 12 Table 2.1 Control Buttons used for Survey Functions... 24 Table 4.1 Survey Screen Selections ... 109 Table 4.2 Survey Menu Screen Selections... 110 Table 4.3 Survey Mode Screen Parameters ... 111 Table 4.4 Point Attribute - Static Screen Parameters...
Page 14 ProMark2 User’s Guide...
Page 15: Chapter 1 Introduction
Introduction What is the ProMark2 Survey System? ProMark2 is a complete GPS system providing both navigation and precision surveying. The ProMark2 system, Figure 1.1, includes two or more ProMark2 GPS receivers, GPS antennas, and all ancillary components required to get you up and running and producing quality survey data in a minimum amount of time.
Page 16: Items Supplied With Promark2
The ProMark2 System operates in conjunction with Ashtech Solutions, Thales Navigation’s highly-automated GPS post-processing engine. Ashtech Solutions is a complete, easy-to-use software package which manages and processes raw GPS data, deriving precise positioning data and presenting the results in easily understood report formats.
Page 17: External Gps Antenna
External GPS Antenna The external GPS antenna, Figure 1.3, is required for surveying functions. While the built-in antenna is sufficient for navigation, a more sophisticated external antenna is required to obtain quality data for precision surveying. The external GPS antenna is the physical data collection point for the raw GPS satellite data.
Page 18: Vertical Antenna Extension
Vertical Antenna Extension The vertical antenna extension, Figure 1.5, provides clearance for the antenna cable when the antenna is mounted on a tripod. The length is 3 inches (0.0762 m). Figure 1.5 Vertical Antenna Extension Field Receiver Bracket The field receiver bracket, Figure 1.6, serves a number of functions. First, it provides the means for mounting the ProMark2 GPS receiver to the tripod.
Page 19: Hi (Height Of Instrument) Measurement Tape
HI (Height of Instrument) Measurement Tape The HI measurement tape, Figure 1.7, is used to measure height of the GPS antenna over the survey point. The end of the tape hooks onto the antenna. The tape is extended until the spike on the tape case is on the point.
Page 20: Office Receiver Bracket With Download Cable
Office Receiver Bracket with Download Cable The office receiver bracket with integrated download cable, Figure 1.9, is an interface device that connects the ProMark2 receiver to an office computer for downloading of stored GPS satellite data. When the ProMark2 is placed into the bracket, the download cable is automatically connected to the receiver via the contacts on the back of the receiver.
Page 21: Documentation
The Ashtech Solutions post-processing software, Figure 1.11, provides the tools required to download and process the GPS satellite data from each ProMark2 receiver to produce relative positions of all points surveyed. Ashtech Solutions is provided on a CD which also contains a user’s guide.
Page 22: Additional Items Required But Not Supplied
Additional Items Required but not Supplied In order to conduct your survey, you will need some of the additional equipment discussed below. This equipment is not supplied with the standard ProMark2 survey system. Tripod, Tribrach, and Tribrach Adapter For each ProMark2 receiver in your system, you will need a tripod, tribrach, and tribrach adapter, Figure 1.12, Figure 1.13, and Figure 1.14, to position the GPS antenna over the survey point.
Page 23: Figure 1.13 Tribrach And Tribrach Adapter
Antenna adapter 5/8 x 11 UNC thread Levelling bubble Lock for antenna adapter Tribrach adapter Tribrach Optical Levelling sight screw Figure 1.13 Tribrach and Tribrach Adapter Locking tab Figure 1.14 Tribrach Adapter Mounted to Tribrach Introduction...
Page 24: Fixed-Height Gps Tripod
Fixed-Height GPS Tripod An option to the tripod, tribrach, and tribrach adapter combination is the fixed-height GPS tripod, Figure 1.15. The fixed-height GPS tripod has the advantage of eliminating the possibility of measuring and/or recording an incorrect HI, since the height is fixed. HI blunders are one of the most common mistakes during data collection.
Page 25: Gps Range Pole
GPS Range Pole An option for mounting the ProMark2 when operating in kinematic mode is a range pole, Figure 1.16 Figure 1.16: GPS Range Pole Introduction...
Page 26: Specifications
Specifications Table 1.1 lists performance and physical specifications for the ProMark2 system. Table 1.1 Performance and Physical Specifications Parameter GPS survey mode supported Survey accuracy (RMS) - Static Survey accuracy (RMS) – Stop-and- Navigation accuracy (RMS) Survey point spacing - Static (vector length) Survey point spacing –...
Page 27 Table 1.1 Performance and Physical Specifications (continued) Parameter Battery life Internal (2 AA): Up to 8 hours with alkaline @ 20 °C Up to 13 hours with lithium @ 20 °C External + internal (8 AA): Up to 32 hours with alkaline @ 20 °C Up to 52 hours with lithium @ 20 °C See Battery Life on page 25 for details.
Page 28: Surveying With Promark2
Surveying with ProMark2 The ProMark2 system is designed to perform GPS surveys using static, stop-and-go, and kinematic modes of GPS data collection. The three modes run independently and the GPS receiver must be turned off to run in a different mode. In the static data collection mode, the GPS receiver systems simultaneously collect raw data from all available satellites while remaining stationary on their respective points.
Page 29: Navigating With Promark2
In the kinematic data collection mode, the GPS receiver systems simultaneously collect raw data from all available satellites while a receiver is moving. In most cases, one GPS receiver system is located on a known point serving as a base station collecting data at that location for the duration of the survey.
Page 30: Loading Maps From Mapsend Cd
Loading Maps from MapSend CD • Launch MapSend software. At the top of the main window, choose Regions and select New (you can also use the toolbar for this purpose). • Now you can select with the mouse an area that you want to upload to ProMark 2. When you select the area, a window, where you need to enter a name for the selected region, should appear.
Page 31: Figure 1.19: Promark2 Connection Error Message
• Choose Upload to GPS Unit and press Next (make sure that ProMark2 is connected to your PC and turned on). By default, MapSend tries to find a receiver on COM1. If you connected the ProMark2 receiver to any other port, there should be a window informing you that the receiver was not found.
Page 32: Figure 1.21: Establishing Communication With Promark2
or Autodetect), and if the serial cable is connected to the PC and not broken, and if the receiver is switched on, the following window should appear: Figure 1.21: Establishing Communication with ProMark2 • Press OK and you will see the following message: Figure 1.22: “GPS Detected”...
Page 33: Figure 1.23: Space Required On Promark2 To Upload A Region
• Press Next and the following window with information about total sizes of your maps and available space should appear: Figure 1.23: Space Required on ProMark2 to Upload a Region • Press Finish and you will see the progress bar of uploading: Figure 1.24: Region Upload Progress Bars •...
Page 34: Time In The Field
Time in the Field Stop-and-go Since the stop-and-go method requires an initialization, the occupation times are much shorter than the static method. Initialization on a known point can be accomplished in as little as 15 seconds with a 1 second recording interval. Initialization with the initializer bar is typically 5 minutes.
Page 35: Where To Find Information
FTP site: ftp://ftp.thalesnavigation.com/Reference Manuals/ProMark2 Technical Support Thales Navigation is committed to providing top technical support and service to our customers worldwide. You can contact Thales Navigation as follows. • The Front Line: Contact directly at 1-800-229-2400 or +1 408-615-3980 between 7AM-6PM PST for prompt, professional service.
Page 36 Promark2 User’s Guide...
Page 37: Chapter 2 Getting Started
Getting Started Overview This chapter discusses the basic features and operation of ProMark2. This is followed by a quick tour of the survey interface to show how ProMark2 can be used to collect survey data with accompanying point attribute data. Control Buttons Figure 2.1 shows the control buttons used for survey functions.
Page 38: Table 2.1 Control Buttons Used For Survey Functions
Table 2.1 Control Buttons used for Survey Functions Button ENTER The ENTER button is used to either execute the highlighted function, edit the highlighted parameter, or enter the highlighted value. To illustrate, refer to Figure 4.5 on page 110, which shows the Survey Menu screen. The Point Attribute function has been highlighted by using the up/down arrows.
Page 39: Battery Life
Battery Life The ProMark2 receiver is conveniently powered by 2 standard AA batteries. Any battery type in the AA form factor can be used in the ProMark2 receiver, including both disposables (alkaline, lithium) and Rayovac® IC3 rechargeables. Other rechargeables are not recommended.
Page 40: Figure 2.3 Low Battery Alarm
As is evident from the graph of the alkaline batteries, temperature plays a large part in the operational life. This is true for all battery types with the exception of lithiums. The lithium experiences little effect on operational life due to temperature, making lithium the best choice for low-temperature operation.
Page 41: Figure 2.4 Extreme Low Power Alarm
The final battery alarm is the Extreme Low Power alarm, Figure 2.4. When this alarm appears, the active survey data file is closed and the receiver is shut down after 10 seconds. The current batteries will need to be replaced in order to continue with the survey Figure 2.4 Extreme Low Power Alarm Getting Started...
Page 42: Installing Batteries
Installing Batteries To install batteries, remove the battery compartment cover as shown in Figure 2.5. Remove old batteries, if any, and install new batteries, observing polarity as indicated. Replace cover and tighten retaining screw. Turn screw counter- clockwise to remove battery compartment cover Removing cover Memory Management...
Page 43: Initialization For First-Time Use
Delete data from receiver after processing. Keep the data files in the receiver until after you have completed the processing. If a data file were corrupted during download, this procedure will provide you with the opportunity to download the file once again. Beware of large detailed street-level map files.
Page 44: Downloading Collected Data To Office Computer
Downloading Collected Data to Office Computer After you have collected data in the field, you must download the data to an office computer and process the data using the Ashtech Solutions software. Use the following procedure to download the receiver data. Insert the ProMark2 receiver into the office bracket, Figure 2.6, making sure that the ProMark2 is securely retained by the hook on the bracket.
Page 45: Chapter 3 Surveying With The Promark2 System
Surveying with the ProMark2 System This chapter presents step-by-step procedures for performing a GPS survey with the ProMark2 system. Review this chapter thoroughly before attempting to perform your first survey. As an exercise, take your system outside of your office and perform a sample survey following the procedures outlined below.
Page 46: Figure 3.1 Three-Point Control Survey Example
Figure 3.1 Three-point Control Survey Example If you were to perform this survey with a conventional total station, you would probably plan on running a closed-loop traverse from the existing control point through the two new points, Figure 3.2. The same philosophy can be used for GPS surveys. Figure 3.2 is your network design for this survey.
Page 47: Figure 3.3 15-Point Control Survey Example
horizontal and 3 existing vertical control points. Figure 3.3 15-Point Control Survey Example Again, if you were to perform this survey with a conventional total station, you would design a traverse plan which produced a strong looking network of closed-loop traverses through the points of the survey.
Page 48: Observation Plan
Although the network design in Figure 3.4 was produced with conventional traversing in mind, this same design can also be used if performing the survey with GPS equipment. When designing your network, keep the following principles in mind: • Design loops through the network points which resemble a square or circle. Avoid loops that are long and skinny.
Page 49: Figure 3.6 Network Design For 3-Point Control Survey
our 3-point control survey network design, shown again in Figure 3.6. Figure 3.6 Network Design for 3-Point Control Survey Assume that a 2-receiver ProMark2 system will be used to perform the survey in Figure 3.6. To produce the link between the existing control point 1 and the new point 2, simply place one ProMark2 receiver system on point 1, place the other receiver on point 2 and simultaneously collect data between the two points.
Page 50: Figure 3.7 Network Design For 15-Point Control Survey
Figure 3.7 Network Design for 15-Point Control Survey To execute this network design, you must perform a direct GPS observation between all points directly linked. Each link can be viewed as a required GPS vector. Counting the links in this network design, you will find that 19 GPS vectors are required to execute this design.
Page 51: Figure 3.8 Receiver Observation Plan For 15-Point Control Survey
Figure 3.8 Receiver Observation Plan for 15-Point Control Survey The observation plan shows that it will take 10 separate observation sessions to complete the survey based on the network design in Figure 3.7. Notice that all observation sessions, except for session 6, produce 2 vectors required from the network design. Observation 6 produces only one since there were an odd number of required vectors (19).
Page 52 location for the given time. Pay particular attention to satellite availability (number of satellites in view) and the satellite distribution. To assist in analyzing the quality of satellite distribution, Dilution of Precision (DOP) values are presented. DOP is a quality analysis value for satellite distribution.
Page 53: Performing A Static Survey With The Promark2
Performing a Static Survey with the ProMark2 The procedures for performing a static survey with the ProMark2 system can be broken down into four primary categories: equipment check , site selection , system setup , and data collection . Following the steps presented below should result in successful execution of your GPS survey.
Page 54 signals transmitted by satellites approximately 21,000 km from earth. Being of relatively high frequency and low power, these signals are not very effective at penetrating through objects that may obstruct the line-of-sight between the satellites and the GPS receiver. Virtually any object that lies in the path between the GPS receiver and the satellites will be detrimental to the operation of the system.
Page 55: System Setup
System Setup Now that the survey site is identified, it is time to set up the ProMark2 receiver system over the point to be surveyed. The setup procedure is illustrated below. Set up tripod / tribrach combination over the survey point. This is done in precisely the same manner as for a conventional total station.
Page 56: Figure 3.10 Gps Antenna Mounted On Tripod Using Tribrach And Extender
Figure 3.10 GPS Antenna Mounted on Tripod using Tribrach and Extender Place the ProMark2 receiver into the field bracket. With the field bracket in hand, place the base of the ProMark2 receiver into the cradle and then tilt the receiver into place, as seen in Figure 3.11. Retaining hook Figure 3.11 Mounting ProMark2 into Field Bracket Cradle Attach the field bracket / ProMark2 combination onto the tripod...
Page 57: Figure 3.12 Field Bracket On Tripod
comfortable height for operation of receiver, as shown in Figure 3.12. Figure 3.12 Field Bracket on Tripod Connect GPS antenna cable. At the GPS antenna, screw in the antenna cable connector until the connection is tight. Connect the other end of the cable to the back of the ProMark2 receiver. This connection is made by simply pushing the connector into the back of the receiver.
Page 58: Figure 3.13 Antenna Cable Connection At The Antenna And Receiver
Figure 3.13 Antenna Cable Connection at the Antenna and Receiver Measure and record instrument height (HI) of GPS antenna The GPS antenna is the data collection point for GPS observations, i.e. the computed position for the point, horizontally and vertically, will be the location of the GPS antenna.
Page 59: Data Collection
Figure 3.14 Measuring HI (Height of Instrument) Data Collection With your ProMark2 receiver system set up over the point to be surveyed you are ready to begin data collection. This section provides you with the step-by-step process of using the user-interface of the ProMark2 to prepare the receiver to collect GPS data at this survey point.
Page 60: Figure 3.15 Mode Screen
receiver. The opening screen appears, followed by the Mode screen, Figure 3.15. Figure 3.15 Mode Screen Select Survey from the Mode screen. Do not use Navigate Mode for data collection. The accuracy of the downloaded waypoints is no better than 3-16 meters. With Survey highlighted, press Enter to bring up the Survey screen, Figure 3.16.
Page 61: Figure 3.17 Survey Menu
Data will begin the data collection process. Steps 3-11 below cover receiver and survey setup functions prior to the start of actual data storage. You will not need to access all of these functions each time you perform a survey, since some items, such as selection of units and receiver ID will remain the same for most surveys.
Page 62: Figure 3.18 Point Attribute Screen
The Point Attribute screen lets you enter attribute information for the survey point you are about to observe. The attribute information comprises the following parameters: • A 4-character site ID. You must assign a unique site ID to each point surveyed in your project.
Page 63: Figure 3.19 File Manager Screen
Figure 3.19 File Manager Screen The File Manager screen provides you with the ability to delete old data files to free up more memory for the current observation session. The screen includes a list of the data files currently in memory and the tools to delete these files. Each file has a symbol associated with it with the following meanings: >...
Page 64: Figure 3.20 Unit Of Measure Screen
Figure 3.20 Unit of Measure Screen The Unit of Measure screen lets you select the units of measure in which you wish to enter antenna height information. Also, the selected units determine the units of measure the Observation Timer utilizes. Press Enter to access the selection list of units.
Page 65: Figure 3.21 Receiver Id Screen
Figure 3.21 Receiver ID Screen The Receiver ID screen provides you with the ability to enter the 4-character receiver ID which is used in naming the raw data files. Each raw data file from this receiver will include this 4-character receiver ID. The receiver ID must be unique among all receivers used together in a survey.
Page 66: Figure 3.22 Contrast Screen
With Contrast highlighted, press Enter to bring up the Contrast screen, Figure 3.22. Figure 3.22 Contrast Screen The Contrast screen provides you with the ability to change the contrast of the receiver screen. Use the left/right arrows to adjust the contrast. Press the ENTER button when finished to return to the Survey Menu .
Page 67: Figure 3.23 Survey Screen
You have completed the setup process and are now ready to begin data collection. The remaining steps will present how to start the data collection process and how to monitor the progress of your survey. 12. From the Survey screen, select Collect Data . With Collect Data highlighted, press ENTER to bring up the Satellite Status screen, Figure 3.24.
Page 68: Figure 3.24 Satellite Status Screen
Figure 3.24 Satellite Status Screen The Satellite Status screen provides you the status of GPS satellite acquisition and tracking by the receiver. Upon entry to this screen, satellites available for tracking are displayed on the sky plot. Once a satellite is acquired, its number is displayed in reverse video (black box with white numbers) and a bar appears in the table below representing signal strength.
Page 69: Figure 3.25 Survey Status Screen
the Survey Status screen, Figure 3.25. Figure 3.25 Survey Status Screen The Survey Status screen provides information on the status of your survey during the data collection period. Information presented here will help you determine when enough data has been collected during this observation to ensure a quality position when the data is later processed.
Page 70 10 KM (6MI) - displays when there has been enough data collected to process a vector between this receiver and any other receiver simultaneously collecting data within 10 KM (6 MI) of this receiver. 15 KM (9MI) - displays when there has been enough data collected to process a vector between this receiver and any other receiver simultaneously collecting data within 15 KM (9 MI) of this receiver.
Page 71 pressing the Menu button. This is the same Survey Menu discussed earlier. All setup functions in the Survey Menu can be utilized at any time during the observation. In other words, steps 3-8 above can be performed after data collection begins, if desired.
Page 72: Kinematic Surveying With The Promark2 System
Kinematic Surveying with the ProMark2 System The kinematic data collection process requires at least two receivers collecting data simultaneously. One receiver is called the base and must remain stationary throughout the data collection. Typically, the base receiver will occupy a survey point for which the precise position is already known.
Page 73: Stop-And-Go Or Kinematic Base
after a loss of lock is critical to maintaining survey accuracy. Finally, kinematic surveys are most successful when the kinematic base receiver is close to the kinematic rover. Accuracies of GPS-derived positions are distance-dependent. The greater the distance between the GPS receivers, the larger the uncertainty. In an ideal case, the kinematic base should be on the same project site as the kinematic rover.
Page 74: Figure 3.26 Promark2 Antennae With Initializer Bar
initialization, be sure to incorporate the bar as part of your base setup as shown in Figure 3.26. Figure 3.26 ProMark2 Antennae with Initializer Bar Note: The base antenna is centered and levelled above the survey mark. The rover antenna is offset on the initializer bar.
Page 75: Kinematic Initialization
The rover antenna is transferred to the rover pole after initialization is completed, Figure 3.28. Figure 3.28 Rover Antenna from Initializer Bar to Range Pole Kinematic Initialization Overview A unique aspect of the kinematic mode of data collection is the requirement to initialize the survey.
Page 76: Bar Point Initialization
described below along with recommendations on when to use them. Bar Point Initialization Bar Point initialization is specific to ProMark2 and is performed using the supplied kinematic initializer bar. Bar Point initialization is the second quickest method of initializing a kinematic survey after initializing on a known point.
Page 77: Known Point Initialization
Known Point Initialization The quickest method to initialize a kinematic survey is Known Point initialization. In most situations, initialization on a known point can be accomplished in 10 seconds or less. It's very important to note that the relationship between the kinematic base point and the known point to be used to initialize must be very accurately established.
Page 78 point 0017, you get too close to the building causing the Kinematic SV Alarm to sound, indicating loss of initialization. You must re-initialize. You return to the initializer bar. If you were careful not to move (rotate) the bar, you can treat the bar point as a known point and perform a Known Point initialization.
Page 79: New Point Initialization
New Point Initialization The New Point method of kinematic initialization is the most time consuming method. It should be used only when other methods are not feasible. Observation times for initialization using the New Point method range from 15-30 minutes for a ProMark2 System. The observation time depends on the distance between the kinematic base and kinematic rover during initialization.
Page 80: Figure 3.29 Mode Screen
Figure 3.29 Mode Screen Select Survey from the Mode screen. With Survey highlighted, press Enter to bring up the Survey screen, Figure 3.30. Figure 3.30 Survey Screen The Survey screen provides the opportunity to perform receiver and survey setup functions prior to beginning survey data collection. If you select Setup , you will be presented with the Survey Menu from which parameters are set.
Page 81: Figure 3.31 Survey Menu
Steps 3-9 below cover receiver and survey setup functions prior to the start of actual data storage. You will not need to access all of these functions each time you perform a survey, since some items, such as selection of units and receiver ID will remain the same for most surveys.
Page 82: Figure 3.32 Point Attribute Screen
The Point Attribute screen lets you enter attribute information for the survey point you are about to observe. The attribute information comprises the following parameters: • A 4-character site ID. You must assign a unique site ID to each point surveyed in your project.
Page 83: Figure 3.33 Recording Interval Screen
Figure 3.33 Recording Interval Screen From the Survey Menu , select Antenna . Set the antenna height parameters for this point. Select Slant if you are measuring the antenna height to the outside edge of the GPS antenna, or Vertical if you are measuring the antenna height to the bottom of the GPS antenna.
Page 84: Figure 3.34 File Manager Screen
The File Manager screen provides you with the ability to delete old data files to free up more memory for the current observation session. The screen includes a list of the data files currently in memory and the tools to delete these files. Each file has a symbol associated with it with the following meanings: >...
Page 85: Figure 3.35 Unit Of Measure Screen
Figure 3.35 Unit of Measure Screen The Unit of Measure screen lets you select the units of measure in which you wish to enter antenna height information. Also, the selected units determine the units of measure the Observation Timer utilizes. Press Enter to access the selection list of units.
Page 86: Figure 3.36 Receiver Id Screen
Figure 3.36 Receiver ID Screen The Receiver ID screen provides you with the ability to enter the 4-character receiver ID which is used in naming the raw data files. Each raw data file from this receiver will include this 4-character receiver ID. The receiver ID must be unique among all receivers used together in a survey.
Page 87: Figure 3.37 Contrast Screen
Figure 3.37 Contrast Screen The Contrast screen provides you with the ability to change the contrast of the receiver screen. Use the left/right arrows to adjust the contrast. Press the ENTER button when finished to return to the Survey Menu . 12.
Page 88: Figure 3.38 Survey Screen
You have completed the setup process and are now ready to begin data collection. The remaining steps will present how to start the data collection process and how to monitor the progress of your survey. 13. From the Survey screen, select Collect Data . With Collect Data highlighted, press ENTER to bring up the Satellite Status screen, Figure 3.39.
Page 89: Figure 3.39 Satellite Status Screen
Figure 3.39 Satellite Status Screen The Satellite Status screen provides you the status of GPS satellite acquisition and tracking by the receiver. Upon entry to this screen, satellites available for tracking are displayed on the sky plot. Once a satellite is acquired, its number is displayed in reverse video (black box with white numbers) and a bar appears in the table below representing signal strength.
Page 90: Figure 3.40 Survey Status Screen
the Survey Status screen, Figure 3.40. The Survey Status screen provides information on the status of your survey during the data collection period. Information presented here will help you determine when enough data has been collected during this observation to ensure a quality position when the data is later processed.
Page 91 10 KM (6MI) - displays when there has been enough data collected to process a vector between this receiver and any other receiver simultaneously collecting data within 10 KM (6 MI) of this receiver. 15 KM (9MI) - displays when there has been enough data collected to process a vector between this receiver and any other receiver simultaneously collecting data within 15 KM (9 MI) of this receiver.
Page 92 The Survey Menu is accessible any time during the data collection process by pressing the Menu button. This is the same Survey Menu discussed earlier. All setup functions in the Survey Menu can be utilized at any time during the observation.
Page 93: Stop-And-Go Rover
Stop-and-go Rover There are two rover modes available— Stop-and-go and Kinematic . The mode must be selected prior to starting the survey. The following steps refer to the setup for stop-and-go operation. Turn on the ProMark2 receiver by pressing the red on/off button on the face of the receiver.
Page 94: Figure 3.42 Survey Screen
With Survey highlighted, press Enter to bring up the Survey screen, Figure 3.42. The Survey screen provides the opportunity to perform receiver and survey setup functions prior to beginning survey data collection. If you select Setup , you will be presented with the Survey Menu from which parameters are set.
Page 95: Figure 3.43 Survey Menu
From the Survey Menu , select Survey Mode . Set the mode to Stop-and-Go . From the Survey Menu , select Point Attribute . Enter attribute information for the point you are about to survey. With Point Attribute highlighted, press Enter to bring up the Point Attribute screen, Figure 3.44.
Page 96: Figure 3.45 Init Mode Screen
The Point Attribute screen lets you enter attribute information for the survey point you are about to observe. The attribute information comprises the following parameters: • A 4-character site ID. You must assign a site ID to each point surveyed in your project.
Page 97: Figure 3.46 Point Attribute Screen
3.46). Note the Time on Site has been set to the default 300 seconds (5 minutes). Figure 3.46 Point Attribute Screen To enter additional point attribute information such as a site description, highlight the field to be changed, and press the ENTER button. Change the values to those desired.
Page 98: Figure 3.47 Recording Interval Screen
Figure 3.47 Recording Interval Screen From the Survey Menu , select Antenna . Set the antenna height parameters for this point. Select Slant if you are measuring the antenna height to the outside edge of the GPS antenna, or Vertical if you are measuring the antenna height to the bottom of the GPS antenna.
Page 99: Figure 3.48 File Manager Screen
Figure 3.48 File Manager Screen The File Manager screen provides you with the ability to delete old data files to free up more memory for the current observation session. The screen includes a list of the data files currently in memory and the tools to delete these files. Each file has a symbol associated with it with the following meanings: >...
Page 100: Figure 3.49 Unit Of Measure Screen
Figure 3.49 Unit of Measure Screen The Unit of Measure screen lets you select the units of measure in which you wish to enter antenna height information. Also, the selected units determine the units of measure the Observation Timer utilizes. Press Enter to access the selection list of units.
Page 101: Figure 3.50 Receiver Id Screen
Figure 3.50 Receiver ID Screen The Receiver ID screen provides you with the ability to enter the 4-character receiver ID which is used in naming the raw data files. Each raw data file from this receiver will include this 4-character receiver ID. The receiver ID must be unique among all receivers used together in a survey.
Page 102: Figure 3.51 Contrast Screen
With Contrast highlighted, press Enter to bring up the Contrast screen, Figure 3.22. Figure 3.51 Contrast Screen The Contrast screen provides you with the ability to change the contrast of the receiver screen. Use the left/right arrows to adjust the contrast. Press the ENTER button when finished to return to the Survey Menu .
Page 103: Figure 3.52 Survey Screen
Figure 3.52 Survey Screen You have completed the setup process and are now ready to begin data collection. The remaining steps will present how to start the data collection process and how to monitor the progress of your survey. 13. From the Survey screen, select Collect Data . With Collect Data highlighted, press ENTER to bring up the Satellite Status screen, Figure 3.53.
Page 104: Figure 3.53 Satellite Status Screen
The Satellite Status screen provides you the status of GPS satellite acquisition and tracking by the receiver. Upon entry to this screen, satellites available for tracking are displayed on the sky plot. Once a satellite is acquired, its number is displayed in reverse video (black box with white numbers) and a bar appears in the table below representing signal strength.
Page 105: Survey Status Screen
14. From the Satellite Status screen, press the Nav/Surv button. While displaying the Satellite Status screen, press the Nav/Surv button to bring up the Survey Status screen, Figure 3.54. Figure 3.54 Survey Status Stop-and-go Screen Survey Status Screen The Survey Status screen provides information on the status of the survey during the data collection period.
Page 106: Kinematic Alarm
15. Start is highlighted and the receiver is ready to log point attribute information. Press the Enter button to start point attribute data collection. The Remain field will begin to count down. When the Remain field reaches 00:00:00, Stop is highlighted, point attribute data collection is stopped, and the site ID is automatically incremented.
Page 107: Kinematic Rover
Kinematic Rover There are two rover modes available— Stop-and-go and Kinematic . The mode must be selected prior to starting the survey. The following steps refer to the setup for the kinematic rover mode of operation. Turn on the ProMark2 receiver by pressing the red on/off button on the face of the receiver.
Page 108: Figure 3.56 Survey Screen
Figure 3.56 Survey Screen The Survey screen provides the opportunity to perform receiver and survey setup functions prior to beginning survey data collection. If you select Setup , you will be presented with the Survey Menu from which parameters are set. Selecting Collect Data will begin the data collection process.
Page 109: Figure 3.57 Survey Menu
The Survey Menu provides you access to receiver and survey setup functions. You may wish to exercise some of these functions prior to beginning data collection. From the Survey Menu , select Survey Mode . Set the mode to Kinematic . From the Survey Menu , select Point Attribute .
Page 110: Figure 3.58 Point Attribute Screen
The Point Attribute screen lets you enter attribute information for the survey point you are about to observe. The attribute information comprises the following parameters: • A 4-character site ID. You must assign a site ID to each point surveyed in your project.
Page 111: Figure 3.59 Init Mode Screen
Figure 3.59 Init Mode Screen Highlight Bar and select Save . The Point Attribute screen (Figure 3.60) will be shown. Note the Time on Site has been set to the default 300 seconds (5 minutes). Figure 3.60 Point Attribute Screen To enter additional point attribute information such as a site description, highlight the field to be changed, and press the ENTER button.
Page 112: Figure 3.61 Recording Interval Screen
Refer to the description of the Point Attribute- Kinematic screen, page 116, for further details regarding this screen. Note: The Point Attribute – Kinematic screen allows you to set the Time on Site field when the Initialize field is set to Bar or Known Point . Otherwise the Time on Site field is not available.
Page 113: Figure 3.62 File Manager Screen
Figure 3.62. Figure 3.62 File Manager Screen The File Manager screen provides you with the ability to delete old data files to free up more memory for the current observation session. The screen includes a list of the data files currently in memory and the tools to delete these files. Each file has a symbol associated with it with the following meanings: >...
Page 114: Figure 3.63 Unit Of Measure Screen
Figure 3.63. Figure 3.63 Unit of Measure Screen The Unit of Measure screen lets you select the units of measure in which you wish to enter antenna height information. Also, the selected units determine the units of measure the Observation Timer utilizes. Press Enter to access the selection list of units.
Page 115: Figure 3.64 Receiver Id Screen
Figure 3.64 Receiver ID Screen The Receiver ID screen provides you with the ability to enter the 4-character receiver ID which is used in naming the raw data files. Each raw data file from this receiver will include this 4-character receiver ID. The receiver ID must be unique among all receivers used together in a survey.
Page 116: Figure 3.65 Contrast Screen
Figure 3.65 Contrast Screen The Contrast screen provides you with the ability to change the contrast of the receiver screen. Use the left/right arrows to adjust the contrast. Press the ENTER button when finished to return to the Survey Menu . 12.
Page 117: Figure 3.66 Survey Screen
Figure 3.66 Survey Screen You have completed the setup process and are now ready to begin data collection. The remaining steps will present how to start the data collection process and how to monitor the progress of your survey. 13. From the Survey screen, select Collect Data . With Collect Data highlighted, press ENTER to bring up the Satellite Status screen, Figure 3.67.
Page 118: Figure 3.67 Satellite Status Screen
Figure 3.67 Satellite Status Screen The Satellite Status screen provides you the status of GPS satellite acquisition and tracking by the receiver. Upon entry to this screen, satellites available for tracking are displayed on the sky plot. Once a satellite is acquired, its number is displayed in reverse video (black box with white numbers) and a bar appears in the table below representing signal strength.
Page 119: Figure 3.68 Survey Status - Kinematic Screen
the Survey Status screen, Figure 3.68. Figure 3.68 Survey Status – Kinematic Screen The Survey Status screen provides information on the status of our survey during the data collection period. From this screen, monitor the following observation quality indicators: • Elapsed - The Elapsed field displays the amount of time passed since the data collection session started.
Page 120 Note: The Elapsed field is replaced by the Remain field during a point initialization. The Remain field will begin to count down. When the Remain field reaches 00:00:00, Stop is highlighted, data collection is stopped, and the site ID is automatically incremented. Transfer the antenna from the initializer bar to the range pole.
Page 121: Chapter 4 Detailed Screen Descriptions
Detailed Screen Descriptions This chapter presents detailed descriptions of the various screens that appear as you use the ProMark2 in the survey mode. The screen descriptions assume user familiarity with the front panel control buttons as described in Control Buttons beginning on page 23. Figure 4.1 is a map showing the screen hierarchy.
Page 122: Mode Screen
Mode Screen The opening screen, Figure 4.2, appears for a few seconds when you turn on the ProMark2. This is followed by the Mode screen, Figure 4.3. If, while still in the opening screen, the Enter key is pressed, this will take you immediately to the Mode screen, Figure 4.6. The Mode screen lets you select navigation mode or survey mode.
Page 123: Survey Screen
Survey Screen The Survey screen, Figure 4.4, provides the option to begin data collection or to access the survey menu in order to set up receiver and data collection parameters without going into data collection mode. The ability to access the survey menu from this point is useful when you wish to set up the receiver or manage receiver data files while not collecting data, i.e.
Page 124: Survey Menu Screen
Survey Menu Screen The Survey Menu screen, Figure 4.5, gives you control over receiver operational parameters, survey data collection parameters, and receiver raw data files. All functions found in the Survey Menu can be utilized at any time before or during survey data collection. The Survey Menu is accessed by either selecting Setup from the Survey screen, or by pressing the Menu button from the Survey Status screen or the Satellite Status screen.
Page 125: Survey Mode Screen
Survey Mode Screen The Survey Mode screen, Figure 4.6, lets you set the type of survey you wish to perform. Table 4.3 describes the screen parameters. Table 4.3 Survey Mode Screen Parameters Parameter Survey Mode Lets you set the survey mode. Static, Stop-and-Go, and Kinematic are the available options.
Page 126: Point Attribute - Static Screen
Point Attribute - Static Screen The Point Attribute screen lets you enter and store attribute information of the point at which data is being or will be collected. The entered attribute information is stored along with the raw survey data and downloaded for use during data processing. The Point Attribute screen is accessed by selecting Point Attribute in the Survey Menu .
Page 127 Table 4.4 Point Attribute - Static Screen Parameters (continued) Parameter Description Note: After a power cycle, all parameters set will be saved with the exception of the site ID, which will display the default value “????”. Note: Site description information is shared by the three different modes of operation. So site description entries added, edited, or deleted in static, stop-and-go, or kinematic mode will be reflected when in the other modes.
Page 128: Point Attribute - Stop-And-Go Screen
Point Attribute - Stop-and-go Screen The Point Attribute Stop-and-go screen, Figure 4.8, lets you enter and store point attribute information when in stop-and-go mode. Table 4.5 describes the screen parameters. Figure 4.8 Table 4.5 Point Attribute - Stop-and-go Parameters Parameter Site ID Lets you enter a 4-character alphanumeric site ID.
Page 129: Screen Descriptions
Table 4.5 Point Attribute - Stop-and-go Parameters (continued) Parameter Control Lets you set the point as a control point for future use as a known point initialization point. Set to Yes and the point occupied becomes available as a known initialization point and is included in the site id table.
Page 130: Point Attribute - Kinematic Screen
Point Attribute - Kinematic Screen The Point Attribute - Kinematic screen, Figure 4.9, lets you set and save point attribute information when kinematic mode is selected. Table 4.6 describes the screen parameters. Figure 4.9 Point Attribute - Kinematic Screen Table 4.6 Point Attribute - Kinematic Screen Parameters Parameter Site ID Lets you enter a 4-character alphanumeric site ID.
Page 131: Site Id Screen
Site ID Screen The Site ID screen, Figure 4.10, is available in stop-and-go and kinematic modes when Known Point has been selected in the Initialize field. To access the site ID screen, select Known Point in the Initialize field, then highlight the Site ID field and press Enter . The Site ID screen lets you select a known site ID with its associated site description during a known point initialization.
Page 132: Site Description Screen
Site Description Screen The Site Description screen, Figure 4.11, can be accessed from the Point Attribute screen when the Site Description field is highlighted and the Enter key is pressed. The Site Description screen lets you select a descriptor from the descriptor list, enter a new descriptor, edit an existing descriptor, and delete a descriptor.
Page 133: Init Mode Screen
Init Mode Screen The Init Mode screen, Figure 4.12, is accessed from the Point Attribute screen when the Initialize field is highlighted and the Enter key is pressed. The Init Mode screen lets you select a type of point initialization. The options include <None>...
Page 134: Recording Interval Screen
Recording Interval Screen The Recording Interval screen, Figure 4.13, lets you set the receiver record interval in seconds. Table 4.10 describes the recording interval screen parameters. Figure 4.13 Recording Interval Screen Table 4.10 Recording Interval Screen Parameters Parameter Seconds Calls the Recording Interval List screen, page 121. The range is 1 to 120 seconds.
Page 135: Recording Interval List Screen
Recording Interval List Screen The Recording Interval List screen, Figure 4.14, is accessed when the Interval field in the Recording Interval screen is highlighted and the Enter key is pressed. The Recording Interval screen lets you select the receiver recording interval in seconds. Table 4.11 describes the screen parameters.
Page 136: Antenna Screen
Antenna Screen The Antenna screen, Figure 4.15, lets you set the GPS antenna parameters of the point at which data is being or will be collected. Table 4.12 describes the screen parameters. Table 4.12 Antenna Screen Parameters Parameter Height Type Lets you select antenna height type: Slant or Vertical.
Page 137: File Manager Screen
File Manager Screen The File Manager screen, Figure 4.16, lets you examine details of each data file stored in the receiver and delete data files that are no longer needed. Each data file is tagged with an identifier indicating if the file has been downloaded; this is very useful when deciding which files to delete when additional memory is required.
Page 138: Figure 4.17 File Naming Convention For Survey Data Files
Table 4.13 File Manager Screen Parameters (continued) Parameter Returns screen to Survey Menu. Lower pane of display Information on highlighted file indicating name and size. Also displays amount of free memory available for data storage. R 1234 A 01.344 Figure 4.17 File Naming Convention for Survey Data Files Note: The session ID increments A-Z, which provides up to 26 unique session IDs for any given day number.
Page 139: Unit Of Measure Screen
Unit of Measure Screen The Unit of Measure screen, Figure 4.18, lets you select the preferred unit of measure in which the antenna height values are to be entered in the Point Attribute screen. The selection also defines the unit of measure used to display thresholds in the Observation Timer parameter found on the Survey Status screen.
Page 140: Receiver Id Screen
Receiver ID Screen The Receiver ID screen, Figure 4.19, lets you set the identifier of the receiver to be used in the raw survey data file name. Each raw survey data file downloaded from this receiver will include this identifier in the name. Be sure to use a unique identifier for each receiver used in a survey, i.e.
Page 141: Contrast Screen
Contrast Screen The Contrast screen, Figure 4.20, is accessed from the Survey menu, page 110. The Contrast screen lets you adjust the screen contrast using the left and right arrows. Press the ENTER key to exit the screen. Figure 4.20 Contrast Screen Screen Descriptions...
Page 142: Survey Status - Static Screen
Survey Status - Static Screen The Survey Status - Static screen, Figure 4.21, provides important status information regarding receiver operation and the current data collection session. All important information about the survey can be viewed from this screen. Depend on the Survey Status screen to determine when enough data has been collected to end the survey, guide you on the quality of the data being collected, and provide you with receiver operational status information such as battery life and remaining memory.
Page 143 Table 4.16 Survey Status - Static Selections (continued) Selection Obs. Timer The Obs. Timer field displays the current state of the observation timer. The possible displayed values are: 0 KM (0 MI) - displays when there has not been enough data collected to accurately process a vector between this receiver and others simultaneously collecting data.
Page 144: Survey Status - Stop-And-Go Screen
Survey Status - Stop-and-go Screen The Survey Status – Stop-and-go screen, Figure 4.22, provides important status information regarding receiver operation and the current data collection session. All important information about the survey can be viewed from this screen. Depend on the Survey Status screen to determine if data is being logged, to start point attribute data logging, to verify the time remaining for the point attribute data collection session, guide you on the quality of the data being collected, and provide you with receiver operational status information such as battery...
Page 145 Table 4.17 Survey Status - Stop-and-go Screen Parameters (continued) Parameter Start The START button lets you begin point attribute data logging. When shown in reverse video (white lettering/black background) the receiver is not storing point attribute information. Press the ENTER button to start point attribute data logging. Stop The STOP button lets you stop the point attribute data logging before the time remaining reaches 00:00:00.
Page 146: Survey Status - Kinematic Screen
Survey Status – Kinematic Screen The Survey Status – Kinematic screen, Figure 4.23, provides important status information regarding receiver operation and the current data collection session. All important information about the survey can be viewed from this screen. Depend on the Survey Status screen to determine if data is being logged, to start point attribute logging, to determine how much time has elapsed since the point attribute logging was started, guide you on the quality of the data being collected, and provide you with receiver operational status information such as battery...
Page 147 Table 4.18 Survey Status - Kinematic Screen Parameters (continued) Parameter PDOP The PDOP field displays the PDOP value at any given time, computed from all logged healthy satellites above 10 degrees elevation. Start The start button lets you begin the data session. When shown in reverse video (white lettering/black background) the receiver is not storing data.
Page 148: Satellite Status Screen
Satellite Status Screen The Satellite Status screen, Figure 4.24, provides a visual display of the GPS satellites which are currently available (i.e., above the horizon), satellites that are being tracked by the receiver, and the signal strength of the tracked satellites. Additionally, this screen displays current power status and memory status.
Page 149 Table 4.19 Satellite Status Screen Parameters Parameter Description Memory status indicator The memory status indicator (box with percent sign in lower right corner of display) provides a graphical and numerical indication of the percentage of memory available for storing data. The numerical value blinks once every recording interval when data is being stored to memory.
Page 150: Edit Screens
Edit Screens Three screens appear at appropriate times to allow you to enter or change parameters. These screens derive from the site ID, site descriptor, and receiver ID variables, as shown in Figure 4.25. Figure 4.25 Edit Screens - Site ID, Site Descriptor, Receiver ID. To change a parameter, use the arrow keys to navigate around the keyboard.
Page 151: Alarm Screens
Alarm Screens Any of five alarm screens may appear under certain conditions: no external antenna connected, low battery , extreme low power , low data memory, and kinematic . These alarms are discussed in the following paragraphs. No External Antenna The ProMark2 will not allow you to collect survey data without the external antenna.
Page 152: Extreme Low Power
again unless you turn off the receiver and turn it back on. Figure 4.27 Low Battery Alarm Extreme Low Power The Extreme Low Power alarm, Figure 4.28, appears when the receiver feels it can no longer guarantee continued, uninterrupted operation. At the appearance of this alarm, the receiver closes the active survey data file and shuts down after 10 seconds.
Page 153: Figure 4.29 Low Memory Alarm
Low Memory The Low Memory alarm, Figure 4.29, appears when remaining memory for survey data storage is 5% or less. If you close the Low Memory alarm screen by pressing the ENTER key, the alarm will not appear again unless you turn off the receiver and turn it back on. Figure 4.29 Low Memory Alarm Screen Descriptions...
Page 154: Figure 4.30 Kinematic Alarm
Kinematic Alarm The Kinematic Alarm screen, Figure 4.30, appears when insufficient satellite measurements are available to maintain kinematic initialization. When the alarm is active, the # Sats field in Survey Status continues to display the number of tracked satellites independent of data quality. To maintain centimeter-level accuracy, you must reinitialize after the alarm appears.
Page 155: Figure 4.31 Power Down Screen
Power Down Screen The Power Down screen, Figure 4.31, appears when the Power button is pressed momentarily during operation. When this screen appears, the ProMark2 will turn itself off in 5 seconds, or you can abort the power down by pressing the Esc key. Figure 4.31 Power Down Screen...
