Page 1: User Guide
September 2008 701P49052 8264E Color Wide Format Printer 100kg Unwinder / Winder User Guide... -
Page 3: Table Of Contents
Safety and Warning Label Information... 1 Safety Considerations ... 1 Warning Labels ... 1 1.2.1 Warning Label Locations and Types ... 2 Operating Instructions Labels ... 3 1.3.1 Instruction Label Locations and Types ... 3 Unwinder / Winder Operation... 5 Location of Major Components ... - Page 4 This page has been intentionally left blank. 100kg Unwinder / Winder User Guide...
-
Page 5: Safety And Warning Label Information
Do not use organic solvents or gasoline to clean the labels. Warning labels must be replaced if damaged, lost, or cannot be read. Contact your local Xerox Representative if an warning label needs to be replaced. 100kg Unwinder / Winder User Guide... -
Page 6: Warning Label Locations And Types
1 Safety and Warning Label Information 1.2.1 Warning Label Locations and Types The figures below indicate the locations of the warning labels. Figure 1. Front Warning Label Locations Figure 2. Rear Warning Label Locations Types of warning label 100kg Unwinder / Winder User Guide... -
Page 7: Operating Instructions Labels
Do not use organic solvents or gasoline to clean the labels. Operating instructions labels must be replaced if damaged, lost, or cannot be read. Contact your local Xerox Representative if an warning label needs to be replaced. 1.3.1 Instruction Label Locations and Types The figures below indicate the locations of the operating instruction labels. - Page 8 1 Safety and Warning Label Information This page has been intentionally left blank. 100kg Unwinder / Winder User Guide...
-
Page 9: Unwinder / Winder Operation
2.1 Location of Major Components This section will explain the names and functions of the major components of the Unwinder / Winder. 2.1.1 Unwinder Components Figure 4. Location of Major Components (Unwinder) Part name Unwinder Spindles Unwinder Tension Bar Roller Unwinder / Winder Power Switch 100kg Unwinder / Winder User Guide... -
Page 10: Winder Components
2 Unwinder / Winder Operation 2.1.2 Winder Components Figure 5. Location of Major Components (Winder) Part name Winder Spindles Winder Tension Bar Roller Media Core Unwinder / Winder Control Panel Function Rolls in the media after printing Used to guide the media after printing to the roll-in device. -
Page 11: Unwinder Control Panel
2.1.3 Unwinder Control Panel The Unwinder Control Panel is used to set the operating mode and to display the status of the Unwinder. 2.1.3.1 Switches / Button Part name Automatic Operation Switch Manual Operation Switch Initialize Button 2.1.3.2 Indicators Part name Power Lamp Error Lamp 100kg Unwinder / Winder User Guide... -
Page 12: Winder Control Panel
2 Unwinder / Winder Operation 2.1.4 Winder Control Panel The Winder Control Panel is used to set the operating mode and to display the status of the Winder. 2.1.4.1 Switches Part name Automatic Operation Switch Manual Operation Switch 2.1.4.2 Indicators Part name Power Lamp Error Lamp... -
Page 13: Connecting The Power Cable
2.2 Connecting the Power Cable This section describes the procedure for connecting the power cable. DO NOT use a damaged power cable. If the power cable is damaged, contact your local Xerox Customer Service Representative for a replacement. Use the following instructions to install the power cable. -
Page 14: Turning The Power On And Off
2 Unwinder / Winder Operation 2.3 Turning the Power ON and OFF The following section provides procedures for setting the Unwinder / Winder power ON and OFF. 2.3.1 Turning the Power ON Turn the power ON by following the instructions below. 1. -
Page 15: Loading Roll Media Onto The Unwinder
2.4 Loading Roll Media onto the Unwinder The following section describes how to load roll media on the Unwinder. Media core size 3 inch：Maximum media width 1625mm, Minimum media width 1000mm, media outside diameter less than 250mm, weight less than 100kg. Roll media must be loaded in the center of the of printer. - Page 16 2 Unwinder / Winder Operation 4. Place the roll media on top of the rear rail. 5. Set the roll media on the Left Unwinder Spindle and tighten the Left Unwinder Spindle Locking Handle. Figure 14. Install Roll Media Part name Rear Rail Roll Media Figure 15.
- Page 17 6. Set the roll media on the Right Unwinder Spindle and tighten the Right Spindle Locking Handle. 7. Loosen the Left and Right Unwinder Spindle Locking Handles and move the roll media to the center of the rail so that the media is aligned with the center of the printer. Tighten the Left and Right Unwinder Spindle Locking Handles.
- Page 18 2 Unwinder / Winder Operation 8. Set the Printer Power Switch to ON. After an short initialization period the Printer Control Panel will display “No Media”. 9. Raise the Media Set Lever. The Printer Control Panel will display “Please Set Media”. 10.
- Page 19 11. Set the Unwinder Automatic Operation Switch as described below: If the paper will be printed on the outside of the roll media: OUTSIDE ROLL ・ If the paper will be printed on the inside of the roll media: INSIDE ROLL ・...
- Page 20 2 Unwinder / Winder Operation 13. Insert the roll media into the tension roller, and then into the Rear Printer Platen. Media can be inserted either with the print surface on the outside (Figure 22) or with the print surface on the inside (Figure 23).
- Page 21 b. When using a roll paper where the print surface is on the inside. Damage and problems that occur because of the use of roll media where the print surface is on the inside are not covered by the warranty. 100kg Unwinder / Winder User Guide Figure 23.
- Page 22 2 Unwinder / Winder Operation 14. Pull about 1 meter of roll media out from the Front Printer Plate. 15. Set the Manual Operation Switch to “Reversal” to roll in the media slightly so that the paper has tension and is straight. ●...
- Page 23 16. Lower the Media Set Lever. 100kg Unwinder / Winder User Guide Figure 26. Install Roll Media Part name Roll Media Media Setting Guide Figure 27. Lower Media Set Lever Part name Media Set Lever 2 Unwinder / Winder Operation...
- Page 24 2 Unwinder / Winder Operation 17 Push the “INITIALIZE” button on the Unwinder Control Panel. Figure 28. Push INITIALIZE 18 Close the Printer Front Cover. Figure 29. Close the Printer Front Cover Part name Printer Front Cover 100kg Unwinder / Winder User Guide...
-
Page 25: Operating The Winder
2 Unwinder / Winder Operation 2.5 Operating the Winder This section provides instructions for using the Unwinder / Winder. 1. Set a media core on the Winder. Ensure that the size of the core is that same size as the media roll core. - Page 26 2 Unwinder / Winder Operation 4. Attached the tip of the roll media to the media core on the Winder Spindles. Ensure that the media parallel to the core. Secure the tip of the media to the core with tape. 5.
-
Page 27: Removing A Printed Media Core From The Winder
2 Unwinder / Winder Operation 2.6 Removing a Printed Media Core from the Winder This section will explain the procedure to remove the media core from the Winder. 1. Set the Winder Automatic Operation Switch to OFF. 2. If the media core being removed is partially filled with printed media, cut the media from the remaining media in the Printer Platen. - Page 28 2 Unwinder / Winder Operation This page has been intentionally left blank. 100kg Unwinder / Winder User Guide...
- Page 30 Printed in the United States of America. XEROX® and all XEROX product names mentioned in this publication are trademarks of XEROX CORPORATION. Other company trademarks are also acknowledged. PANTONE is a registered trademark of Pantone, Inc.
