Electronic Control

Maximize Ice Production Feature

These appliances are equipped with a feature that can boost ice production up to 40% above normal. By touching
the MAX ICE key on the control panel, the ice maker system is switched ON (if OFF); multiple ice cube icons appear
in the LCD (See Figure 2-9); the freezer set-point is automatically set to -5°F (-21°C) for twenty-four (24) hours, and
the freezer evaporator fan is switched to 100% run for twenty-four (24) hours, switching off only when the door is
opened.
After twenty-four (24) hours, the freezer set-point reverts to the last manually input set-point, the freezer evaporator
fan resumes its normal operation (cycling with the compressor); and two of the three ice cube icons disappear from
the LCD, indicating normal ice production has resumed.
NOTES:
• When the maximize ice production feature is active, power to the icemaker system is NOT interrupted after ice
harvest, so the icemaker will initiate a harvest as soon as the thermostat reaches 10°F (-12°C).
• Switching the unit OFF, then back ON with the POWER key, or touching the MAX ICE key during the twenty-four
(24) hour production period will switch the maximize ice production feature OFF.
• When in Sabbath Mode, the icemaker system is disabled. Sabbath Mode will be explained later.
LIGHTS ICE MAKER MAX ICE
Figure 2-9. Maximize Ice Production Feature ON or OFF - Touch MAX ICE Key,

Door Ajar Alarm Feature ON/OFF

All BI Series units are equipped with a door ajar alarm feature. To enable the door ajar alarm, touch the ALARM key
on the control panel and the bell icon will appear in the LCD indicating the alarm is enabled (See Figure 2-10). With
the alarm enabled, the bell icon will flash and an audible alarm will chime at two (2) second intervals whenever a
door is left open for more than sixty (60) seconds. To disable the door ajar alarm, touch the ALARM key again and
the bell icon disappears from the LCD.
LIGHTS ICE MAKER MAX ICE
Figure 2-10. Switching Door Ajar Alarm ON or OFF - Touch ALARM Key, Bell Appears when Activated
7040317 - Revision A - September, 2015
Built-In (BI) Series
Built-In (BI) Series
COLDER WARMER
Multiple Ice Cubes Appear when Activated
COLDER WARMER
Alarm Feature is ON
(SWS #4380000)
(SWS #4380000)
COLDER WARMER
Production
Maximize Ice
COLDER WARMER
2-8
PURE AIR ALARM POWER
Feature Activated
PURE AIR ALARM POWER
