Electronic Control

UNIQUE ELECTRONIC CONTROL INPUT OPERATIONS

The following pages illustrate unique customer input operations performed at the control panel. The input operations
described are: Temperature Unit Selection Mode, Contrast Adjust Mode, Tone Adjust Mode, Showroom Mode,
Sabbath Mode, Manual Zone Disable and Manual Freezer Evaporator Defrost.
Temperature Units Selection Mode (Selecting Degrees Fahrenheit or Degrees Celsius Display)
The appliance is initially set to display temperatures in Fahrenheit temperature units of measure, indicated by the "F"
at the upper right of the temperature readings in the LCD. This can be changed so Celsius units of measure are dis-
played by initiating Temperature Units Selection Mode.
NOTE: Temperature Units Selection Mode must be initiated within the first (1) minute after switching the unit ON.
To convert Fahrenheit (°F) temperature units of measure to Celsius (°C) within the first minute after switching the
unit ON, touch and hold the ALARM key and the POWER key simultaneously for five (5) seconds, then release the
keys (See Figure 2-13); a "c" will appear at the upper right of the temperature readings in the LCD, indicating that
temperatures will now be displayed in Celsius units of measure. Please note that changing from Celsius tempera-
ture units of measure to Fahrenheit is the same procedure (See Figure 2-14).
NOTES:
• Do not touch and hold the POWER key first, that will switch the unit OFF.
• Temperature Units Selection Mode will end ten (10) seconds after the last key stroke, or the ALARM key can be
touched to exit this mode before the ten (10) seconds has elapsed.
Indicates Celsius Units of Measure
LIGHTS ICE MAKER MAX ICE
Figure 2-13. Converting Temperature Units of Measure to °C (within first minute after switching unit ON) -
Fahrenheit
Indicates
LIGHTS ICE MAKER MAX ICE
Figure 2-14. Converting Temperature Units of Measure to °F (within first minute after switching unit ON) -
7040317 - Revision A - September, 2015
Built-In (BI) Series
Built-In (BI) Series
COLDER WARMER
Touch and Hold ALARM Key and POWER Key for 5 Seconds
Units of Measure
COLDER WARMER
Touch and Hold ALARM Key and POWER Key for 5 Seconds
(SWS #4380000)
(SWS #4380000)
COLDER WARMER
Touch and hold for 5 seconds
COLDER WARMER
Touch and hold for 5 seconds
2-10
PURE AIR ALARM POWER
PURE AIR ALARM POWER
