FAULT CODE TABLE WITH LCD CORRELATION DIAGRAM ( PAGE 2 of 2 )
LIGHTS ICE MAKER MAX ICE
10 Thermistor Faults
15 Relay Faults
20 Defrost Heater Faults
30 Ice/Water/Accessory Faults
35 Fan Faults
40 Runtime Faults
44 Glass Heater Faults
45 Lighting Faults
50 Flow Meter
60 Load/Component Faults
90 Control Faults
95 Diagnostics
98 Power Faults
NOTE: These Columns are repeated from last page
NOTE: There are three fault codes not covered in this table, they are "LO C", "H2 LO" and "dO Or". These are
explained under the heading of "Possible Instruction and Error/Fault Indicators" earlier in this section
(SWS #4380000)
(SWS #4380000)
COLDER WARMER
0 Misc
1 Refrigerator
2 Freezer
3 Condenser
4 Defrost System
5 Control System
6 Compressors
7 Ambient
8 Icemaker
9 Dispenser
A Air Purifier
d TC Drawer
F Freezer Evaporator
H High Voltage System
L Lighting
r Refrigerator Evaporator
U Water Systems
COLDER WARMER
50 Open Heater
55 Triac Open
56 Triac Short
60 No Load/Load Open
65 Stuck at Dispenser Water Valve Out
66 Stuck at Ice Water Valve Out
70 Bad Flash Write
71 Flash Initialized
72 Flash Memory Bad
73 Invalid Log Fault Checksum
74 Invalid E2 Checksum
75 Invalid Model E2 Checksum
80 No Communication
81 Communications Time-out
82 Partial Communications
83 Bad Micro Communication
84 Micro Initialization
85 Display Failure
86 Too Slow
87 No Flow
90 Framing Errors
92 Excessive Collisions
93 Data Overrun
95 FMEA Error
96 Calibration or Low Signal Error
97 Quantum SPI
98 Brownout
99 Other
