Safety - SMC Networks e-Rodless E-MY2 Series Operation Manual

SAFETY

The e-Rodless Actuator and this manual contain essential information for the protection of users
and others from possible injury and property damage and to ensure correct handling.
Please check that you fully understand the definition of the following messages (signs) before
going on to read the text, and always follow the instructions.
Please read the operation manuals of related apparatus and understand it before operating the
actuator.
IMPORTANT MESSAGES
Read this manual and follow its instructions. Signal words such as WARNING, CAUTION and
NOTE, will be followed by important safety information that must be carefully reviewed.
Indicates a potentially hazardous situation which could result in death
or serious injury if you do not follow instructions.
Indicates a potentially hazardous situation which if not avoided, may
result in minor injury or moderate injury.
Gives you helpful information.
Do not disassemble, remodel (including change of printed circuit board) or repair.
An injury or failure can result.
Do not perform operation and setting.
Electric shock may occur.
Do not operate beyond specification range.
Fire, malfunction or switch damage can result.
Please use it after confirming the specification.
2
Do not use the product in the environment with possible presence of flammable,
explosive or corrosive gas with the product to prevent fire, explosion or corrosion.
Note the actuator doesn't have explosion proof construction.
During operation, do not enter your hand into moving range nor touch moving parts.
It may cause injury.
Do not touch the side and lower part of motor and controller.
These parts become hot and should not be touched until it is confirmed they become cool enough.
The grounding should be performed separately at short length near controller if pos-
sible.
Be sure to ground the product to keep the capability of resistance for the noise in the actuator.
Ground with FG terminal.
Perform functional inspection after maintenance.
Stop operation when equipment or component doesn't work properly. Safety may not be guaran-
teed by unintended malfunction.
Ensure the safety in wiring for ALM signal by inputting emergency stop signal and causing succes-
sive error.
After the stroke is adjusted, turn on power supply and then perform stroke learning.
If the stroke leaning is not performed, the product may not operate along with the adjusted stroke
and damage the connected equipment.
Do not connect driving power supply and turn on it before the area where the work
(slider) is moved confirms safety.
The movement of the work may cause accident. And when power supply is turned on, the work is
returned to home position by input IN1 or IN2 signal. (Except that stroke learning is not performed
at all.)
3
