- Page 1 Doc. DOC1117660 PRODUCT NAME Compact Wireless Remote MODEL / Series / Product Number EXW1-RDY*M5C...
- Page 2 Contents Safety Instructions ···························································································· 2 Precautions for Handling ··················································································· 5 Important Instructions concerning the Wireless System ········································ 7 SMC Wireless System ························································································ 9 Features and Summary ··························································································································· 9 System Configuration ····························································································································· 10 How to Order ······································································································································· 11 Summary of Product parts ··············································································· 12 EXW1-RDY*M5C-* ································································································································...
-
Page 3: Safety Instructions
Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations. -
Page 4: Limited Warranty And Disclaimer/Compliance Requirements
Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act. - Page 5 Operator ♦This operation manual is intended for those who have knowledge of machinery using pneumatic equipment, and have sufficient knowledge of assembly, operation and maintenance of such equipment. Only those persons are allowed to perform assembly, operation and maintenance. ♦Read and understand this operation manual carefully before assembling, operating or providing maintenance to the product.
-
Page 6: Precautions For Handling
Precautions for Handling ○Follow the instructions given below for selecting and handling. ●The instructions on design and selection Product specifications •Use within the specified voltage. Otherwise, failure or malfunction can result. •Reserve a space for maintenance. Design the system to allow the required space for maintenance. •Do not remove the label. -
Page 7: Operating Environment
Operating environment •Select the correct type of enclosure according to the operating environment. IP67 protection class is achieved when the following conditions are met. (1) The units are connected correctly using power supply cables and communication cables with M12 (or M8) connectors. - Page 8 Maintenance •Turn off the power supply, stop the supplied air, exhaust the residual pressure and verify the release of air, before performing maintenance. Otherwise safety is not assured due to an unexpected malfunction or incorrect operation. •Perform regular maintenance and inspections. There is a risk of unexpected operation due to malfunction of the equipment.
- Page 9 Fieldbus System/ Industrial IoT Cybersecurity In recent years, factories have introduced industrial IoT, building up complex networks of production machines. These systems maybe subject to a new threat, cyberattack. To protect the industrial IoT from cyberattacks, it is important to take multiple measures (multi-layer protection) for IoT devices, networks and clouds.
-
Page 10: Related Documents
SMC Wireless System Features and Summary SMC Wireless Products are modular devices consisting of a gateway (hereafter referred to as a Base) and wireless devices (hereafter referred to as Remotes). From an upper-level (PLC) control component, a Base appears to be a single system including Remotes paired with it. -
Page 11: System Configuration
System Configuration PLC compatible with EXW1 series communication protocols. <Base> EXW1 series <Remote> EXW1 series Input/ output/ devices. -10- Doc. DOC1117660... -
Page 12: How To Order
How to Order The product system, model names and part numbering system of SMC wireless systems are as follows. <Compact wireless Remotes> This product line-up consists of 6 models, namely EXW1-RDYPM5C, EXW1-RDYNM5C, EXW1-RDYPM5C-E, EXW1-RDYNM5C-E, EXW1-RDYPM5C-N, and EXW1-RDYNM5C-N. 6 models are the wireless system remote used in combination with a wireless adaptor that has wireless communication capabilities. -
Page 13: Summary Of Product Parts
Summary of Product parts EXW1-RDY*M5C-* Name Application Performs wireless communication. (Factory installed if the wireless Wireless adaptor adaptor option is selected in the ”How to order”) Secures the wireless adaptor. (Factory installed if the wireless Wireless adaptor cover adaptor option is selected in the ”How to order”) M12 power connector (PWR) Supplies power to the compact wireless remote. -
Page 14: Led Indicator
LED indicator The LED indicates product status (the power supply, communication and diagnostic status), and outputs status. LED indicators of the compact Wireless Remote Refer to below for LED status of PWR, MS, W-SS, W-NS and PD. LED status Function Description ON/OFF/ name... - Page 15 Connectors •Power supply connector M12, 4-pin, plug Signal Description A code 24V (US1) 24VDC (US1): Input* 24V (US2) 24VDC (US2): Input 0V (US1) 0VDC (US1) 0V (US2) 0VDC (US2) *1: 24 VDC +/-10% •Connector for wireless adaptor Signal Description M8, 4-pin, socket 24V (US1) 24VDC (US1): Output Internal BUS B...
-
Page 16: Setting And Adjustment
Setting and Adjustment Flow chart for operating the wireless system Flow chart for using the wireless system To use SMC wireless units (Base and Remotes), they need to be set up using an NFC reader/writer and the I/O Configurator. Refer to the operation manual of the product or I/O configurator in use for the further details. -
Page 17: Mounting And Installation
Mounting and Installation Installation (Valve) Caution Apply the recommended tightening torque to avoid damage to parts. ・ Install the product using screws in the two mounting holes. Use M3×30mm screws. The ・ recommended torque is 0.6+/-10% N・m. Caution Mounting the wireless adaptor (direct mount) 1. - Page 18 Mounting the wireless adaptor (with the wireless adaptor cable) Caution Connect the wireless adaptor cable to the product and the wireless adaptor. Wireless adaptor cable Wireless adaptor -17- Doc. DOC1117660...
-
Page 19: Troubleshooting
Troubleshooting When problems occur, take appropriate countermeasures while referring to the LED indication, troubleshooting and parameter settings. If a cause applicable to the failure cannot be identified, this indicates that the equipment itself is broken. The fieldbus system damage can be caused by the operating environment. Contact SMC to obtain countermeasures. - Page 20 •Remote troubleshooting LED status Problem Investigation and Possible causes name countermeasures Color ON/OFF/Flashing The US1 (for control / input) Supply 24 VDC +/-10% for US1 power supply is OFF (for control / input) power source. US2 (for output) power supply Supply 24 VDC +/-10% for US2 Green Flashing...
- Page 21 LED status Investigation and Problem No. Possible causes name countermeasures Color ON/OFF/Flashing (1) Supply 24 VDC +/-10% for the US1 (for control / input) power source of the Base. When Protocol V.1.0 is used (2) The distance which wireless (1) Power supply for the Base is communication between wireless Flashing systems can be established may...
- Page 22 LED status Investigation and Problem No. Possible causes name countermeasures Color ON/OFF/Flashing (1) Supply 24 VDC +/-10% for the US1 (for control / input) power source of the Base. (2) The distance which wireless (1) Power supply for the communication between wireless base is OFF Flashing systems can be established may...
-
Page 23: Technical Information
Technical Information I/O map The table below shows the number of bytes occupied by input and output. For the EXW1-RDX*G4C* and EXW1-RDM*G3C*, the number of occupied bytes for the entire unit varies depending on the wireless protocol. Occupied bytes Product No. Input Output EXW1-RDY*M5C... - Page 24 For the fieldbus / Industrial Ethernet with the little endian transmission format (e.g. EtherNet/IP, EtherCAT) For diagnostic information, please refer to the following diagnostic parameters and the user manual for the wireless base. -23- Doc. DOC1117660...
- Page 25 Parameters Parameters and data can be changed/checked by IO configurator and paired base. For more details, refer to the manual of the IO configurator and paired base. When EXA1 series is paired, parameters of EXW1-RDY*M5C is fixed default setting. < EXW1-RDY*M5C parameters > Default Target Parameter...
- Page 26 Default Target Parameter Definition Item Content setting Sets hold status Hold Hold the output ○ when Wireless Hold State for RF Communication Timeout timeout is Individual Refer to No.12. occurred. Sets output Clear Turn off the output ○ status when Output State for Wireless Individual...
- Page 27 < EXW1-RDY*M5C diagnostic parameters > 対象 名称 定義 値 内容 Ch #: ON/OFF count 0-4294967295 ON/OFF times for each ON/OFF Counter value. (0 to 0xFFFFFFFF) channel. Value Clears the Input Ch #: ON/OFF Counter ON/OFF counter Clr (Clear) Clear ON/OFF count value. Clear to 0.
-
Page 28: Specifications
Specifications Dimensions -27- Doc. DOC1117660... -
Page 29: Electrical Specifications
Electrical specifications Item Specifications Model EXW1-RDYPM5C EXW1-RDYNM5C 24VDC+/-10% US1 (for control/ input) power supply voltage range 24VDC+/-10% US2 (for output) power voltage Current consumption 50 mA or less Galvanic isolation Between US1 and US2 Number of points 32 points/ unit Output type Output Maximum load current... -
Page 30: Accessory List
Accessories Accessory List For the selection of accessories, refer to the catalog and SMC world website. URL: https://www.smcworld.com -29- Doc. DOC1117660... - Page 31 Revision history https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved...
