Relay Station RS422 Pin-outs
The RF Relay Stations are connected by twisted pair wire -- use Belden 1227A1, Cat 5 wire or equivalent.
The Relay Port on the Base Station and the Relay Port on the Relay Station are connected with a straight
cable using the following pin-outs:
Make a cable with 5-5, 6-6, 2-2, and 3-3 (a straight cable); but, be careful that you select wires so that the 2
wire is in the twisted pair with the 3 wire, and the 5 wire is in the twisted pair with the 6 wire.
For all RJ Cable pin numbers, number from left to right with the metal pin side of the connector facing you
and the cable running to the down position.
Base Connector Pin #
Receive Data + 5
Receive Data - 6
Transmit Data + 2
Transmit Data - 3
Relay Connector
Transmit Data +
Transmit Data -
Receive Data +
Receive Data -
