Bar Code Options - Worth Data RF Terminal 7000 Owner's Manual

Control Keys Only
Control Keys Only
Control Keys Only
• Several special keys on the RF Terminal keypad can generate a response automatically, sending a separate
message to the host by simply pressing the appropriate control key (without pressing the ENTER key
afterward). This allows for simple and fast scrolling by the operator. The arrow keys, Begin, End, and Search
are the specific keys supported. The default setting is to require the ENTER key to be pressed before data
transmission.
• If you set this feature to ON, in order for the RF Terminal to transmit the following values, the corresponding
Control Key must be the first key pressed in a data entry sequence. If it is not the first data entered, the arrow
key is ignored.
Control Key on RF Terminal
Up Arrow
Down Arrow
Left Arrow
Right Arrow
Begin
End
Search
The message is sent to the host as:
Bytes Function
1 RF Terminal ID
2 Data Transmitted
Last Terminator of Message
Automatic Check Back
This parameter should not be changed under normal circumstances. After the host sends a prompt, the
Terminal goes to sleep waiting on the operator to key or scan input in response to the prompt. It waits until
the Automatic Shut Off time or until the operator responds. This parameter sets the time that the Terminal
stops waiting on input from the operator, discards the current prompt, and goes back to the host to see if
there is a change in instructions. If no change, the host must resend the prompt again because the Terminal
has discarded the original prompt. The host now has the opportunity to change a prompt. The time can be set
in increments of 5 seconds, up to 495 seconds. The default value is 00. The values possible for entry are 00-
99. An entered 99 gives 99x5 seconds, or 495 seconds between check backs. The Terminal sends back an
ASCII 07 for the data back to the host (ID ASCII 07 CR). To change this value press the 6 key in the RF
Configuration menu and enter the 2 digit value desired.

Bar Code Options

Code 3 of 9 (Code 39)
Code 3 of 9
Full ASCII
Accumulate Mode
Transmit Start Stop
MOD 43 Check Digit
Transmit MOD 43
Caps Lock
Decode Option
• The Start and Stop character for Code 39 is the * character. Setting 4 determines whether or not those
Off
On
Code transmitted to Host
FS (ASCII 28)
GS (ASCII 29)
RS (ASCII 30)
US (ASCII 31)
ETB (ASCII 23)
CAN (ASCII 24)
VT (ASCII 11)
Value
0-9, A-Z, a-z, - =
ASCII Value from Table Above
CR
ON OFF 1
ON OFF 2
ON OFF 3
ON OFF 4
ON OFF 5
ON OFF 6
ON OFF 7
0, 1, 2 8
