For example, the command @1,1,1, Enter Quantity would display Enter Quantity starting at position 1 on
line 1, then wait for the operator to enter their data.
These are valid entries for the third position character:
Here are some rules and useful tips for creating messages (one or more commands per message):
• Re-initialize commands *@, or n@ (where n is the Terminal ID 0-F) clear the buffer for terminal(s) in the Base
Station. Following a re-initialization, the host program should re-display of all the screen data necessary to start
the application.
• A message with multiple commands is legal and useful. For example, the command "@1,1,0, PLEASE
ENTER@2,1,1,QTY" would display PLEASE ENTER on line 1, display QTY on line 2, and then wait for
data input. All 6 lines can be filled with one message.
• Messages can be a combination of multiple commands, (i.e. voice messages, initialization, clearing lines,
requesting data entry), up to 1000 characters in length. A message cannot though, contain an @S command in
combination with any other command. A message also should not contain more than 1 request for data entry
(third character in command is 1). For example:
has two data entry "prompt" commands combined. If this message were sent to the RF Terminal, the first
data entry prompt (@1,1,1,ITEM) would be executed, but any and all commands after the first data entry
0 No data input for this Command, Display ONLY
1 Data input required from the keypad or scanner
2 Only keypad input allowed, start un-shifted
3 Only keypad input allowed, start SHIFTED
4 Only scanner input allowed
5 Only accept YES (Enter key or C key) or NO (0 key or B key)
keypad response. (Terminal sends 1 for YES, 0 for NO). C and
B key are there to facilitate YES/NO keypad entry while
scanning with integrated laser.
7 Single key entry required. Only one keystroke is accepted with
the following exceptions: F2 – replays last voice prompt,
DELETE and CLEAR are ignored, STATUS – displays status,
SHIFT – toggles shift mode as usual, ENTER – transmits an
empty string, F1 – exits.
A same as 1, but time stamped as prefix (hhmmss)
B same as 2, but time stamped as prefix (hhmmss)
C same as 3, but time stamped
D same as 4, but time stamped
E same as 4, but can press END key to break-out of scanner-
only input mode. Terminal ID + CR is sent to host
S SHIFTED keypad input or scanner input
p un-shifted keypad entry with no display (for passwords)
P SHIFTED keypad entry with no display (for passwords)
R Data input required from the RS-232 serial port (waiting for
serial input can be bypassed by pressing the ENTER key
which will send a NULL data string back to host computer.)
Uses for this are PDF 417 Serial Scanners, and the Cameo
Printer's magnetic stripe input. A POS terminal becomes
possible. Scan the credit card and print the receipt, all on the
RF Terminal.
K Data input from an external serial keyboard that attaches to the
serial port. As data is keyed, the characters are displayed on
the RF Terminal LCD display.
M This command is for a printer initialization and magstripe input
on the Zebra Cameo printer equipped with the magstripe
option.
@1,1,1,ITEM@2,1,1,QTY
