Programming for the RF Terminal

The three levels of programming support offered for the RF Terminal are:
• Low Level ASCII sequences sent to and from the Base Station by the user program reading/writing to the
serial port.
• Active X drop-in components. Every necessary function is defined. You just complete the code for each
function.
• TCP/IP Active X drop-in components used by the "Server" computer to communicate with the "Client"
computer that has the Base Station(s) attached.

Low-Level Direct To Serial Port Programming

Planning
Remember, plan for every error that the Base Station might return including:
Sequence Errors detected
Illegal Command detected
Base Station Initialization detected
Addressing a Terminal Not Signed In detected
Command without an ID
Programs can be written in any language that has access to the serial port (reading/writing), regardless of the
platform. No more than one Base Station is allowed for each serial port.
Host to Terminal Programming
The basic format of a message that is transmitted from Host to Base to Terminal is fairly simple:
The RF Terminal ID is always the first byte and always only 1 character in length. There are 64 different
possible values - 0-9 , A-Z, a-z, - and =.
The Command(s) section of the message always starts with the second byte and can consist of one or more
commands - including data to be displayed or voice messages to be broadcast.
The last byte is always ASCII 4 (EOT) to terminate the message.
Byte position Function
1 RF Terminal ID
2+ Command(s)
Last Termination of message
Possible values
0-9, A-Z, a-z, - =
**
EOT (ASCII 4)
