Worth Data RF Terminal 7000 Owner's Manual page 19

UPC-E / EAN-8 Options
UPC-E First Digit
EAN-8 First Digit
UPC-E Check Digit
EAN-8 Check Digit
UPC-E Expanded
UPC-E1
• Use setting 1 and 2 to enable or disable the UPC-E or EAN-8 first digit.
• Use setting 3 and 4 to enable or disable the UPC-E or EAN-8 check digit. The check digit is the last character
and is based upon a calculation performed on the other characters.
• Use setting 5 to select UPC-E0 compressed or expanded. When set to ON (the default setting) UPC-E1 codes
are transmitted as is, when set to OFF UPC-E1 codes are transmitted with inserted zeros to make them the
same length as a UPC-A bar code. An NSC of 0 is assumed.
• Use setting 6 to enable the reading of UPC-E1 bar codes. Do not enable UPC-E1 if you plan on reading EAN-
13 bar codes. You may experience partial reads when reading ENA-13.
• If you prefer to transmit UPC-E bar codes in a 6-digit format while EAN-8 is transmitted in its original 8-digit
format, set option 7 to ON.
Code 128
Code 128
UCC/EAN 128
• UCC/EAN-128 is a subset of Code 128 that follows certain specifications regarding character content, length
and check digits. Enabling UCC/EAN-128 (2) causes the RF Terminal to look for a Code 128 bar code that
begins with the Code 128 F1 (Function 1) character. See Appendix H: Code 128 for more details.
Codabar
Codabar
Codabar CLSI
Start Stop Character
• CLSI is a form of Codabar often used by libraries.
• Setting 3 will transmit the Codabar start and stop characters with the bar code data to your computer. If you are
varying the start and stop characters to differentiate between different labels, transmitting the start and stop can be
helpful. See Appendix G; Codabar for more information.
2 of 5 Code
Interleaved 2 of 5
Check Digit
Transmit Check Digit
Standard 2 of 5
2 of 5 Code Length
• Setting 2 requires that the last digit in your bar code conform to the specifications for the 2 of 5 check digit
calculation. See Appendix I; 2 of 5 Code for more information.
• Transmission of the check digit (3) requires the use of setting 2 and will transmit the check digit along with the bar
code data to the computer.
ON OFF 1
ON OFF 2
ON OFF 3
ON OFF 4
ON OFF 5
ON OFF 6
ON OFF 1
ON OFF 2
ON OFF 1
ON OFF 2
ON OFF 3
ON OFF 1
ON OFF 2
ON OFF 3
ON OFF 4
06 5
