RF System Setup

The RF Terminal can be configured using the Terminal Setup Menu. Most users do not need to change
anything in the setup. The most commonly changed setup parameters are the Terminal ID (especially if you
have more than 1 terminal) and the Channel (if you are adding an additional Base station).

Factory Default RF Terminal Configuration

Parameter Default Setting
RF Configuration RF Channel - 0
Terminal ID - 0
Security code - OFF
Skip opening screen - OFF
Control Keys Only - OFF
Auto Check Back - 00
Code 3 of 9 Code 39 - ON
Full ASCII - ON
Accumulate Mode - ON
Transmit Start Stop - OFF
MOD 43 Check Digit - OFF
Transmit MOD 43 - OFF
Caps lock - OFF
Decode Option - 0
2 of 5 Code Interleaved 2 of 5 - OFF
Check Digit - OFF
Transmit Check Digit - OFF
Standard 2 of 5 - OFF
2 of 5 Length - 06
UPC-A EAN 13 UPC/EAN ALL - ON
Supplements - OFF
UPC-A NSC - ON
UPC-A check digit
transmitted - ON
EAN-13 country code
transmitted - ON
UPC-E EAN 8
EAN-13 Check - ON
ISBN EAN-13 mode - OFF
UPC-A as EAN-13 - OFF
UPC-E First Char - OFF
EAN-8 First Char - ON
UPC-E Check Digit - OFF
EAN-8 Check Digit - ON
UPC-E Expanded
Transmission - OFF
UPC-E1 - OFF
Other Bar Code Storage Tek Label – OFF
Options
LabelCode 5 - OFF
LabelCode 4 - OFF
Barcode IDs - OFF

Using the Setup Menu on the RF Terminal

The RF Terminal can be setup via the Terminals' keypad by entering Setup Mode from the menu. Turn on
the Terminal and press any key. You should see the MODE MENU message:
1. - Sign On
2. - Setup
3. - One Way Mode
4. - RF Site Survey
Press the 2 key. The next menu allows you to choose which item to configure:
RF TERMINAL SETUP
RF CONFIGURATION
BAR CODE OPTIONS
RS-232 I/O SETTINGS
DATE & TIME SETTINGS
Parameter Default Setting
MSI /Plessey Code MSI - OFF
MSI with 1 mod 10 - OFF
MSI with 2 mod 10 - OFF
MSI with mod 11/mod 10 -
OFF
Transmit check digit - 0
Plessey - OFF
Codabar
Codabar - OFF
CLSI format - OFF
START STOP Char - OFF
Code 128 Code 128 - ON
UCC/EAN-128 - OFF
Databar / RSS-14 Databar / RSS-14 - OFF
Code 93 / Code 11 Code 93 - OFF
Code 93 full ASCII - ON
Code 11 - OFF
Code 11 Check Trans - 0
RS-232 I/O Settings Baud Rate - 9600
Parity - none
Data bits - 8
XON/XOFF Printer - ON
Time & Date Settings Date Format - USA
Year Output – 2 digits
Shut Down Time – 5 min
Speaker Options Beep Volume - medium
Beep Tone - 2
Voice Volume - medium
Keypad Tone - ON
Laser Options Double Decode - OFF
4.5 Second Beam - OFF
Aiming Dot Duration – 0
seconds
LCD Settings 4/6 Line Legacy Mode -OFF
Background Color – 1 (black)
Text Color – 2 (blue)
Brightness – medium
Brightness Timeout – 5 sec
