① Wired DMX Cable Connections
Use the provided DMX to Data cables to connect to the in/out network sockets on the light
for use with a cabled connection.
Note: 1. Turn off the wireless DMX when using a DMX cable connection.
2. This can be done by accessing (SnAL) in your Menu and changing the setting to (Uire)
.
② Wireless DMX Connection
Operational instructions:
1. Firstly, ensure that you are outputting signal from your wireless DMX controller
2. Verify light is set to (ULee) in your (SnAL) menu
3. Press the (Menu) button and (Enter) to display the current DMX address. Set as necessary.
4. Reading the Wireless Indicator / Group ID Light:
● Red LED Flash: Sending Signal
● Green LED Flash: Receiving Signal
This unit features seven wireless groups for multiple applications.
*Receiving unit Group ID must be on the same Group ID as the transceiver i.e. red-red
DMX Settings & Connections
Group
1
2
3
4
5
6
7
Wireless Indicator LED Color
Red
Green
Yellow
Blue
UV
Cyan
White
