Technical data
16.1.3
Height of the UNIGATE
16.2
Technical data UNIGATE
Characteristics
Supply voltage
Interface
IP-address
Bus-baud rate
UART-baud rate
Supported Ethernet protocols
Technology
Others
Dimensions
Weight
Operating temperature
Storage / transport temperature -40°C..+100°C
Built-in position
40
Instruction manual UNIGATE
®
FC
®
FC PROFINET
Explanation
3.3V ± 5 %, max. 550 mA DC
2 UART interfaces, 1 synchronous serial interface
Assigned by the Profinet-IO-controller (SPS)
100 MBaud
Up to 520 Kbaud (adjustable via script)
UDP/IP, TCP/IP
32-bit-processor
I/Os, analogous signals, shift registers, LEDs, switches and so on can be
connected externally
47-52 mm x 56 mm x 18 mm (WxDxH)
Approx. 25 g
-40°C ..+85°C
Any
®
FC - PROFINET 2Port V. 1.5
Deutschmann Automation GmbH & Co. KG
4.10.17
