Firmware-Update

15 Firmware-Update

15.1

Overview

®
UNIGATE FC has an internal memory for the firmware. It can be replaced via the UNIGATE
FC's Ethernet-(PROFINET)-interface.
15.2

Execution of the firmware-update

The safest way for the firmware-update is the use of the basic board combined with the software
"FDT.EXE" (firmware-download-tool). These tools are available from Deutschmann Automation
(see chapter 17 on page 41).
A Firmware-update can be carried out in the following operational modes:
Configuration mode (via the IP-address UNIGATE
Firmware-update-mode (via the fixed IP-address 10.10.10.10)
15.3

Adjusting the firmware-update-mode

15.3.1

Adjustment by hardware

®
UNIGATE FC can be brought to the firmware-update-mode by the hardware. For it the signal
BE (boot enable) has to be pulled to the potential GND during the Power-up-process.
15.4

Note on safety

The firmware-update should only be carried out when there is no other possibility left. A firm-
ware-update-process that has already been started CANNOT be undone. With it the previously
used firmware is permanently unusable.
15.5

Operation mode of the FC

Data exchange mode
This mode is required for the regular use of the FC. In this mode the FC will process all script-
commands and normally exchange the corresponding user data. The bus as well is operated in
this mode through the FC.
Configuration mode
In the configuration mode the UNIGATE
reset). After a successful self-test it will wait for further commands. Here it is possible to load a
translated Script into the unit or to configure the device.
