Tools Required for Assembly

R-Style Modesty Panel & Beam #
53357
A. Power Driver with Adjustable Torque
B. #2 Phillips Head Driver Bit
C. #2 Square Head Drive Bit
A
B
C

Hardware Included for Assembly

(may have extra)
D. M6 x 1/2" Phillis Machine Screw x6
E. 10 X 5/8" Round Washer Head Recex Drive Screw x9
D
E

Step 1

• Attach the modesty panel to the legs
with six machine screws.
D
A
B
D
D
K&A Manufacturing • 800.298.4351 • www.raproducts.com/install
2 of 6
