RightAngle R-Style Beam Assembly Instructions

Advertisement

R-Style Beam Assembly Instructions
Failure to comply with or observe all assembly, safety, and operation instructions
and warnings regarding the use of this product may result in serious property
damage or bodily injury.
Make sure no obstacles are in the desk's path and all cords are of appropriate length for the
desk. Always maintain a 1" clearance around the table to prevent pinching.
Never assemble (or disassemble) the table or components with the table plugged into a
power outlet. This product is for use on a nominal 120-volt circuit and has a grounding plug.
Make sure that the product is connected to an outlet having the same configuration as the
plug. No adapter should be used with this product.
Warranty: raproducts.com/warranty
Instruction #54126 • Dated: 05/22/2018
1 of 3
