The following table provides information on each connector and a description:
Rear PANEL ELEMENTS TABLE
Item
A
B
C

3.1.3 Side Panels

Two WWAN antennas are located on the side panels, one on either side.
Fig. 3: Right hand side panel
Fig. 4: Left hand side panel

3.1.4 Underside Panel

The following elements can be found on the underside panel:
Teldat Connect-4GE Router
Description
RESET. Reset button. For further information on how the reset button operates,
please see the section on the
ETHERNET. Gigabit Ethernet.
Power source connection (PSU).
RESET Button on page 11 further on in this chapter.
3 Components and Power Supply
5
