. TOOLS AND TORQUE SPECS

3.1 Use the proper tightening torques, it is essential for the correct function and to
avoid loosening or structural damages. In certain cases tightening torques ensure
mechanical couplings, in other cases they prevent loosening. Depending on the
application, the threads should be greased or treated with thread-lockers. Refer to the
chart below for the proper torque to be applied and for the treatment.
Suggested thread-lockers are:
- Loctite 222
- Arexons System 52A22
To lubricate threads never use lithium-based greases.
COMPONENT
Seat Post: fixing clamp
Seat Post: saddle rail bolts
Stem: fork tube fixing bolt
Expander: inside steerer tube
Cap on top of the stem
Bottle Cage
BB Cable Guide
Down Tube Cover
Talon Ultra Cover (rear)
Talon Ultra
Cover (front)
Use MOST Safe grip paste on the seat post before installing it. After first ride, and
consistently thereafter, recheck the tightness of each bolt to ensure secure attachment
of the components.
5
TORQUE [Nm]
4
4 (front)
8(rear)
6
6
Preload: 2
Final: 6 (MAX)
2
2
0.5
0.5 (MAX)
w/o iTalon 1 (MAX)
w/ iTalon 3
CICLI PINARELLO S.R.L. | Viale della Repubblica, 12 - 31020 Villorba (TV) - Italia
C.F. - R.I. - P.IVA IT 05994100963 | tel. +39 0422 42 08 77 | fax +39 0422 42 18 16 | www.pinarello.com
THREAD TOOL
Lubricated Torx T15
10 mm HEX key (front)
Lubricated
5 mm Allen key (rear)
Thread-locker Torx T20
Lubricated Allen key 6 mm
Thread-locker Allen key 5 mm
Thread-locker Torx T25
Thread-locker Torx T20
Thread-Locker Allen key 2 mm
Thread-Locker Torx T10
Thread-Locker
Torx T25
Torx T25
