Iperation
7.1 Iperating channels
using the browser
2004919_i•en•2017-09-01
In the "Operation" menu (see Fig. 24), you can switch the control functions
(sun control mode and dawn/dusk control mode) on and off via the on/off
button for all created channels that are linked to the WMS WebControl. While
the transmission process is "on", the control modes are displayed in green;
when the transmission process is "off", they are displayed in red (see Fig.
23).
Fig. 23 Control modes on/off
In the "Settings" menu (see Fig. 23), the status (on/off) of the control func-
tions of the selected channel is displayed (of the comfort control modes
only; safety control modes are not affected).
The values for sun and dusk can be changed using the slider.
Even if the control modes are switched off in the "Operation" menu, the slid-
ers can still be changed in the "Settings" menu. Thus, for example, klx values
can be set using the sliders; these settings are subsequently already preset
and apply when the control modes are switched back on.
To use this functionality, open your browser. If you are using a PC, enter
"http://webcontrol" in the address bar of the browser. If you are using iOS/
OS X, enter "webcontrol.local" in the address bar. (See also Chapter 4.4 on
page 12).
Now open the "Operation" menu in the left column of the WMS WebControl
browser page to view the changes.
Select the room and channel.
In this example, the current position of your channel (here, for example, kitch-

en, external venetian blind kitchen) is shown in the right column.
To change the position of the unit (roller shutter, external venetian blind, ...),
for example by lowering it, drag the slider to the desired setpoint position
while keeping the mouse button pressed.
The position you set is displayed as a percentage. This percentage shows

you the new setpoint position.
Press the "" symbol for "play" and start the process.
The spinning wheel indicates that the actuated channel is moving; the set

positions are shown in grey during the movement. As soon as the target
position in grey (% value) is reached, the spinning wheel disappears and the
current position is displayed in black.
A small white wireless symbol at the top left indicates that the WMS Web-

Control is transmitting.
The wireless symbol lights up green briefly after successful transmission and
red if the process failed (see the table Fig. 25 on page 30).
The new current position is now displayed as a black percentage value.
The " " stop button lets you stop the product movement.
With external venetian blinds, you also have the option of adjusting the incli-
nation angle of the slats using the left slider. The procedure is the same.
We reserve the right to make technical changes
29
