- Page 1 WMS WebControl Manual (Keep for future use) Valid from 01 September 2017 Sun. Light. WAREMA . 2004919_i...
- Page 2 Operating instructions, manuals and software are protected by copyright. All rights to the software are specified in the license agreement included. WAREMA and the WAREMA logo are trademarks of WAREMA Renkhoff SE. All other brand or product names included in this document are trademarks or registered trademarks of their respective owners.
-
Page 3: Table Of Contents
Loading the firmware update ................35 Resetting the device to the factory settings ..........35 DHCP disabled ....................36 10 External access to WMS WebControl via the Internet ........ 37 10.1 What is VPN? ...................... 37 11 Connecting to the WAREMA WebControl App ..........38 12 Technical data .................... -
Page 4: Legal Notes
Copying, duplication, translation or conversion into any electronic medium or into a machine-readable format, as a whole or in part, without prior written consent by WAREMA is not permitted. All further rights to the software are specified in the supplied license agreement. -
Page 5: Intended Use
CCAUTIO The WMS WebControl is for indoor use only. It is not water-proof. The operating range of radio remote controls is limited both by legal regula- tions for radio systems and structural factors. Adequate radio reception must be ensured when planning the project. -
Page 6: Introduction
3 Tntroduction 3.1 Functions Using WMS WebControl, you can comfortably operate WMS products on a mobile device from your home using your own WLAN network. Separate apps are available for iOS devices such as the iPhone and iPad, and for Android devices (smartphone, tablet). -
Page 7: Scope Of Delivery
"DHCP" (Chapter 9 on page 36). Therefore, check that the unit is functioning properly before installing/setting it up permanently. Both the WMS WebControl ➊ and the WMS components ➏ being controlled must have excellent radio reception. 2004919_i•en•2017-09-01... -
Page 8: Installation
The WMS WebControl is supplied with power via the included plug-in power supply unit ➍. Connect the USB power supply unit ➍ to the WMS WebControl ➊ using the included USB cable. Connect the WMS WebControl ➊ with the locally configured router ➎ via the included LAN cable ➌. -
Page 9: Connections
Resetting the device to the factory settings (see Chapter 8.3 on page 35). RJ45 socket, yellow LED Flashes when there is data traffic between the WMS WebControl and the router. RJ45 socket, green LED Lights up permanently when the physical connection between the WMS Web- Control and the router is functional. -
Page 10: Commissioning
4.1 Commissioning via the WMS studio software A comfortable method of loading new projects to the WMS WebControl is made available by the WMS studio software as of version 2.0.0 (see the "WMS studio software" software manual, art. no. 890396). You will require an SD card with the format FAT32. -
Page 11: Adding The Wms Webcontrol To The Wms Network
The hand-held transmitter scans for receivers. If they are found (in this case, the WMS WebControl), the display in the upper LED row flashes red (new receiver). If multiple receivers are indicated by the LEDs, verify that it is the right receiv- er, i.e. -
Page 12: Access Through A Browser
If this procedure is not successful on your Smartphone and/or PC, the web address of the WMS WebControl was not recognised by your router. In this case, open the client table of your router (use the router manual for this pur- pose). -
Page 13: Password Use
Commissioning 4.4.1 Password use Because a project does not yet exist when you access the system for the first time, you will need to click on the "Configuration" menu. You will then be prompted to enter a password. For initial access, please use the following preset password: Password "5858". -
Page 14: Configuration Menu
Create new channels and scenes ⑦ List symbol activated: move channels/scenes using "drag and drop" ⑧ Adopt WMS channels in the WMS WebControl using the "L adopt" but- ton. ⑨ Save settings We reserve the right to make technical changes... -
Page 15: Setting The Clock
(see also the explanations in Chapter 7.4.1.1 WMS studio Software Manual, art. no. 890 409). Fig. 9 Setting the date and time of the WMS WebControl 2004919_i•en•2017-09-01 We reserve the right to make technical changes... -
Page 16: Creating And Editing Rooms
Configuration WMS WebControl 5.2 Creating and editing rooms Click on the "+" button to create rooms. A window appears in which you can enter the name of the room (for exam- ple, "Living room"). Click "Create". The room is then created and appears in the left column of the menu. -
Page 17: Adding Channels To A Room And Editing Them
Configuration In this way, you can create a total of 20 rooms of 10 channels or scenes each. A maximum of 32 scenes can be created (with the numbers 0 to 31). Follow the instructions step-by-step. Always create a room first so that you can then (as described below) create the associated channels. -
Page 18: Creating Scenes
Accept your selection with the "Create" button. Never use the same scene number for different transmitters (e.g. WMS Hand- held transmitter and WMS WebControl) in combination with the same plug receivers (you would overwrite the first scene). If you have already created scenes in another project, begin numbering the scenes from the end, i.e. -
Page 19: Copying The Structure Of The Wms Network To The Wms Webcontrol
The WMS Hand-held transmitter must be within radio range of the WMS WebCon- trol. In the WMS WebControl, go to the "Configuration" menu and select the de- sired channel (e.g. Roller shutter 1) in the corresponding room (e.g. Kitchen). Wake up your WMS Hand-held transmitter, for example, by pressing any product button. -
Page 20: Settings Menu
Settings WMS WebControl 6 Settings menu 6.1 Control modes Fig. 15 Interface of the WMS WebControl, Settings menu, Control modes menu item ① Control modes menu item ② Room setting ③ Channel setting ④ Sun control mode ⑤ Dawn/dusk comfort mode ⑥... -
Page 21: Overview Of Control Modes
When the "CLOUD" limit value is undercut, the sun shading products are raised. If the "SUN" limit value is adjusted via WMS WebControl (or via the WMS Hand-held transmitter), the "CLOUD" limit value will always change automati- cally as well (60% of the "SUN" limit value). - Page 22 Settings - control modes WMS WebControl Below you can see an overview of the WMS WebControl screens on which you can adjust the control modes. In the "Operation" menu, the (①) buttons activate and deactivate the control modes for all rooms with the channels created there that the WMS WebControl knows.
- Page 23 Settings - time switch In the "Time switch" menu item in the "Settings" menu, the time switch button must be set to "On" (①) to be able to adjust the control modes. Time switch off: Completely deactivates the time switch; the channels are controlled by the control modes Time switch on: Here you can switch on the time switch and, as described later (see Chap-...
- Page 24 Settings - control modes WMS WebControl Control modes in the "Operation" menu (see Fig. 16) enable You have set the control modes for a channel in a room to "Off" (slider in Fig. 17) and have enabled these for a switching time (Fig. 18). This means that the values entered for the switching time always apply at that time and the sun shading system moves to this position at that time.
-
Page 25: Time Switch With Switching Times
Switching times 6.3 Uime switch with switching times Fig. 19 WMS WebControl interface, Settings menu, Switching times menu item ① Switching time menu item ② Room setting ③ Channel setting ④ Time switch on/off ⑤ Select the weekday ⑥ Set the time ⑦... - Page 26 Switching times WMS WebControl The time switch lets you define up to four different switching times per day in the "Settings" menu. Depending on the channel (i.e. awning, external venetian blind, etc.), you can set positions and/or inclination angles at each switching time that meet your personal comfort requirements.
- Page 27 Switching times Select the switching times that you wish to assign one after the other and en- ter the required times using the arrow keys. Alternatively, you may edit the time with a mouse click or enter the time using the digits on the keyboard.
-
Page 28: Operation Menu
Iperation WMS WebControl 7 Iperation menu Fig. 22 WMS WebControl interface, "Operation" menu ① Selection of rooms ② Selection of channels and scenes ③ Slider for changing the position of sun shading products ④ Percentage shows the current position of the sun shading product ⑤... -
Page 29: Operating Channels Using The Browser
In the "Operation" menu (see Fig. 24), you can switch the control functions (sun control mode and dawn/dusk control mode) on and off via the on/off button for all created channels that are linked to the WMS WebControl. While the transmission process is "on", the control modes are displayed in green;... - Page 30 Example A window alarm is active on the awning on the west side, the awning has been retracted, the WMS WebControl shows a black wind symbol and a green wireless symbol, and manual operation is blocked. The awning on the east side is extended due to the sun control, and in addition to the above symbols the "Sun...
-
Page 31: Operation Of Scenes
Iperation 7.2 Iperation of scenes After you have created a scene (see 5.4 on page 18), change to the "Op- eration" menu. The newly created scene (Kitchen scene 1) is displayed in the menu. On the left, click the room for which you created the scene (Kitchen) and se- lect the scene on the right (Kitchen scene 1). - Page 32 Iperation WMS WebControl Fig. 27 "Operation" menu after successful creation of a scene Before you can operate your channels using the scene, for example to move to another position by clicking on "" for "play", you first need to teach the system how to react to the scene.
-
Page 33: System Menu
Display of: ① DHCP "ON" or "OFF" (see Chapter 9 on page 36) ② IP address (assigned to the WMS WebControl by the router) ③ Subnet (assigned to the WMS WebControl by the router) ④ Gateway (assigned to the WMS WebControl by the router) ⑤... -
Page 34: Sd Memory Card
System WMS WebControl The menu bar of the WMS WebControl contains another large menu item. Click the "System" button to obtain information about the status of your sys- tem. Fig. 29 Status information under the "System" menu item. 8.1 SD memory card... -
Page 35: Loading The Firmware Update
You can then release the push button, and the device will be reset to the fac- tory settings. When you reset the device to the factory settings, all data are deleted and the WMS WebControl is deleted from the WMS network. The IP settings are retained. 2004919_i•en•2017-09-01... -
Page 36: Dhcp Disabled
Make sure that the IP address you assign lies within the router's subnet mask. Save this file on an SD card. Insert the SD card into the SD slot of the WMS WebControl before connect- ing the USB cable. Plug in the power supply unit. -
Page 37: External Access To Wms Webcontrol Via The Internet
Tnternet WMS devices can only be operated on the home network. Access via the Internet is not supported by WMS WebControl. However, access is possible using appropriate routers via VPN (e.g. Fritz!Box by AVM: www.avm.de). 10.1 What is VPO? VPN access (VPN = Virtual Private Network) authorises the mobile device to access the local network from the Internet. -
Page 38: Connecting To The Warema Webcontrol App
The following screen appears when the app is opened: Fig. 31 App start screen If the WMS WebControl was not found, see the Chapter 13 on page 40 Troubleshooting. The data are synchronized, i.e. the project is loaded. The app automatically changes to the "Operation" screen. -
Page 39: Technical Data
Conformity available at www.warema.de Ambient conditions Operating temperature °C Storage temperature °C Rel. humidity (non-condensing) Article numbers WMS WebControl black 2003 877 WAREMA Renkhoff SE Hans-Wilhelm-Renkhoff Strasse 2 97828 Marktheidenfeld Germany 2004919_i•en•2017-09-01 We reserve the right to make technical changes... - Page 40 DHCP to "OFF" as described in Chapter 9 on page 36. The WMS WebControl is not found by the DHCP is set to "OFF", i.e. there is no auto- Check the network connection.
-
Page 41: Appendix
Further comfort control functions (such as the dawn/dusk control) are not shown here since these are preset as system time clocks at the factory for use of the WMS WebControl and are not permitted to be changed. 2004919_i•en•2017-09-01 We reserve the right to make technical changes... - Page 42 WAREMA Renkhoff SE Hans-Wilhelm-Renkhoff-Strasse 2 http://www.warema.de info@warema.de 97828 Marktheidenfeld/Main/Germany...
