- Page 1 WAREMA climatronic® WebControl Manual (Keep for future use) Valid from 01 December 2015 Sun. Light. WAREMA . 2011980_d...
- Page 2 Operating instructions, manuals and software are protected by copyright. All rights to the software are specified in the license agreement included. WAREMA climatronic® is a registered trademark of WAREMA Renkhoff SE. WAREMA and the WAREMA logo are trademarks of WAREMA Renkhoff SE.
-
Page 3: Table Of Contents
Loading firmware updates ................. 25 Resetting the device to the factory settings ..........26 DHCP disabled ....................27 External access to WAREMA climatronic® WebControl via the Internet .. 28 What is VPN? ...................... 28 10 Connecting with the WAREMA climatronic® WebControl App ....29 11 Technical data .................... -
Page 4: Safety Instructions
Safety WAREMA climatronic® WebControl instructions 1 Safety instructions We have developed and tested the WAREMA products and this software in compliance with basic safety requirements. Residual risks nevertheless remain! For this reason, please read this manual before commissioning and operat- ing the controls. -
Page 5: Target Group
These instructions are intended for persons who wish to operate their sun shading products using an app or browser. 1.4 Additional documents These instructions provide all of the information necessary to configure the WAREMA climatronic® WebControl. The following documents are available in addition to these instructions: Document Number WAREMA climatronic®... -
Page 6: Introduction
Nntroduction WAREMA climatronic® WebControl 2 Nntroduction With the WAREMA climatronic® WebControl, you can comfortably operate your sun shading system from home on your own WLAN network using your web browser or mobile devices (laptops, smartphones, tablets). An app is available for Android devices. -
Page 7: Wiring Diagram
Nntroduction The WAREMA climatronic® WebControl is connected to the WAREMA cli- matronic® control panel via the controlbus. Power must be supplied to the WAREMA climatronic® WebControl from the WAREMA climatronic® power supply unit. The WAREMA climatronic® WebControl is also connected to your existing configured router via the included LAN cable. -
Page 8: Connections And Leds
Nntroduction WAREMA climatronic® WebControl 2.5 Connections and LEDs terminating resistance120 Fig. 4 Connections and LEDs on the WAREMA climatronic® WebControl (front, bottom) Pos. Function Mode button Resets device to the factory settings (see 7.2 on page 26) Reset button ... -
Page 9: User Interfaces
Aser interfaces 3 Aser interfaces 3.1 Dynamic interfaces Depending on which format you use for displaying your WAREMA climatron- ic® WebControl (tablet, PC or smartphone), you will automatically be provid- ed with different interfaces. The positioning of the user interfaces is adjusted accordingly. As a result of the different views, these interfaces may have a slightly different appearance than the images contained in this manual. -
Page 10: Configuration Menu
Aser interfaces WAREMA climatronic® WebControl 3.2 Configuration menu Fig. 7 Interface of the WAREMA climatronic® WebControl, Configuration menu ➊ Change password ➋ Synchronise* ➌ Create rooms ➍ Manage channels, groups and scenes ➎ Edit rooms icon: assign names or rename... -
Page 11: Operation Menu
Aser interfaces 3.3 Iperation menu Fig. 8 Interface of the WAREMA climatronic® WebControl, Operation menu ➊ Selection of rooms ➋ Selection of channels, groups and scenes ➌ Slider for changing the inclination angle of slat products (e.g. external venetian blinds) ➍... -
Page 12: System Menu
Aser interfaces WAREMA climatronic® WebControl 3.4 System menu Fig. 9 Interface of the WAREMA climatronic® WebControl, System menu Display of: ➊ DHCP "ON" (default) or "OFF" (see Chapter 8 on page 27) ➋ IP address (assigned to the WAREMA climatronic® WebControl by the router) in DHCP ➌... -
Page 13: Commissioning
4.1 ASB / RS 485 port There are two types of ports on your WAREMA climatronic® control panel: in the WAREMA climatronic® menu illustrated below, you can choose to enable the USB port on the left side of the control panel or, alternatively, the RS 485 port on the back of the panel: Fig. - Page 14 Another method of determining the access data for your router is to use oth- er software programs, such as the free "FING" app. After you download this app, you can use it to search your network for users. Your WAREMA clima- tronic® WebControl is listed under the name "Microchip Technology". This will help you quickly find the required IP address.
-
Page 15: Password Use
Commissioning 4.3 Password use Because a project does not yet exist when you access the system for the first time, you will need to click on the "Configuration" menu. You will then be prompted to enter a password. For initial access, please use the following preset password: 5858 You can change the password at any time. -
Page 16: Creating And Editing Rooms
Commissioning WAREMA climatronic® WebControl 4.4 Creating and editing rooms To create rooms, click the "+" button next to "Room". A window appears in which you can enter the name of your room (for exam- ple, "Kitchen"). Click "Create". The room is then created and appears in the left column of the menu. -
Page 17: Assigning Channels/Groups/Scenes To A Room
For the room that you created and highlighted in orange in the overview, you can then assign different preset channels provided by the WAREMA clima- tronic® (for sun shading products such as roller shutters, external venetian blinds, etc., but also for light). -
Page 18: Copying Channels/Groups/Scenes To An Existing Room
The commissioning process is now complete. NOTE We recommend saving the project created in your WAREMA climatronic® WebControl on an SD card once you have successfully completed the com- missioning process (see Chapter 7.1 on page 25). -
Page 19: Manual Synchronisation
NOTE If a channel, group or scene is deleted on the WAREMA climatronic® control panel, the WAREMA climatronic® WebControl will recognise this after manual synchronisation and indicate it by displaying an "!" in a red warning triangle next to the WAREMA logo (in the "Configuration"... -
Page 20: Operation Of Channels, Groups, Scenes
5.1 Iperating channels and groups The channels, groups or scenes used are read from the WAREMA climatron- NOTE ic® and have the same designations as they do on the control panel. On the WAREMA climatronic® WebControl, you can also create rooms and... -
Page 21: Operating Scenes
The graphic display does NOT show the actual product position. Therefore, when you tilt up the inclination angle slightly by pressing the button, the display on the WAREMA climatronic® WebControl jumps all the way to the top. However, this does not mean that your external venetian blind has been tilted up completely;... - Page 22 NOTE If you would like to use your scene to move products into a position other than the one predetermined by the WAREMA climatronic®, you must first teach the system how to react to the scene. Using your control panel, move the channels created in the scene into the desired position.
-
Page 23: Settings
The "control modes" (only the comfort control modes, as this does not apply to safety control modes) can be switched ON and OFF using the slider for the complete WAREMA climatronic® system. The "Absent" function can also be switched ON or OFF. - Page 24 Settings WAREMA climatronic® WebControl The safety control modes, which are familiar to you from the WAREMA climatronic® and which are activated there, are displayed in the menu line of the WAREMA climatronic® WebControl as follows: Fig. 23 The overview shows all possible alarm and notification symbols...
-
Page 25: System
Using a standard SD memory card, you can perform the following tasks in this menu: Load a project you have previously created on the WAREMA climatronic® WebControl and saved on the SD card by pressing the "Load" button Conveniently store a backup copy of the project you created on an SD mem- ory card by pressing the "Save"... -
Page 26: Resetting The Device To The Factory Settings
LED thereby indicates that communication is normal. The status LED shines steady green once the update has been successfully completed. The previously saved project file has been loaded into the WAREMA clima- tronic® WebControl from the SD card. NOTE If the status LED flashes green, the project was not previously saved on the SD card and was deleted from the WAREMA climatronic®... -
Page 27: Dhcp Disabled
Save this file on an SD card. Insert the SD card into the SD slot on the WAREMA climatronic® WebControl and briefly press the Reset button (< 1 s results in an interruption of the power supply). Communication with the router is now ensured and you can continue the commissioning process in Chapter 4.2. -
Page 28: External Access To Warema Climatronic® Webcontrol Via The Internet
WAREMA cannot be held liable for performance problems and incompati- bilities caused by applications, services or devices from third parties. WAREMA does not provide technical support in setting up a VPN access. We reserve the right to make technical changes... -
Page 29: Connecting With The Warema Climatronic® Webcontrol App
10 Connecting with the WAREMA climatronic® WebControl App Download the WAREMA app named " climatronic WebControl" from the the store for your system (App Store for Apple, Google Play Store for Android) and open it. Google Play Store: climatronic Android-App: http://www.warema.de/web-... -
Page 30: Technical Data
Ambient conditions Operating temperature °C Storage temperature °C Rel. humidity (not condensing) Article numbers WAREMA climatronic® WebControl REG 2006 861 WAREMA Renkhoff SE Hans-Wilhelm-Renkhoff-Strasse 2 97828 Marktheidenfeld 54 mm 3 TE Fig. 27 Dimensions We reserve the right to make technical changes... -
Page 31: Troubleshooting
If you are using an SD card, check whether and the status LED on the WAREMA clima- DHCP is set to "ON" or "OFF" in the saved tronic® WebControl flashes red. - Page 32 WAREMA Renkhoff SE Hans-Wilhelm-Renkhoff-Strasse 2 http://www.warema.com info@warema.com 97828 Marktheidenfeld/Main; Germany...
