LM-2310/2210
LCD Monitor
User's Manual
FCC NOTICE
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions manual, may cause interference to radio communications. It has been tested and found to comply with limits for a Class
A digital device pursuant to subpart J of Part 15 of FCC Rules, which are designed to provide reasonable protection against
interference when operated in a commercial environment. Operation of this equipment in a residential area is likely to cause
interference in which case the user at his own expense will be required to take whatever measures to correct the interference.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than the authorized technicians. The user
should consult his/her dealer for the problem happened. Warranty voids if the user does not follow the instructions in application of
this merchandise. The manufacturer is by no means responsible for any damage or hazard caused by improper application.
ABOUT THIS MANUAL
This manual assists the user to utilize the Touch Monitor LM-2310/LM-2210. This product provides exquisite touch control
capability over a stable and adjustable LCD monitor with minimal footprint.
The manufacturer of the LM-2310/LM-2210 monitor heartily apologizes to the user for reserving the right to change or to modify
this manual without notice due to the rapid and constant progress and improvement on science and technology. The user may
always obtain the most up to date information through any of our web sites: http://www.posiflex.com, http://www.posiflex.com.tw,
http://www.posiflexusa.com.
TRADE MARKS AND SERVICE MARKS
POSIFLEX is a registered trademark of Posiflex Technology, Inc.
Other brand and product names are trademarks and registered trademarks and service marks of their respective owners.
I.
FEATURES
• LM-2310/LM-2210 is principally designed for Posiflex KS-series POS
solutions
• 10" LCD monitor with tilt adjustment for industrial and commercial use
• High quality TFT LCD panel.
• Easy maintenance structure allowing easy cleaning
• Super VGA monitor resolution up to 800 x 600 pixels
• Support power supply through LCD cable from Posiflex Terminal to
operate without power adaptor
Rev. Original
© Copyright Posiflex Technology, Inc. 2012
P/N: 19610900010
Part 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the LM-2310 and is the answer not in the manual?

Questions and answers

Related Manuals for POSIFLEX LM-2310

Summary of Contents for POSIFLEX LM-2310

  • Page 1 LCD monitor with minimal footprint. The manufacturer of the LM-2310/LM-2210 monitor heartily apologizes to the user for reserving the right to change or to modify this manual without notice due to the rapid and constant progress and improvement on science and technology. The user may always obtain the most up to date information through any of our web sites: http://www.posiflex.com, http://www.posiflex.com.tw,...
  • Page 2 II. PARTS IDENTIFICATION FRONT VIEW (LM-2210/LM-2310) Main Unit Display Screen Power LED Stand REAR VIEW (LM-2210/LM-2310) Main Unit Hinge Base Stand Cable Exit Joint Bracket SIDE VIEW (LM-2310) VGA Connector and DC jack Control button area OSD button NXT button “+”...
  • Page 3 C. SIDE VIEW (LM-2210) Control button area VGA Connector and DC jack. OSD button NXT button “+” button “-“ button Power switch D. POWEPOWER LED INDICATION • Green: standby (no signal) • Blue: operating Before routing the cable, please release the hooks CABLE ROUTING IN BASE (LM-2210) Of stand’s back cover as arrowed in the right picture...

  • Page 4: Vesa Mount

    75mm and use another four bind head screws which attached in the packing kit to fasten on the VESA arm or bracket. CABLE ROUTING IN BASE (LM-2310) Before routing the cable, please release the hooks of back cover of stand as arrowed in the right picture.
  • Page 5 (On Screen Display adjustment). The OSD window will pop up on the screen. On top part of this window is a Posiflex logo with the OSD firmware version indicated to its lower right part. Below this area are a row of icons for main OSD menu.
  • Page 6 selected icon one by one from left to right and then wrap around to the leftmost part. Press “OSD” button to enter the selected sub menu. If there is no button for OSD setting, is pressed within a period of time (about 5 seconds to 1 minute as programmed) the OSD window will disappear with all the adjusted parameters saved.
  • Page 7 main menu area and the video signal mode. Press “OSD” button to select an item or return to color adjust submenu. Press “NXT” button to select among separate color adjustment, 4200K, 5000K, 6500K, 7500K, 9300K and exit. “SEPARATE COLOR ADJUST”: When this item is selected, there will be 3 adjustment indication bars between the main menu area and the video signal mode.
  • Page 8 phase adjustment icon with an adjustment indication bar under it between the main menu area and the video signal mode. Press “+” or “- ” button to adjust the pixel synchronization phase for the best picture display. Press “OSD” button to save the current setting and return to “Geometry adjust submenu”.
  • Page 9 and the video signal mode. Press “+” button to move OSD window downward. Press “-” to go upward. Press “OSD” button to save the current setting and return to “OSD submenu”. “EXIT”: Return to “Tools submenu”. “RESET TO DEFAULT”: Pressing “OSD” button on this icon will set all parameters back to the status when the monitor is factory installed.
