Argo MILO PLUS Operating Instructions Manual page 8

1) CONTROL PANEL AND FUNCTION BUTTONS AND FUNCTION BUTTONS
WITHOUT REMOTE CONTROL
2) VERTICAL FINS AND AIR INTAKE
3) WHEELS
4) CORD CABLE CLAMP
5) POWER CORD
6) AIR FILTER
Min/max operating limits (internal temperature)
Cooling: 16 °C DB / 35 °C DB
Heating: 10 °C DB / 27 °C DB
Dehumidification: 16 °C DB / 35 °C DB
Cooling mode room temperature adjustment range: 16 °C DB Cooling mode room temperature adjustment range: 16 °C DB / 30 °C DB
PRE-OPERATING CHECKS AND OPERATIONS
The following space must be maintained to ensure the operating efficiency of the portable air conditioner. The following space must be maintained to ensure the operating efficiency of the portable air conditioner. The following space must be maintained to ensure the operating efficiency of the portable air conditioner.
Open the packaging and remove the box from above. Remove the product and the other elements supplied Open the packaging and remove the box from above. Remove the product and the other elements supplied Open the packaging and remove the box from above. Remove the product and the other elements supplied
(illustrated in the box below).
LCD remote control
Round fitting for window (1) to
be positioned between the end
of the tube and the end fitting
for the window(in the
packaging is the same fitting
mounted on the porthole kit
V 06/20
temperature)
OPERATING CHECKS AND OPERATIONS
APPLIANCE START-UP APPLIANCE START
7) AIR FILTER
8) AIR EXPULSION HOSE
9) JOINT
10) END FITTING FOR WINDOW
11) REMOTE CONTROL
Type AAA batteries for the
remote control
End fitting for window,
supplied into 2 partsto be
joined with 2 tabs that fit
together. (2)
38
