PORTABLE AIR CONDITIONER (LOCAL)
MILO PLUS
OPERATING INSTRUCTIONS
Read the instructions carefully before operating the appliance or carrying out maintenance work.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or
damage. Store these instructions in a safe place for future reference.
V 11/18
20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MILO PLUS and is the answer not in the manual?

Questions and answers

Related Manuals for Argo MILO PLUS

Summary of Contents for Argo MILO PLUS

  • Page 1 PORTABLE AIR CONDITIONER (LOCAL) MILO PLUS OPERATING INSTRUCTIONS Read the instructions carefully before operating the appliance or carrying out maintenance work. Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage. Store these instructions in a safe place for future reference.
  • Page 2 Appliance filled with flammable gas R290. Before installing and using the appliance, read the owner’s manual. Before repairing the appliance, read the service manual. The Refrigerant R290 • To realize the function of the air conditioner unit, a special refrigerant circulates in the system.
  • Page 3 GENERAL OPERATING AND SAFETY INSTRUCTIONS • This appliance is a local air conditioner designed for domestic use. • Only use this air-conditioner as described in this manual. • Ensure that the required voltage and frequency (220-240V/50 Hz) match the available power source. •...
  • Page 4 • Do not use the plug as a means by which to start/stop the air conditioner: use the ON/OFF button on the remote control or on the control panel. • Do not install the air conditioner in rooms where it may receive water splashes (e.g.
  • Page 5 PRECAUTION! • Do not insert any objects into the air conditioner: this is very dangerous as the fan turns at high speed. • Ensure that air circulates freely around the unit. Do not cover the air intake and delivery grilles with drapes or any other means.
  • Page 6 The manufacturer will not be held liable if safety and accident prevention rules are not observed. V 11/18...

  • Page 7: Descrizione Dell'apparecchio

    DESCRIZIONE DELL’APPARECCHIO FRONT VIEW REAR VIEW CONTROL PANEL AND FUNCTION BUTTONS AIR FILTER WITHOUT REMOTE CONTROL AIR EXPULSION HOSE VERTICAL FINS AND AIR INTAKE JOINT WHEELS 10) END FITTING FOR WINDOW CORD CABLE CLAMP 11) REMOTE CONTROL POWER CORD AIR FILTER Min/max operating limits (internal temperature) Cooling: 16 °C DB / 35 °C DB Dehumidification: 16 °C DB / 35 °C DB...

  • Page 8: Appliance Start-Up

    PRE-OPERATING CHECKS AND OPERATIONS The following space must be maintained to ensure the operating efficiency of the portable air conditioner. APPLIANCE START-UP Open the packaging and remove the box from above. Remove the product and the other elements supplied (illustrated in the box below). Type AAA batteries for the LCD remote control remote control...
  • Page 9 INSTALLATION OF CORD WINDER HOOKS 1. Hook 2. Screw Install the cord winder hooks to the back of the unit using the When the appliance is not being used, wind the power screws, as shown in the figure. cord around the hooks. The hooks must be positioned facing upwards and Wind the cord around the hook.
  • Page 10 USE WITH WINDOW UNIT KIT To make the hole in the glass it is advisable to take 2. Insert the window unit into the window. the porthole kit accessory to the glazier. 3. Insert the round fitting into the retractable flexible pipe and 4.

  • Page 11: How To Use The Appliance

    8. If the air conditioner is not used for prolonged periods, disconnect the pipe and plug the window unit. Connect the power cord to a suitable electric socket (220–240 V). Insert the supplied batteries into the remote control and make sure the poles match. Select the desired operating mode from the remote control. HOW TO USE THE APPLIANCE This appliance can be used for cooling, dehumidifying and ventilating.

  • Page 12: Dehumidification Mode (Dry)

    3. DEHUMIDIFICATION MODE (DRY) • Press the MODE button to select Dry. • The temperature is controlled by the PCB and cannot be regulated. • In this mode, whenever the ON/OFF button is pressed, the unit switches off, the appliance saves the settings and, when switched back on again, retains them.

  • Page 13: Remote Control Operation

    4. Avoid bends in the drainage tube. REMOTE CONTROL OPERATION Insert the batteries into the remote control, while respecting the indicated polarities. Only use type AAA 1.5V batteries. Remove the batteries if the remote control is not used for a month or longer.
  • Page 14 1. ON/OFF BUTTON 2. TEMPERATURE AND TIMER BUTTON 3. MODE BUTTON 4. SWING BUTTON 5. TEMPERATURE AND TIMER BUTTON 6. FAN SPEED BUTTON 7. TIMER OFF BUTTON 8. CLOCK BUTTON 9. TIMER ON BUTTON 10. SLEEP BUTTON 11. TEMPERATURE SETTING BUTTON 13.

  • Page 15: "Swing" Button

    (1) ON/OFFBUTTON Press this button to switch the unit on or off. When switched on, the appliance will start functioning based on its last settings (save function). (2) MODE SELECTION BUTTON (MODE) Press this button to select the various operating modes, according to the following sequence: In the COOL mode the display lights up.

  • Page 16: Safety Functions

    (on the remote control) X-FAN BUTTON ( Pressing the X-FAN button in cooling or dehumidification mode, when the power is turned off the fan continues to operate for about 2 minutes to completely dry the evaporator. SLEEP BUTTON (on the remote control) Press this button to activate the Sleep function, which automatically adapts the temperature to changes in body and room temperature throughout the night, so as to optimise comfort when sleeping and minimise consumption.

  • Page 17: Care And Maintenance

    CARE AND MAINTENANCE WARNING! Prior to carrying out any cleaning or maintenance, unplug the unit from the power socket. 1. Cleaning the air filters The air filter must be checked at least once every two weeks of operation. Operating with dirty or clogged filters will decrease the effectiveness of the air conditioner and can cause serious problems.
  • Page 18 5. For complete safety, regularly check the condition of the power cord; should it be damaged through use, contact the Service Centre to replace it. TIPS FOR MAXIMISING COMFORT AND MINIMISING CONSUMPTION CHECK that: • the unit's extraction and delivery grilles are always unobstructed; •...
  • Page 19 INSTALLING THE EWPE SMART APP The EWPE SMART app is compatible with devices using standard Android or iOS operating systems. OPERATING SYSTEM REQUIREMENT FOR YOUR DEVICE: iOS Systems Android Systems Adding the EWPE SMART app to your device 1. SELECT AND DOWNLOAD THE EWPE SMART APP. Scan the QR code to open the EWPE SMART app selection page.
  • Page 20 3. SIGN UP FOR THE WIFI ACCESS. The app login screen will be displayed. For first-timer users, select the “Sign up” button to create an account and register your unit. On the sign up screen, you should: -Create a Username -Enter your email address -Create a password -Select region...
  • Page 21 6. RETURNING TO THE HOME SCREEN. Tap the back “<” button to return to the My Home screen. Your unit will be displayed on the My Home screen. Turn your unit “ON” and “OFF” by tapping the circle button For a full screen display view tap the unit display. Unit “OFF”...
  • Page 22 Single unit screen Multiple units screen START UP AND OPERATION OPERATING MODE Select “Auto”, “Cool”, “Dry”, “Fan” or “Heat” by sliding the mode icon right or left on the smartphone display. The modes will be displayed as follows. See unit instructions for detailed operation of these modes. “Cool”...

  • Page 23: Fan Modes

    FAHRENHEIT °F / CELSIUS °C SCREEN To switch the display to °C, tap the °F icon on the smartphone screen. Repeat the procedure to switch the display back to °F. Fahrenheit °F screen Celsius °C screen FAN MODES Fan mode can be adjusted by sliding the fan icon right or left on the device screen The fan modes will be displayed as follows: See Unit instructions for detailed operation.

  • Page 24: Special Functions

    SPECIAL FUNCTIONS The EWPE SMART app has multilple special functions to improve your comfort, save time and lower energy usage. Tap the “function” icon to open the special functions window. According to the unit, more then 14 special function can be activated/deactivated from this screen.
