EN
PORTABLE AIR CONDITIONER (LOCAL)
MILO PLUS
OPERATING INSTRUCTIONS
Read the instructions carefully before operating the appliance or carrying out maintenance work.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or
damage. Store these instructions in a safe place for future reference.
V 06/20
31

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MILO PLUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Argo MILO PLUS

Summary of Contents for Argo MILO PLUS

  • Page 1 PORTABLE AIR CONDITIONER (LOCAL) MILO PLUS OPERATING INSTRUCTIONS Read the instructions carefully before operating the appliance or carrying out maintenance work. Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage. Store these instructions in a safe place for future reference.
  • Page 2 Appliance filled with flammable gas R290. Before installing and using the appliance, read the owner’s manual. Before repairing the appliance, read the service manual. The Refrigerant R290  To realize the function of the air conditioner unit, a special refrigerant circulates in the system.
  • Page 3 GENERAL OPERATING AND SAFETY INSTRUCTIONS  This appliance is a local air conditioner designed for domestic use.  Only use this air-conditioner as described in this manual.  Ensure that the required voltage and frequency (220-240V/50 Hz) match the available power source. ...
  • Page 4 system, etc.). Please refer to the maximum power input data indicated on the air conditioner's data plate.  Connection to the electricity grid must take place in accordance with current installation standards.  Ensure that the automatic switches and system protection valves are able to withstand a start-up current of 6A (normally for less than 1 second).
  • Page 5 manufacturer, dealer or a similarly qualified person so as to avoid any safety risks.  Keep the unit away from fire, possible fire sources, inflammable or explosive objects.  Do not leave the unit unattended while it’s operating, turn the unit off and unplug it.
  • Page 6 In the event of an anomaly, switch the appliance off and unplug it from the socket. Do not dismantle or attempt to repair or modify the product. In the event of a malfunction, contact the service centre directly. WARNING!  Do not expose the air conditioner to direct sunlight, as the colour of the materials may change;...

  • Page 7: Front View

    DESCRIZIONE DELL’APPARECCHIO FRONT VIEW REAR VIEW V 06/20...
  • Page 8 CONTROL PANEL AND FUNCTION BUTTONS AND FUNCTION BUTTONS AIR FILTER WITHOUT REMOTE CONTROL AIR EXPULSION HOSE VERTICAL FINS AND AIR INTAKE JOINT WHEELS 10) END FITTING FOR WINDOW CORD CABLE CLAMP 11) REMOTE CONTROL POWER CORD AIR FILTER Min/max operating limits (internal temperature) temperature) Cooling: 16 °C DB / 35 °C DB Heating: 10 °C DB / 27 °C DB...
  • Page 9 (A). Flat fitting for positioning between the air discharge Hose outlet and the hose Drain hose Cord winder Screws Drainage pipe Round fitting for window unit, to be Window unit kit (3 pcs) positioned between the end of the Window unit (B) Cap (C) (A+B+C) tube and the window unit (A)
  • Page 10 Connect the round window fitting (1) to the end of the hose Open the windows and lock one of the two leaves with the then the end fitting for the window (2), previously obtained by handle. joining parts A and B Place the end fitting against the fixed leaf of the window, and draw the other leaf towards it.

  • Page 11: How To Use The Appliance

    secure it with the hook (B). The upward-facing side of the flat fitting is marked "TOP". 7. The outlet must be between 40 cm and 130 cm above the ground. Avoid tight curves or bends in the flexiblehose. 8. If the air conditioner is not used for prolonged periods, disconnect the pipe and plug the window unit. Connect the power cord to a suitable electric socket (220–240 V).

  • Page 12: Operating Modes

    Cooling, Heating, Fan Dehumidifying THE DISCHARGE TUBE MUST ALWAYS BE CONNECTED to the appliance: the only exception is when the appliance is used solely for dehumidification, in which case it is advisable to let the appliance discharge directly into the environment for maximum efficiency (consult the "Dehumidification Mode" paragraph). Regularly clean the air filters beneath the easily removable rear grille to keep the air conditioner working efficiently.

  • Page 13: Remote Control Operation

     The temperature cannot be adjusted. HOW TO ELIMINATE CONDENSATE This appliance automatically vaporises condensate in the cooling and heating mode. When the air conditioner operates in cooling and heating mode, there is no need to drain condensate continuously; only in certain weather conditions with very humid air may it occur that water deposits inside the unit.

  • Page 14: Remote Control Batteries

    REMOTE CONTROL BATTERIES Insert the batteries into the remote control, while respecting the indicated polarities. Only use type AAA 1.5V batteries. Remove the batteries if the remote control is not used for a month or longer. Do not attempt to recharge the batteries. Replace all batteries at the same time.
  • Page 15 1. ON/OFF BUTTON 2. TEMPERATURE AND TIMER BUTTON 3. MODE BUTTON 4. SWING BUTTON 5. TEMPERATURE AND TIMER BUTTON 6. FAN SPEED BUTTON 7. TIMER OFF BUTTON 8. CLOCK BUTTON 9. TIMER ON BUTTON 10. SLEEP BUTTON 11. TEMPERATURE SETTING BUTTON 13.

  • Page 16: "Swing" Button

    (1) ON/OFFBUTTON Press this button to switch the unit on or off. When switched on, the appliance will start functioning based on its last settings (save function). (2) MODE SELECTION BUTTON (MODE) Press this button to select the various operating modes, according to the following sequence: In the COOL mode the display lights up.

  • Page 17: Safety Functions

    Press this button to activate the Sleep function, which automatically adapts the temperature to changes in body and room temperature throughout the night, so as to optimise comfort when sleeping and minimise consumption. In cooling mode, the temperature increases by 1 °C in an hour then by 2 °C in two hours, and remains in this setting for the whole period.

  • Page 18: Light Function

    LIGHT FUNCTION Press the “+” and “FAN” buttons simultaneously for 3 seconds to set the activation/ deactivation of the lamp. WIFI GUIDE How to set and operate the air conditioner with Wifi 1. Make sure that the device (smartphone or Tablet) used is equipped with a standard version of Android (version 4.4 or higher) and iOS (iOS7.0 or higher) as the operating system.
  • Page 19 2. Registration and access. After installing the application, open "EWPE SMART" and click Sign up to register. PLEASE NOTE: • USERNAME: must be UNIQUE, composed of name + number, without spaces (egRossi57) • Personal email: if already registered, retrieve Username / Password. It is not possible to create another account with the same mail.
  • Page 20 Select the relevant type: 1) in case of a portable air conditioner: the third box on right 2) in case of rensidential air conditioner: the fist box on left 3) in case of commercial air conditioner: the central box V 06/20...
  • Page 21 After choosing the category of interest, proceed with the reset of the unit. Different unit reset systems can be chosen depending on the type of unit / system and remote control (with or without wifi key). Follow step by step the operative instructions depending on the selected reset system. After performing the reset following the instructions, click on Next to automatically add the unit (it’s necessary to enter Wi-Fi password).
  • Page 22 WIRE CONTROL OR REMOTE CONTROL WITH WIFI REMOTE CONTROL WITHOUT WIFI PORTABLE AIR BUTTON BUTTON (MODE andTURBO) CONDITIONER (CONTROL Direct the remote control towards Direct the remote control towards PANEL RESET) the unit. the unit. Press the button on the touch With the remote control off, press Press the "Mode"...
  • Page 23 Configuration of the main functions In the Homepage click on the device you wish to control and access the operating interface of it. 1. Select, operating mode, temperature and fan speed. Mode 2. Temperature for each mode: just slide your finger on the indicated temperature V 06/20...
  • Page 24 3. Ventilation speed for each mode: just slide your finger on the fan symbol (the adjustment possibilities vary depending on the mode) 4. Set advancedfunctions Click Function (Func) in the lower left corner of the interface to enter the advanced settings. X-FAN fucntion Vertical flap swinging Horizontal flap swinging (ifavailable)

  • Page 25: Swing Setting

    Sleep function Light on indoor unit displayTemperature unit conversion Swing setting Clic Up & down swing to turn the swing function on or off. Click the arrow in the lower right corner of the icon to go to the next screen and set the swing level. V 06/20...

  • Page 26: Other Functions

    List of Preselections Clic Timer. Then clic + and make adjustments. Otherfunctions 1. Homepage menu Click profile picture in the upper left corner of the homepage and set each menu function V 06/20...

  • Page 27: Group Control

    2. Group Control Click Group Control to use the present devices (Ex. Change the group name to "hhh" and set up the devices in the group list). When this group is working you can change the settings of the whole group.
  • Page 28 Help Press Help to view the instructions for EWPE SMART APP 5. Feedback Clic Feedback to send a feedback on the product. 6. How to reset the air conditioner WiFi module: Turn off the unit with the remote control and disconnect the air conditioner power for at least 10 seconds.

  • Page 29: Care And Maintenance

    Analysis of common network setting errors: If the short distance control does not work, perform the checks specified below: • Make sure the air conditioner power is connected. • Make sure that the air conditioner'sWiFi function is normally active. • Make sure your phone's WiFi selects the corresponding air conditioner. •...
  • Page 30 cause a short circuit. 3. Storage. When you do not envisage using the air conditioner for a long time, clean the filters before storing it away. When you do not envisage using the air conditioner for a long time, clean the filters before storing it away. When you do not envisage using the air conditioner for a long time, clean the filters before storing it away.
