4.3.5 Control board wiring
4.3.5.1 Standard control board
LED1 LED1
O
LED2 LED2

Wiring instruction:

1. Connect L and N to the power supply of AC220V/50HZ; AC110V/60HZ; L is live wire, N is
Neutral wire, and PE is grounding wire.
2. Connect LAMP to D1, D2; voltage: AC220V/50HZ; AC110V/60HZ.
3. Connect the motor wire U to the REV motor wire, connect W to the FWD motor wire, and
connect V to the motor common wire.
4. Connect C, C to the capacitor wire.
X5 Terminal
24VDC Power supply for fittings +24VDC
GND Power ground;
I.R Photocell input (N.C.);
CLLM Close limit switch;
COM Limit switch common terminal;
OPLM Open limit switch.
X7 Terminal
COM Control button common terminal;
STP Stop control button (N.O.);
CLS Gate close control button (N.O.);
OPN Gate open control button (N.O.).
Lamp Capacitor Lamp
Capacitor
D2 D1 D2 D1 C C
X3 X3
ON ON
AN1 AN1
Motor Motor Power Power
Earth Earth
M
W U V PE PE PE N L PE
X2 X2
SW1 SW1
X8 X8
Figure 18
Electric current ≤50mA）;
（
X1 X1
10A 10A 250V 250V
X5 X5
24VDC 24VDC
GND GND
I.R I.R
CLLM CLLM
COM COM
OPLM OPLM
COM COM
STP STP
CLS CLS
OPN OPN
X7 X7
24VDC 24VDC
GND GND
Infrared sensor Infrared sensor
Limit switch Limit switch
External button External button
switch switch
