JOYTECH PY800AC User Manual

Sliding Gate Operator
User's Manual
PY800AC/PY1400AC
PY800AC/PY1400AC SLIDING GATE OPERATOR
1. Products introduction
Please read the instructions carefully before proceeding.
MCU is supplied to control the gate operator.
Keypad / single button interface.
Have Infrared safety sensor interface.
Soft start and soft stop function and the soft stop width are
adjustable.
Working time is adjustable.
Motor output torque is adjustable.
User can select Auto-close function.
Manual key release designed for emergency purposes.
2. Important safety information
Carefully read and follow all safety precautions and warning before
attempting to install and use this automatic gate operator.
The gate operator should be installed by a qualified technician;
otherwise, serious personal injury or property damage may
occur.
When opening or closing the gate, do not attempt to walk or
drive through the gate.
If enable the auto-close function, must use the infrared sensor.
Children should not be allowed to play near or operate automatic
gates.
The automatic gate operator must be grounded.
Install the gate operator on the inside of the property; DO NOT
install it on the outside of the property where the public has
access to it.
Be careful when in close proximity to moving parts where hands
or fingers could be pinched.
Do not allow control devices to be placed so that a person can
1
