Summary of Contents for JOYTECH SL500DC
- Page 1 SL500DC/SL800DC Sliding Gate Opener User Manual...
-
Page 2: Table Of Contents
Table of Contents: 1. Safety Instruction………………………………………………………………………………………………1 2. Packing List…………………………………………………………………………………………………….2 3. Technical Parameters……………………………………………………………………….…………………3 4. Installation………………………………………………………………………………………………………4 4.1 Installation Drawing…………………………………………….…………………………………………4 4.2 Size of Main Machine and Accessories…………………………………………………………………5 4.2.1 Size of Main Machine………………………………………………………………………………5 4.2.2 Size of Mounting Plate…………………………………………………………………………..…5 4.3 Installation Procedures……………………………………………………………………………………6 4.3.1 Preparation Work before Installation……………………………………………..………………6 4.3.2 Main Machine Installation………………………………………………………………………..7... - Page 3 5.9 Restore Factory Setting…………………………………………………………………………………33 6. Others………………………………………………………………………………………………………….34 6.1 Maintenance……………………………………………………………………………………………...34 6.2 Troubleshooting………………………………………………………………………………………….34...
-
Page 4: Safety Instruction
Dear users, Thank you for choosing this product. Please read this manual carefully before installation and use. Please do not forget to include this manual if you send the product to a third party. 1. Safety Instruction Please read this manual carefully before installation, in which involves with important information about installation、using、maintenance and safety. -
Page 5: Packing List
A warning sign must be placed somewhere on the sliding gate according to the national standard. Please keep this instruction properly for future reference. 2. Packing List (standard) Picture Name Quantity Main machine Mounting plate Manual release key Remote control Accessories box Magnet and bracket... -
Page 6: Technical Parameters
Picture Name Quantity Steel gear rack 1m/pc Nylon gear rack 1m/pc Infrared sensor Wireless keypad Alarm lamp 3. Technical Parameters Model SL500DC SL800DC Power supply 220V/50Hz;110V/60Hz 220V/50Hz;110V/60Hz Motor power 150W 180W Gate moving speed 16-18m/min 16-18m/min Maximum weight of gate... -
Page 7: Installation
12V/9Ah 4. Installation SL500DC/SL800DC sliding gate opener is applicable to the type of sliding gate which weight is less than 500kg/800kg, length less than 12m. The drive mode adopts the rack and gear transmission. This gate opener must be installed inside the enclosure or yard for protection. -
Page 8: Size Of Main Machine And Accessories
4.2 Size of Main Machine and Accessories 4.2.1 Size of Main Machine Figure 2 4.2.2 Size of Mounting Plate 4×M8 228±0.2 Figure 3... -
Page 9: Installation Procedures
Please precast a concrete pedestal with the size of 500mm x 300mm, depth 250mm in advance, so Please make sure the distance between as to firmly install SL500DC/SL800DC gate opener. the gate and gate opener is appropriate before casting the pedestal. -
Page 10: Installation
4.3.2 Main Machine Installation a) Dismantle the plastic housing of the main machine before installation, keep the relevant fasteners properly; b) Please prepare the power cable for connecting the main machine to power supply (the number of power supply cable cores should not be less than 3 PCS, the sectional area of cable core should be over 1.5mm²... - Page 11 Figure 7 The fit clearance of output gear and rack is shown in Figure 7 below: Gear Gear rack rack Output Output gear gear Figure 8 Warnings To ensure safety, install safety stop blocks on both ends of the rail to prevent the gate from running out of the rail.
-
Page 12: Magnet Installation
Earth leakage circuit breaker must be installed in where the gate movement can be seen, and the minimum mounting height is 1.5m to avoid being touched by children. After installation, please check whether the mechanical property is good or not, whether gate ... - Page 13 power failure recovery, the control board can judge the state of the gate through detecting the angle of the direction sensor, when the magnet moves to the position that triggers the direction sensor, the travel limit switch position will be automatically restored. Function Illustration: 1.
-
Page 14: Control Board Connection And Adjustment
Button NO COM NC O/S/C O/S/C button button Hall sensor Alarm lamp 12/24VDC Battery 12V/9AH SL500DC Control Board Power supply input:220VAC / 110VAC Transformer Fuse ： 5A Motor 24VDC output: 22VAC Figure 12 1. Power supply port (P7) (Transformer Output) -
Page 15: Operation Interface Instruction
5.2 Operation Interface Instruction Figure 13 Indicator Lights: L0 (Green): Indicating the control board working status and menu status. L1-L5 (Red): Indicating the settings, parameters, errors and battery level. Setup Buttons PROG: Enter into or exit the setting menu. - and +: Function select and parameter adjust. SET: Enter into the selection, save the setting. -
Page 16: Operation Instruction For Travel Limit Position Setting
Note: The travel limit position must be settled according to the gate travel length after the first installation of the gate opener. 5.3.1 Operation Instruction for Travel Limit Position Setting: A. Operation Instruction 1. Enter into Setting Mode: a. Press “-” button for 3 sec. to enter into travel limit position setting. ... -
Page 17: Travel Setting Tips
Indicator lights will be on in sequence from L5 to L1 L1-L5 flicker simultaneously Press "—" button for 3 sec Press "SET" button once 2. Gate Closing Limit Position Setting: Release " — " button after arriving Indicator lights will be on Press “—”... -
Page 18: Remote Control Management
Indicator light status： Flicker Status Instruction Travel for closing is too long （≥ 12m ） Travel for closing is too short （≤ 0.5m ） Travel for opening is too long （≥ 12m ） Travel for opening is too short （≤ 0.5m ） Magnet is not detected STOP button is pressed, travel setting is interrupted Hall sensor signal is not detected... -
Page 19: Single Button Mode Learning (L1)
Remote Control Mode Instruction: There are two modes available for remote control under the control board for this product. Users may pair the remote control to their requirement under the corresponding mode. 1. Single button mode: Open-stop-close of the gate opener is controlled by only one button on the remote control. -
Page 20: Three Button Mode Learning (L2)
B. Operation Graphic Illustration Press the button which is to be L1 and L5 will Press "SET" button once Press "+" button for 3 sec L1 will be on flicker alternately learned on the remote control PROG L1-L5 will be on for 1 sec Press "PROG"... -
Page 21: Pedestrian Mode Function On Remote Control (L3)
3. Press “SET” button once to enter into three button learning mode. Indicator lights L3 and L5 will flicker alternately. (If an alarm lamp is connected, it’ll flash at the same time) 4. Press the button which is to be learned on the remote control. Indicator lights L1-L5 will be on ... -
Page 22: Remote Control Delete (L4)
. 1. Press and hold “+” button for 3 sec. to enter into remote control management mode Indicator light L1 will be always on. 2. Press “+” button twice to select pedestrian mode function option. Indicator light L3 will be ... -
Page 23: Remote Control Intelligent Learning
3. Press “SET” button once to enter into remote control delete option. Indicator lights L1-L5 will be on. 4. Press “SET” button for 6 sec. delete will be complete and automatically exit. Indicator lights will be off in sequence from L5 to L1, after which indicator lights L1-L5 will be on for one sec. B. -
Page 24: Basic Menu Setting
1. Simultaneously press and hold the third and fourth buttons of the paired remote control for 3 sec. The alarm lamp will flash, which indicates that the learning function of the control board is on working. 2. Press the button to be learned on the remote control under the above status. The alarm lamp will be on for one sec. -
Page 25: Running Speed Setting
5.5.1 Running Speed Setting (L1) Users may adjust the gate opening/closing speed according to the actual installation and using condition. A. Operation Instruction: 1. Press and hold “PROG” button for 3 sec. to enter into basic menu. Indicator light L0 will flicker once, then L1 will be always on. -
Page 26: Slow Stop Speed Setting
5.5.2 Slow Stop Speed Setting (L2) The setting for slow stop speed can effectively reduce the inertial force when the gate is opened or closed to its limit position, which will extend the lifetime of both gate and gate opener. A. -
Page 27: Auto-Reverse When Meeting Obstacles Setting (L3)
5.5.3 Auto-reverse When Meeting Obstacles Setting (L3) During the gate opening or closing travel, accidental collision with obstacles may pose a threat to people and property. In order to prevent impact of such collision, users may adjust the sensitivity of meeting obstacles to reduce the effect of collision. -
Page 28: Slow Stop Distance Setting
5.5.4 Slow Stop Distance Setting (L4) Setting for slow stop distance makes the gate running more smoothly and extends the service life of both gate and gate opener. Operation Instruction: Press and hold “PROG” button for 3 sec. to enter into basic menu. Indicator light L0 will flicker once, and then L1 will be always on. -
Page 29: Auto-Close Function Setting (L5)
5.5.5 Auto-close Function Setting (L5) When the gate is fully opened, the control board will send the auto-close signal to enable the gate close automatically according to the pre-set auto-close time. A. Operation Instruction: Press and hold “PROG” button for 3 sec. to enter into basic menu. Indicator light L0 will flicker once, and then L1 will be always on. -
Page 30: Advanced Menu Setting
Indicator light status： Status Instruction Flicker Cancel Auto-close function Auto-close after 10 sec. Auto-close after 20 sec. Auto-close after 30 sec. Auto-close after 40 sec. Auto-close after 50 sec. Table 2 Auto-Close Time 5.6 Advanced Menu Setting 1. Press “PROG” button for 3 Sec. under the control board standby mode, indicator light L0 will flicker once, and then enter into basic menu setting. -
Page 31: Working Mode Setting (L1)
5.6.1 Working Mode Setting (L1) Due to the usage for this product is different for users from different regions, the control board for this product offers 3 different working modes for users to choose. 1. Standard Mode (L1): Terminals for external buttons: OSC: Single button control PED: Pedestrian button STP: Stop button... -
Page 32: Acceleration Setting (L2)
B. Operation Graphic Illustration PROG PROG Press "PROG" button again Press "PROG" button for 3 sec L0 will flicker twice,L1 will be on L0 flicker once, L1 will be on for 3 sec Press "SET" button once Press "+" or "—" button to adjust the parameters, LED will show the Save and exit automatically Press "SET"... -
Page 33: Start-Up Delay Setting (L3)
B. Operation Graphic Illustration PROG PROG Press “ PROG ” button again L0 flicker once, L1 will be on for 3 sec Press "PROG" button for 3 sec L0 will flicker twice, L1 will be on Press “+” button once L2 will be on Press “+”... -
Page 34: Manual Control Mode
setting. (Table 3 Start-up Delay Time) Press “SET” button once to save and automatically exit. Indicator lights L1-L5 will be on for 1 sec. B. Operation Graphic Illustration PROG PROG Press “ PROG ” button again Press "PROG" button for 3 sec L0 flicker once, L1 will be on for 3 sec L0 will flicker twice, L1 will be on... -
Page 35: Battery Level Checking
2. Press “+” button to open the gate, then release “+” to stop running; Press “-” to close the gate, then release it to stop running. 3. Press “PROG” button once to exit the manual control mode. Indicator light L3 will be off. B. - Page 36 PROG L1-L5 will indicate the current Press “SET” button once battery level Press “PROG” button once L1-L5 will be off Exit the battery level checking Figure 34 Indicator light status： Status Instruction Flicker Battery level ≥ 13.2V Battery level ≥ 12.6V Battery level ≥...
- Page 37 6. Others 6.1 Maintenance Check whether the gate is operates normally every month. For the sake of safety, each gate is suggested to be equipped with infrared protector, besides which regular inspection is required. Before installation and operation of the gate opener, please read all instructions carefully. Our company reverses the right to change the instruction without prior notice.
- Page 38 mounting position can be mutually aligned. 4. Remove the objects. 5. Increase the sensitivity of meeting obstacles. 1. Low battery power of the remote 1. Change the remote control Remote control doesn’t control. battery. work. 2. Remote control learning is not 2.
- Page 39 Warranty Warranty Ordinance 1. To repair against this warranty card and invoice during the warranty period. 2. Warranty period: 1 year after the date of invoice. 3. Without unauthorized dismantling, any product broken or damage due to quality problem, we’ll offer the repair service for free or replace for free.
