EVAL-M3-IM564 User Manual
iMOTION™ Modular Application Design Kit
Bill of material
No. Qty Part description
49 6
RES SMD 10kΩ 1% 1/10W 0603
50 1
RES SMD 3K OHM 0.1% 1/10W 0603
51 3
RES SMD 1K OHM 0.5% 1/10W 0603
52 3
RES SMD 15K OHM 0.5% 1/10W 0603
53 1 RES SMD 10 OHM 1% 1/8W 0805
54 8
RES SMD 499 OHM 0.5% 1/10W 0603
55 1 RES SMD 4.7 OHM 5% 1/8W 0805
56 1 RES SMD 5.1 OHM 5% 1/4W 1206
57 8
RES SMD 100 OHM 0.5% 1/10W 0603
58 1 RES SMD 4.7K OHM 5% 1/10W 0603
RES SMD 0 OHM JUMPER 1/10W
59 3
0603
60 2 RES SMD 40K OHM 1% 1/10W 0603
61 1 RES SMD 20K OHM 1% 1/10W 0603
62 1 RES SMD 7.5K OHM 5% 1/10W 0603
63 2 RES SMD 12K OHM 5% 1/10W 0603
64 1 RES SMD 9.1K OHM 5% 1/10W 0603
65 1 RES SMD 100K OHM 5% 1/10W 0603
66 1 RES SMD 510K OHM 5% 1/10W 0603
67 1 RES 68 OHM 1% 2W 2512
68 1 RES SMD 30K OHM 5% 1/10W 0603
69 1 RES SMD 56K OHM 5% 1/10W 0603
70 1 RES SMD 22K OHM 5% 1/10W 0603
RES SMD 2K OHM 1% 1/10W 0603
71 8
72 1 RES SMD 27K OHM 5% 1/10W 0603
73 3 RES SMD 249 OHM 1% 1/4W 1206
User Manual
Designator Part number
R3, R28,
R45,
RC0603FR-0710KL
R17, R50,
R59
RT0603BRD073KL
R4
R5, R29,
RT0603DRD071KL
R60
R7, R8,
RT0603DRD0715KL
R26
R11 RC0805FR-0710RL
R12, R15,
R22, R25,
RT0603DRD07499RL
R42, R43,
R51, R53
R13 RC0805JR-074R7L
R19 RC1206JR-075R1L
R20, R32,
R34, R35,
RT0603DRD07100RL
R36, R37,
R38, R39
R23 RC0603JR-074K7L
R24, R52,
RC0603JR-070RL
R83
R27, R55 9C06031A4002FKHFT
R30 RC0603FR-0720KL
R31 RC0603JR-077K5L
R33, R85 RC0603JR-0712KL
R44 RC0603JR-079K1L
R47 RC0603JR-07100KL
R48 RC0603JR-07510KL
R49 SR2512FK-7W68RL
R54 RC0603JR-0730KL
R56 RC0603JR-0756KL
R57 RC0603JR-0722KL
R20, R32,
R34, R35,
RC0603FR-072KL
R36, R37,
R38, R39
R21 RC0603JR-0727KL
R23 RC1206FR-07249RL
40 of 45
Manufacturer
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Yageo
Revision 1.0
2019-09-17
