EVAL-M3-IM564 User Manual
iMOTION™ Modular Application Design Kit
EVAL-M3-IM564 main features
Table 5 provides the pin assignments of the 30 pins iMOTION™ MADK-M3 interface connector J3. This connector
is the interface to the controller board.
Table 5 J3 - iMOTION™ MADK-M3 30 pin interface connector for controller board
Pin Name
1 PWMUH
2 GND
3 PWMUL
4 GND
5 PWMVH
6 +3.3V
7 PWMVL
8 +3.3V
9 PWMWH
10 I_U
11 PWMWL
12 I_U-
13 GK
14 DCBSense
15 VTH
16 I_V
17 I_V-
18 I_W
19 I_W-
20 VCC
21 PFCG0
22 GND
23 PFCG1
24 +3.3V
25 PFCGK
26 DCBSense
27 VAC+
28 VAC-
29 IPFC+
30 IPFC-
User Manual
Pin Name Connectors
3.3 V compatible logic input for high side gate driver-Phase U
Ground
3.3 V compatible logic input for low side gate driver-Phase U
4 GND Ground
3.3 V compatible logic input for high side gate driver-Phase V
On board 3.3 V supply
3.3 V compatible logic input for low side gate driver-Phase V
On board 3.3 V supply
3.3 V compatible logic input for high side gate driver-Phase W
Positive Current sense output
3.3 V compatible logic input for low side gate driver-Phase W
Negative current sense output or Ground
Gate kill signal – active low when overcurrent is detected
DC bus positive voltage, scaled in 0-3.3 V range by a voltage divider
Thermistor Output
Not used
Not used
Not used
Not used
15 V Power Supply
3.3 V compatible logic input for PFC gate driver IC
Ground
Not used
On board 3.3 V supply
PFC Gate kill signal – active low when PFC overcurrent is detected
DC bus positive voltage, scaled in 0-3.3 V range by a voltage divider
AC voltage sensing positive cycle
AC voltage sensing negative cycle
PFC current sensing positive
PFC current sensing negative
