CHARACTERISTICS:

The HD67661-A1 is a PROFINET / EtherNet/IP Master Converter.
It allows the following characteristics:
Up to 1440 bytes in reading and 1440 bytes in writing;
Two-directional information between EtherNet/IP and PROFINET;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].

CONFIGURATION:

You need Compositor SW67661 software on your PC in order to perform the following:
Define the parameter of the PROFINET;
Define the parameter of the EtherNet/IP;
Define the list of EtherNet/IP slaves connected to the converter;
Update the device.
