Once the pool is full and all connections are made, the water qual-
ity system can be started .
When power is first introduced to the system, the heater-controller
will go through a boot-up cycle (which can last 2-5 minutes). The
pump that activates the propulsion system will automatically turn
on for about 1 minute during the boot-up cycle and will then turn
off . It's important that no buttons are pressed on the keypad during
the boot-up cycle . At the end of the boot-up cycle, the keypad
should display the temperature of the water .
If the keypad is flashing "FLO" then air may need to be bled out
of the system . Turn the power to the pool off . With a towel on
hand, slowly unthread the union that's attached to the inlet of the
circulation pump (small black pump) to allow any air to escape the
pluming . DO NOT completely unthread the union . Bleed air to the
point where you start to see water escaping from the union . Once
the air has been bled out, retighten the union (Fig. 1).
Fig . 1
Important Note: When bleeding air, you will lose some water .
It's important to take this into account before resupplying power
to the pool . The water level should cover the honey comb grill on
the front of the propulsion system housing .
After the system is turned on and the heater-controller has verified
proper water flow (to avoid heater activation in dry conditions),
the heater will automatically turn on to reach and maintain the
water temperature set point .
Heater-Controller
Your heater-controller has been programmed to run your circulat-
ing pump continuously, meaning that your pool is receiving au-
tomated circulation and filtration (through the skimmer/filter) 24
9
hours a day . The temperature of your pool is controlled by the up
and down key on your keypad (Refer to the following section for
more information on the heater-controller features).
The Heater-Controller has a freeze protection feature called Smart
Winter Mode . Smart Winder Mode senses the ambient tempera-
ture around the heater-controller and turns on the propulsion sys-
tem pump as the temperature drops . A swim current will be pro-
duced in the pool when the propulsion system pump is on . The
colder the temperature, the more frequently the pump will turn on .
The Smart Winter Mode indicator light (see Keypad Function sec-
tion) is illuminated when this feature is activated.
The heater-controller is also programmed to turn the propul-
sion system pump on 4 times daily, for 60 seconds.
The in .xe is a heater controller used by Endless Pools to control
the following features:
• Water temperature can be set between 59ºF and 92ºF (15ºC -
33ºC). Default set point at 84ºF (29ºC). The set point is changed
with the up and down keys .
• The Circulating Pump, CP, is always on . The heater can only turn
on when CP is on .
• Pump # 1 is a dual speed pump that drives the propulsion system .
Pressing Key 1 will activate the pump for the propulsion system
on low speed resulting in a slow to medium pace swim current .
Pressing Key 1 a second time will switch the pump to high speed
resulting in a faster pace swim current . A built-in timer will auto-
matically shut the pump off after 30 minutes .
Holding in Key 1 for 5-10 seconds will turn off all devices for 30
minutes to allow for servicing . Pressing Key 1 again will return
the system to normal operation .
Important Note: If a swim current is not produced when press-
ing Key 1, air may need to be bled from the propulsion system
plumbing . Press key 1 a second time to switch the pump to high
speed . With the propulsion system pump running on high speed,
slowly unthread the air plug (Fig. 2). This will allow air to escape
the plumbing . Continue to unthread the plug until a swim current
is produced in the pool . Once a swim current is produced, thread
the air plug back in the port .
Fig . 2
Propulsion System Pump
Air Plug
Drain Plug
