INSTALLATION INSTRUCTIONS: Attaching the voice kit to the DLT-V83
5
Attaching the left/right voice kit holder
Figure 3: Attaching the right voice kit holder to the DLT-V83 – step 1
Technical customer support
DLoG GmbH Phone: +49 (0)89 / 41 11 91 999
Industriestraße 15 email: helpdesk@dlog.com
D-82110 Germering Web: www.advantech-dlog.com
 DLoG GmbH 2015
Note
The figure shows the attachment of the voice kit holder to the DLT-V83 on
the right-hand side. The attachment to the left-hand side occurs
analogously but mirror-inverted.
Figure 4: Attaching the right voice kit holder to the DLT-V83 – step 2
Date: 04/14/2015
Our product manuals are available for download
at www.advantech-dlog.com in the
Download menu.
Installation instructions: Attaching the voice kit to the DLT-V83 V1.00, PN 20DLDOCX88598E00
