FDS183C-EN
Audible and visual fire alarm
User manual
Overview
Features
Product appearance and dimensions (mm)
A6V12741360_en--_b
2021-12-15
The audible and visual fire alarm FDS183C-EN can send audible and visual alarm signals
when connected with a DC 24 V power supply. It can be used with bus fire alarm controller via
I/O module, and also can be combined with gas fire alarm to create a gas fire alarm system.
When an accident occurs, the I/O module receives the start signal from the controller and
drives the audible and visual alarm to send dazzling flashing signals and harsh audible alarm
signals that alert the field personnel to quickly understand the occurrence of a fire on site and
take measures for evacuation as soon as possible, thus avoiding major accidents.
FDS183C-EN is designed for audible and visual alarm at the scene of accident, and can be
used in public space, hotels, entertainment venues, factories, shopping malls, hospitals,
schools, office buildings, stock exchanges and other places, especially the locations with low
visibility or smoke production.
Top cover and base structure for easy design, installation, commissioning and
maintenance
Loud and clear alarm sound able to alert field personnel at distance
Several ultra-bright white light-emitting diodes as the light source for striking optical display,
long lifetime and low power consumption
Figure 1
Smart Infrastructure

Advertisement

loading
Need help?

Need help?

Do you have a question about the FDS183C-EN and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Siemens FDS183C-EN

  • Page 1 FDS183C-EN is designed for audible and visual alarm at the scene of accident, and can be used in public space, hotels, entertainment venues, factories, shopping malls, hospitals, schools, office buildings, stock exchanges and other places, especially the locations with low visibility or smoke production.
  • Page 2 Installation and Commissioning FDS183C-EN is mounted on a special base, as shown in Figure 1, and has dimensions of 106 (L) × 124 (W) × 48 (D) mm. It adopts the two-wire system for connection. The 24 V and 0 V terminals are connected with terminal 1 and terminal 2 respectively, the output of which is controlled by the I/O module.
