7.3 Macro switch set-up

When you have ordered a section with Macro switches it is here that you can program specific
functionality. The Macro switches shall always control the global remote independent upon its
own settings (see 7.1.9 Remote out). The fill in form can be reached via the menu 'Micro-
switch set-up' in the SETUP-menu.
By clicking the TAB you select for which Macro you want to make these settings. You can
choose between a latching or a momentary action by activating the menu item Momentary
(also for remote outputs).
The next step is to tie a function to this switch. You can choose from:
Preset
Red-light 1
Red-light 2
Timer
PPM meter window
Module window
PPM meter window
Overview window
Talk-back to output
Sirius digital Mixer from D&R Phone +31 294 418014, email:
A preset/snapshot can be downloaded instantly by scrolling through the
brow options you can select the file that needs to be loaded.
Red-light 1 can be switched on or off by a macro switch.
Red-light 2 can be switched on or off by a macro switch.
The internal Timer can be started or stopped by macro switch.
Selects the PPM meter window on the screen
Selects the module window on the screen
Selects the PPM window on the screen
Selects the overview window on the screen
The selected output will get the TB / CUE buss signal when this function
is activated by the switch.
