- Page 1 CLUBMIX CLUBMIX OWNERS MANUAL Clubmix manual page 1...
- Page 2 The 19" rack frame can accept a maximum of 10 input modules. To become familiar with all the facilities of the ClubMix we suggest you to read this manual very carefully. It will give you important information about the operation, installation and service of this high quality product.
- Page 3 2.0 MONO INPUT CHANNEL The ClubMix channels are either mono or stereo. The front panel controls only differ in a few functions. We shall describe the mono and stereo channels separately. 2.1 Mic/line input channel The channel can operate in either the microphone or line input mode.
- Page 4 This is a 1/4" tip ring sleeve jack which is balanced. The tip is hot, ring is cold and the sleeve is wired to ground. This input has a sensitivity of -40dBu to 0 dBu. The impedance is 10k Ohms. I t will accept any Line output of tape recorders, keyboards, CD players and so Clubmix manual page 4...
- Page 5 The aux sends are factory set pre and post fader. The Aux 1 is postfader is mono and receives a summed left right signal. Aux 2 is mono and wired pre fader and receives a summed stereo signal. Clubmix manual page 5...
- Page 6 The B input can also be converted to a Phono input as described before. The tip will be the left input and the ring will be the right input. Clubmix manual page 6...
- Page 7 ON switch is activated or the Cue switch. 10.0 MASTER MODULE The master module of the ClubMix contains all the electronics for the summing of the left/right signals, the aux signals, the crossfader signals, the Cue signals, the voice over signals, and the control room monitoring as well as the power supply.
- Page 8 A level pot controls the output. 10.6 ZONE 1 OUTPUT The ClubMix has three individually adjustable main outputs apart from the Light, Aux, Subbass and Phones outputs. The Zone 1 output is intended to be the main output of the console. It is a ground compensated balanced XLR +4dBu output, which can be switched to mono.
- Page 9 11.3 SUBBASS OUTPUT The Subbass output of the ClubMix is a +4dBu ground compensated balanced output which has a frequency roll off above 150 Hz by a gentle 6 B per octave avoiding phasing errors. The subbass output is directly fed from the Zone 1 output.
- Page 10 The power supply is primarily fused between the power supply cable and the power supply transformer. For 220 Volt use the value is slow 3.15 Amp. For 110 Volt use the value is slow 6.30 Amp. Clubmix manual page 10...
- Page 11 The console can accept a maximum of 10 input modules these can be mono and/or stereo modules. 13.1 STANDARD CONTROL SETTINGS Before you switch on the ClubMix check whether you have a 110 Volt version or a 220 Volt version. This has to match with your local voltage.
- Page 12 Sleeve: ground ZONE 3 OUTPUT Jack +4dBu at 100 Ohm tip left. ring : right. sleeve : ground. INSERTS level : 0dBu (0.775 Volt) tip : return signal. ring : send signal. sleeve : ground. Clubmix manual page 12...
- Page 13 : ground. AUX SENDS Jack connector level : + 4dBu (1.22 Volt). tip: in phase. ring: ground compensation sleeve: ground PHONES Stereo jack, level : + 4du (1.22 Volt) tip: left output ring: right output sleeve: ground Clubmix manual page 13...
- Page 14 Use a 2K2 series resistor and a 680 ohm shunt resistor across the amplifier inputs. 14.2 GENERAL WIRING PROCEDURES To take full advantage of the excellent signal to noise ratio of the ClubMix it is necessary to carefully read this part of the manual.
- Page 15 Differential Destination I is essential to study the signal flow chart carefully. This will help to isolate problems in the ClubMix. If you follow the signal from input to output jacks it is possible to locate a fault. If a fault is located, inform your dealer or us and we will assist you by phone. If this will not help return the channel or master to your dealer, or the factory and we will be happy to repair it within 24 hours.
- Page 16 15.0 WORKING WITH THE CLUBMIX After you have wired up the ClubMix properly as described in earlier pages, it is time to switch on the unit. All the control settings are as described under the heading "control settings". The ledbar will light up partly and fall down slowly leaving the ON led on.
- Page 17 * Return your product yearly to your dealer to give it a safety check. * The hazard of an electrical shock can be avoided by careful ly following the above mentioned rules. Clubmix manual page 17...
- Page 18 DO NOT TOUCH a person being SHOCKED. You could also be hocked, once removed from the stock have someone send for medical help immediately. ALWAYS KEEP THE ABOVE MENTIONED INFORMATION IN MIND WHEN USING ELECTRICALLY POWERED EQUIPMENT. Clubmix manual page 18...
- Page 19 Aanvullende informatie: Het produkt voldoet hierbij aan de eisen van de richtlijn voor; Laag voltage 73 / 23 / EEG EMC-richtlijn 89 / 336 / EEG. (*) Het produkt is getest in een normale gebruiks situatie. Clubmix manual page 19...
- Page 20 Summary In this manual we have tried to give you an oversight of all the possibilities the ClubMix offers you. If there are any questions left do not hesitate to contact us or your dealer. We wish you many years of enjoyable music.
