The Software - D&R Sirius Manual

Software

7 The Software

The Sirius mixer is totally software controlled. It means that all data is digitally processed and
saved on hard disk of floppy or any other storage device. The software allows you to configure
the Sirius just the way you want it.
Set-ups can be configured in just any way you want it. It is however important to carefully
program this personal set-up, so benefiting from it will be a repeated pleasure.
It is very important to get familiar with all the software options that are built into this design.
The Software can be divided in several building blocks.
1) Global settings
2) Input and output set-up
3) Macro-switch set-up
4) User management.
5) Snapshots and pre-sets.
6) Work environment.
7) Service.
Block 1, 2, 3 and 4 are intended for one time only personal programming. Block 5 and 6 are
intended for daily use. It can be seen as the main screen display.
Block 7 is a section where all options are located to monitor the internal activities of the Sirius
for service purposes.
Directory structure
When the Sirius software is installed on your system you will be presented with a number of
typical directories (normally this should be C:\Program Files\D&R Electronica B.V.\Sirius
Digital). Such as;
Dynamics Presets
EQ Presets
Firmware
Projects
Sirius digital Mixer from D&R Phone +31 294 418014, email:
This directory is used to save the default Dynamics presets. There are
of course user directories to save personal presets. Note: The presets in
the default (Dynamics Presets) are accessible for all users.
This directory is used to save the default EQ presets. There are of
course user directories to save personal presets. Note: The presets in
the default (EQ Presets) are accessible for all users.
In this directory you can find the software for the individual software
components of the Sirius. Only during an 'update embedded software'
(see 7.7.3 Update embedded software ) this software is used.
This directory can be used to save snapshots. It is however advisable to
create several new files for individual saving of personal snapshots.
Note: The default snapshot 'Default.SRS' is always located in the
installation directory of the Sirius (normally it is C:\Program Files\D&R
Electronica B.V.\Sirius Digital).
info@d-r.nl Page 23
