Product may vary slightly from the item pictured due to model upgrades.
Read all instructions carefully before using this product.
Retain this owner's manual for future reference.
NOTE:
This manual may be subject to updates or changes. Up to date manuals are available through our
website at www.lifespanfitness.com.au
Pursuit 2
Treadmill
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pursuit 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LifeSpan Pursuit 2

Summary of Contents for LifeSpan Pursuit 2

  • Page 1 Pursuit 2 Treadmill USER MANUAL Product may vary slightly from the item pictured due to model upgrades. Read all instructions carefully before using this product. Retain this owner’s manual for future reference. NOTE: This manual may be subject to updates or changes. Up to date manuals are available through our...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Important Safety Instructions ....... 03 II. Important Electrical Information ......05 III.

  • Page 3: Important Safety Instructions

    I. IMPORTANT SAFETY INSTRUCTIONS WARNING: Read all instructions before using this treadmill. It is important your treadmill receives regular maintenance to prolong its useful life. Failing to regularly maintain your treadmill may void your warranty. DANGER To reduce the risk of electric shock disconnect your treadmill from the electrical outlet prior to cleaning and/or service work.
  • Page 4 • The treadmill is intended for in-home use only and is not suitable for commercial environments. • To disconnect, turn all controls to the off position, remove the safety key, and then remove the plug from the outlet. • The pulse sensors are not medical devices. Various factors, including the user’s movement, may affect the accuracy of heart rate readings.

  • Page 5: Important Electrical Information

    II. IMPORTANT ELECTRICAL INFORMATION WARNING! • Route the power cord away from any moving part of the treadmill including the elevation mechanism and transport wheels. • NEVER remove any cover without first disconnecting AC power. • NEVER expose this treadmill to rain or moisture. This treadmill is not designed for use outdoors, near a pool, or in any other high humidity environment.

  • Page 6: Important Operating Instructions

    III. IMPORTANT OPERATING INSTRUCTIONS • Understand that changes in speed and incline do not occur immediately. Set your desired speed on the display console and release the adjustment key. The display will obey the command gradually. • Use caution while participating in other activities while walking on your treadmill, such as watching television, reading, etc.

  • Page 7: Assembly Instructions

    IV. ASSEMBLY INSTRUCTIONS PARTS LIST Description Specification Description Specification Main Frame Lock Washer 5#Allen Wrench Oil Bottle Water Holder Safety Key Blot M8*16 Wrench w/Screw S=13, 14, 15 Driver Bolt 4.2*12 ASSEMBLY TOOLS: #5 Allen wrench 5mm 1pc NOTICE: Do not connect power before completing assembly. ASSEMBLY INSTRUCTIONS |...
  • Page 8 STEP 1 STEP 2 1. Open the carton. 1. Position the display according to the 2. Extract the parts listed above. diagram. 3. Place the Main Frame onto level ground. 2. Using the 5# Allen wrench (12), secure the display frame to Left Upright and Right Upright by using Bolt M8*16 (51) and Lock Washer (64).
  • Page 9 STEP 3 STEP 4 1. Carefully erect the display and the upright 1. Using the 5# Allen wrench (12), screw in the tubes. Bolt M8*40 (70) and Lock washer (64). 2. Do not damage the display wire when doing 2. Attach the Right Upright Tube to the Main Frame;...

  • Page 10: Folding Instructions

    Whilst supporting position (A) with our hand, gently push position (B), the marked area on the air pressure bar, with your foot. The base frame will descend automatically. (Please keep people and pets away from the machine during descent). Video Tutorial Available at: http://youtu.be/TcuPbJ7KuxQ Lifespan Fitness YouTube Channel: http://www.youtube.com/user/treadmillsvideos | FOLDING INSTRUCTIONS...

  • Page 11: Operation Guide

    VI. OPERATION GUIDE 1. OVERVIEW 2. LCD WINDOW DISPLAY SPEED: Shows speed. TIME WINDOW: Displays exercise time. DIST WINDOW: Shows the running distance. CALO WINDOW: Shows the calories burnt. Calories burnt are an estimate only and are not to be used as medical data.
  • Page 12 3. BUTTON FUNCTIONS "PROGRAM": Choose the program, cycle from manual mode, P1 – P12 to FAT. "MODE": Mode selection button. Press this button to cycle the mode. During standby mode, use MODE to choose between countdown mode, from TIME countdown, DISTANCE countdown and CALORIE countdown.
  • Page 13 • Setting DISTANCE Countdown: When Standby mode, press "MODE" until the "DISTANCE" window displays "1.00" and lights up. Use the "SPEED+", "SPEED-", buttons to set total workout distance. The setting range is between: 0.50-99.90. • Setting CALORIES Countdown: When Standby mode, press "MODE" until the "CALORIES" window displays lights up.
  • Page 14 3. When setting each parameter, press SPEED "/" to adjust the data, and CAL/PULSE window will show the data. Press the "MODE" button to finish. The window will show "F5-" and "---" before entering ready condition. Hold the hand pulse sensors with both hands and it will show your BMI data after 5 seconds.

  • Page 15: Exercise Guide

    VII. EXERCISE GUIDE PLEASE NOTE: Before beginning any exercise program, consult your physician. This is important especially if you are over the age of 45 or individuals with pre-existing health problems. The pulse sensors are not medical devices. Various factors, including the user’s movement, may affect the accuracy of heart rate readings.
  • Page 16 COOL DOWN Finish each workout with a light jog or walk for at least 1 minute. Then complete 5 to 10 minutes of stretching to cool down. This will increase the flexibility of your muscles and will help prevent post- exercise problems.

  • Page 17: Maintenance Instructions

    VIII. MAINTENANCE INSTRUCTIONS Reasonable cleaning/lubricating should be made to extend the life time of this unit. Performance is maximized when the belt and mat are kept as clean as possible. WARNING: • The mat/deck friction may lay a major role in the function and life of your treadmill and that is why we recommend you constantly lubricate this friction point to prolong the useful life of your treadmill.
  • Page 18 Running Belt Board Video Tutorial Available at: http://youtu.be/cP9NtFHfWlc Lifespan Fitness YouTube Channel: http://www.youtube.com/user/treadmillsvideos 4. HOW TO CHECK THE RUNNING MAT FOR PROPER LUBRICATION 1. Disconnect the main power supply. 2. Fold the treadmill up into the storage position. 3. Feel the underside surface of the running mat.
  • Page 19 5. ADJUSTING THE RUNNING BELT Place treadmill on a level surface. Run treadmill at approximately 4km/h, checking the running condition. If the belt has drifted to the right: Whilst the If the belt has drifted to the left: Whilst the treadmill is running at 4km/h, carefully turn treadmill is running at 4km/h, carefully turn the right adjusting bolt 1/4 turn clockwise.
  • Page 20 Some treadmills that have longer belts may give different measurements for correct belt tightness. Simply, if the belt begins to slip during use, this is an indication that the belt still needs tightening. Video Tutorial Available at: http://youtu.be/vllsamTSvvA Lifespan Fitness YouTube Channel: http://www.youtube.com/user/treadmillsvideos 20| MAINTENANCE INSTRUCTIONS...

  • Page 21: Replacing Motor Brushes

    IX. REPLACING MOTOR BRUSHES After extended use, the motor brushes in your treadmill motor will wear down, and this can lead to motor failure. It is important that you maintain your motor by replacing the brushes on either side of the motor when they are worn down.
  • Page 22 4b. Some treadmill motors may use a push 4c. Remove the clip, noting the direction in clip instead. In this case, gently push the which it was originally placed, and put it clip inwards and then up to release it from safely aside.
  • Page 23 9a. Release the clip back into its position. 9b. If your motor uses a push clip, replace the push clip by pushing it inwards and then down so that it engages the catch. 10. Check that the motor brush is held firmly 11.

  • Page 24: Exploded Diagram

    X. EXPLODED DIAGRAM | EXPLODED DIAGRAM...

  • Page 25: Parts List

    XI. PARTS LIST Description Specs Description Specs Main Frame Control Board Base Frame Display Bottom Wire Upright Frame Display Up Wire Motor Bracket Rubber Pad 2 Display Bracket Magnetic Ring Bolt ST4.2*25 Brown Single Line Cushion Bolt M8*25 Turning Tube Lock Nut Front Roller Screw...

  • Page 26: Trouble Shooting Guide

    Description Specs Description Specs Speaker Box Grill Motor Bottom Cover Elliptical Tube Plug Bolt 4.2*12 Wrench with S=13,14,15 Screw Driver Screw ST4.2*55 XII. TROUBLE SHOOTING GUIDE Code Reason Solution Signal failure within the connection A. Check that the wires connecting between display and controller.
  • Page 27 Code Reason Solution B. Check IGBT on bottom control board is burnt out. Test the above reasons and change the relevant part. Unable to Refer to E03. Control Speed No Power A. Check the fuse. B. Check that the power plug terminal is in good contact with the controller.
  • Page 28 Code Reason Solution No display A. Check if the voltage is correct. appearing on B. Check power to machine. Red on/off switch should light up. C. Change the controller. D. Change the display. LCD Screen A. Check if the voltage is correct. Flashing B.

  • Page 29: Warranty

    XIII. WARRANTY AUSTRALIAN CONSUMER LAW Many of our products come with a guarantee or warranty from the manufacturer. In addition, they come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage.

  • Page 30: Hand Pulse Technology

    If your hands are dry, then wet them slightly (saliva works as a great conductor if this doesn’t bother you). For more information, please contact our Lifespan Fitness Technical Support Department www.lifespanfitness.com.au support@lifespanfitness.com.au...
  • Page 32 WWW.LIFESPA NF ITN ES S.COM.AU...
